Sida 1/33
D F
-
3
5
DARK FLEET
T
HE
A
DVANCED
G
AMING
F
ORCE
U
S E R
M
A N U A L
2
DF-35
U
SER
’
S
M
ANUAL
Congratulations on your purchase of the Antec Dark Fleet DF-35.
The DF-35 is a completely unique chassis – massively convenient, but in a swifter, lighter mid-tower size. It
starts with the brilliant white LEDs set in variable-speed, knob-controlled Fleet-Release™ 120 mm access door
fans. They open to allow rapid access to the DF-35’s 11 total drive bays and two Fleet-Swap™ modular SATA
interfaces, in a blacked-out presentation interior with cable routing. Two more SATA bays – one external hot-
swappable bay on the front panel for convenience, and another floor-mounted inside for internal SSDs –
round out the feature set. With full-tower capability and convenience and swift mid-tower size, the DF-35 is
the paradox that performs.
The DF-35 comes without a power supply. Make sure you choose a power supply that is compatible with your
computer components and has a long enough power harness to reach your motherboard and peripheral devices.
We recommend our High Current, Signature Series, TruePower Quattro or TruePower New power supplies
for the latest ATX specification compliance, broad compatibility, and power savings capability.
At Antec, we continually refine and improve our products to ensure the highest quality. As such, your new case
may differ slightly from the description in this manual. This isn't a problem; it's simply an improvement. As of
the date of publication, all features, descriptions, and illustrations in this manual are correct.
Disclaimer
This manual is intended only as a guide for Antec’s computer enclosures. For more
comprehensive instructions on installing the motherboard and peripherals, please refer to
the user’s manuals that come with those components.
3
T
ABLE OF
C
ONTENTS
SECTION 1: INTRODUCTION
1.1 Getting to know your case…………………………………………………. 5
1.2 Case specifications…………………………………………………………. 6
1.3 Before you begin…………………………………………………………… 7
1.4 Locating and positioning your computer…………………………………... 8
SECTION 2: HARDWARE INSTALLATION
2.1 Setting up…………………………………………………………………... 10
2.2 Motherboard installation…………………………………………………… 12
2.3 Standard ATX power supply installation…………………………………... 14
2.4 Cable management…………………………………………………………. 15
2.5 Internal 3.5” device installation……………………………………………. 16
2.6 External 3.5” device installation…………………………………………… 17
2.7 Using Fleet-Swap™….…………………………………………………….. 18
2.8 Using the top 2.5” hot-swap bay…………………………………………… 22
2.9 External 5.25” device installation…………………………………………… 23
2.10 Internal 2.5” device installation…………………………………………….. 24
SECTION 3: FRONT I/O PORTS
3.1 USB 2.0…………………………………………………………………….. 26
3.2 AC’97 / HD audio ports……………………………………………………. 26
3.3 Power switch / reset switch / hard disk drive LED connectors……………. 27
3.4 Rewiring motherboard header connections………………………………... 27
SECTION 4: COOLING SYSTEM
4.1 Included fans………………………………………………………………. 29
4.2 Top 140 mm red LED fan…………………………………………………. 30
4.3 Front 120 mm red LED fans ……………………………………………… 30
4.4 Rear exhaust 120 mm TwoCool™ fans………………………………….... 31
4.5 Optional fans.…………………………………………………………….... 31
4.6 Washable air filters………………………………………………………... 32
