Sida 1/5
MADE IN USA
TWO YEAR WARRANTY
ProLink 500™ Wireless Intercom Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
A Message from the President
Congratulations on purchasing an Anchor Audio intercom
system, the choice of thousands of satisfied customers
including the White House, prestigious universities, school
districts nationwide, police and fire departments, and all
branches of the U.S. military. Our products are made of the
finest materials and built with pride in the U.S.
We’ve incorporated the latest technology into your intercom
system yet kept it simple to use. Just take a few minutes to review
this manual to ensure the maximum enjoyment of your Anchor
system. Or, you can view a demonstration video complete with a trouble shooting
section at www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru Friday between
7:00am and 5:00pm Pacific Standard Time with any questions. We love to hear
from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
GETTING STARTED / WARRANTY INFORMATION 1 .......................................................................
DEFINITIONS/APPLICATIONS / SYSTEM RANGE / RECHARGEABLE BATTERIES 2 ............................
BASIC SYTEM SETUP / BELT PACK CONTROLS / BLUETOOTH SETUP 3 .........................................
FAQ ....................................................................................................................................... 4
TROUBLESHOOTING/TECHNICAL SPECS 5 ..................................................................................
CONTENTS
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA
(Return Authorization)
number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select “Warranty Registration.” Complete the online
form to activate the two-year limited warranty on
your ProLink 500 intercom system.
1
100-0200-000/A - 03/11
MADE IN USA
TWO YEAR WARRANTY
ProLink 500™ Wireless Intercom Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
2
RECHARGEABLE BATTERIES
ProLink 500 belt packs include three “AA” rechargeable batteries and AC gang charger.
Fully charged batteries yield approximately five hours of continuous use. Alkaline batteries
can be used. Connecting the AC charger to a belt pack with alkaline batteries installed
could seriously damage the system.
INSTALL BATTERIES
1. Remove battery door
2. Install three “AA” NiMH batteries
3. Replace battery compartment door
CHARGE BATTERIES
1. Connect gang charger (included) into charg-
ing port on the bottom of the belt packs
2. Plug gang charger into AC outlet for minimun
of five hours
LED ON = battery charging
LED OFF = battery charged
WHAT IS PROLINK 500™?
ProLink is a digital wireless, full duplex intercom system that is easy to configure and
easy to operate. You can operate the MASTER belt pack with up to three REMOTE
belt packs which are identified on the side label as R1, R2 or R3. You may also have
an option of unlimited number of “Listen Only” beltpacks.The transmitter and receiver
operate in the license free 902-928 MHz range without the need for a base station.
DEFINITIONS AND APPLICATIONS
ProLink 500 - wireless duplex intercom system
ProLink 500 Network - requires a MASTER belt pack and includes up to three REMOTE belt packs
(option of unlimited number of “Listen Only” beltpacks)
Channel - A or B channel selection for different applications
E X A M P L E 1 - O n e n e t w o r k
E X A M P L E 2 - T w o i n d e p e n d a n t n e t w o r k s i n t h e s a m e f a c i l i t y
E X A M P L E 3 - D i r e c t o r o r c o a c h t a l k i n g a n d l i s t e n i n g b e t w e e n t w o c h a n n e l s
r e q u i r e s t h e f o l l o w i n g c o n f i g u r a t i o n
MASTER
BP-500M
Channel A
MASTER
BP-500M
Channel A
MASTER
BP-500M
Channel A
MASTER
BP-500M
Channel B
MASTER
BP-500M
Channel B
REMOTE 1
BP-500R
Channel A
REMOTE 1
BP-500R
CHANNEL A CHANNEL B
REMOTE 1
BP-500R
Channel A
REMOTE 2
BP-500R
Channel A
REMOTE 2
BP-500R
Channel B
REMOTE 3
BP-500R
Channel A
REMOTE 3
BP-500R
Channel B
REMOTE 1
BP-500R
Channel B
REMOTE 2
BP-500R
Channel A
REMOTE 2
BP-500R
Channel A
REMOTE 2
BP-500R
Channel B
REMOTE 3
BP-500R
Channel A
REMOTE 3
BP-500R
Channel A
REMOTE 3
BP-500R
Channel B
Head coach or director toggles between Channel
A and Channel B for conversations between a two
ProLink networks
This is an assigned group such as the
offense coach or lighting crew
This is an assigned group such as the
defense coach or sound crew
CAUTION: Do not attempt to charge alkaline batteries.
Some users are required (for emergency preparedness, etc.) to leave their
ProLink 500 units plugged into the charger at all times.
For those applications we recommend replacing the batteries every 12
months.
SYSTEM RANGE
The RF signal will travel through many solid objects. However, the more solid
objects between the belt packs, the more the range will be reduced. When the belt
packs are transmitting, the Transmit LED will flash red. If the signal drops out, the
LED will glow solid red on REMOTE belt packs only. If the belt packs are too far
apart, the REMOTE belt packs need to move closer to the MASTER belt pack.
MADE IN USA
TWO YEAR WARRANTY
ProLink 500™ Wireless Intercom Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
3
BASIC SETUP AND OPERATION
1. Charge the batteries 5-6 hours.
Note: Belt packs operate about ten to twelve hours of
continuous use per charge. (Diagram 2)
2. Find the MASTER belt pack as indicated on the top label. The
Master belt pack must be ON for each of the REMOTE belt
packs to function. (Diagram 1)
3. Plug headset cable into belt pack & adjust boom. (Diagram 2)
4. Turn on power and set headset volume. Power ON LED is
solid green and flashing green for LOW battery. (Diagram 1)
5. Set slide switch to Push to Talk or Always On mode.
(Diagram 3)
6. Choose channel A or B for all belt packs. If both channels are
used at the same time, two master belt packs are required
(See page 6). (Diagram 1)
Note: repeat above for each member’s belt pack in use.
D I A G R A M 3
“PUST TO TALK “ OR
ALWAYS ON SLIDE SWITCH
BELT CLIP
BATTERY COMPARTMENT
BLUETOOTH
PAIRING
PANEL
MIC GAIN CONTROL CHANNEL SELECTOR
RX/TX LED (RED)
“PUST TO TALK “ BUTTON
POWER LED (GREEN)
ON/OFF/VOLUME CONTROL
D I A G R A M 1
PROLINK 500 BELT PACK
Model Shown: BP-500M
CHARGING PORT
CHARGING LED (RED)
XLR CONNECTOR
D I A G R A M 2
BELT PACK CONTROLS
Mic Gain – controls the microphone sensitivity. Someone with a soft
voice will increase the Mic Gain.
Power Knob also controls headset volume. The Power LED is solid
green while ON and flashes green when batteries need recharging.
A/B Channel Selection – each member of the system must be on the
same channel to hear communication
RX/TX LED – flashes RED when transmitting and is SOLID RED on the
Remote belt packs when out of range of the Master belt pack
PTT control – push to engage in conversation and release when done
Push to Talk or Always ON slide switch for the mode of operation
preferred. If you want hands free operation, select the Always On mode.
Your belt pack is live at all times.
4-PIN XLR headset connector - use Anchor Audio headsets or any
headset with a dynamic microphone.
Charging Port for the GC-9000 gang charger – charge LED glows RED
when charging and stops glowing when charge complete.
HEADSETS
ProLink 500 uses noise cancelling headsets with a 4-pin XLR connector.
Models H-2000 (dual ear muff) and H-2000S (single ear muff) are
available. The headsets include an adjustable boom microphone.
BLUETOOTH SETUP
1. Turn ON the BT headset and put it in pairing mode to pair (“CONNECT”) with ProLink 500 beltpack.
Note: Every Bluetooth headset has its own pairing procedure. Refer to instructions.
2. The BT will auto pair with the ProLink 500 if the BT headset has been already paired to the ProLink 500 beltpack.
3. RED LED will turn ON (see on the back side of ProLink 500) in a few seconds indicating that it has paired.
4. After the RED LED turns ON push the CONNECT button to activate the audio.
5. If you want to switch to the wired headset on the same beltpack you will have to turn
OFF/disconnect the BT headset.
6. If you want to pair a new BT headset push “DISCONNECT” to delete current pairing before you start the pairing process.
