Mini P180 / Mini P180 White
User’s Manual
Manuel de l’utilisateur
Anwenderhandbuch
Manuale per l’operatore
Manual del usuario
পᡅ䂀ᯢ
Ё᭛Փ⫼ݞ
1
At Antec, we continually refine and improve our products to ensure the highest
quality. As such your new case may differ slightly from the descriptions in this
manual. This isn’t a problem; it’s simply an improvement. As of the date of publication,
all features, descriptions, and illustrations in this manual are correct.
Mini P180 / Mini P180 White User’s Manual
The Mini P180 is a small case that’s big on features. It is a professional case that
is highly configurable. For that reason, this case comes without a power supply.
Make sure you choose a power supply that conforms to the newest ATX standard
and is compatible with your motherboard.
Most ATX power supplies come with an on/off switch. Make sure you turn the
switch to the ON (I) position before you boot up your computer for the first time.
Normally, you won’t need to switch to the OFF (O) position, since the power supply
includes a soft on/off feature. This lets you turn your computer on and off by using
the soft switch on your computer case. If your computer crashes and you can’t
shut it down using the soft switch, you can switch the main power to the OFF (O)
position to clear the fault, then reboot.
Setting Up
1. Place the case upright on a flat, stable surface with the rear of the case facing you.
2. Remove the thumbscrews from the right side panel. Grip the panel at the top
and bottom and slide it towards you to open the case.
3. Remove the screws from the left side panel. Grip the panel at the top and
bottom and slide it towards you to remove the left side panel.
Note: Don’t use your fingernails to pry or lift the panels.
Inside the case you should see two separate chambers — the upper chamber
for motherboard, a 5.25” external drive and up to 5 hard drives; and the lower
chamber for power supply and two bays for 5.25” external drives. The upper
5.25” bay will accommodate a CD or DVD drive up to 170mm in length. You
will also find some wiring with marked connectors (USB, PWR etc.), drive
rails for 5.25” drives, installed I/O panel, and a 5.25” to 3.5” drive bay adapter.
Remove the middle hard disk cage to access the tool box which contains all
the hardware screws, spare silicone grommets, and standoffs.
Installing the power supply
1. With the case upright, install the power supply into the case.
Note: You can mount the power supply either side up. If you have a power
supply with a large fan, the fan should be on top once the unit is installed.
2. Between the two chambers a plastic structure lets you run cables between
the upper and lower chambers.
Disclaimer
This manual is intended only as a guide for Antec’s Computer Enclosures. For more
comprehensive instructions on installing the motherboard and peripherals, please
refer to the user’s manuals that come with those components.
2
Installing the Motherboard
This manual does not cover CPU, RAM, or expansion card installation. Please consult
your motherboard manual for specific mounting instructions and troubleshooting.
1. Lay the case down, with the open side facing up. The drive cages and power
supply area should be visible.
2. Make sure you have the correct I/O panel for your motherboard. If the panel
provided with the case isn’t suitable, please contact your motherboard
manufacturer for the correct I/O panel.
3. Line up the motherboard with the standoff holes. Determine which holes line
up and remember where they are. Not all motherboards will match with all of
the provided screw holes, and this is not necessary for proper functionality.
Some standoffs may be pre-installed for your convenience.
4. Remove your motherboard by lifting it up.
5. Install standoffs as needed and put the motherboard back in.
6. Screw in your motherboard to the standoffs with the provided Philips-head
screws. Your motherboard is now installed.
Cable Organizer
Instead of running all the power cables into the upper chamber, they can be organized
between the motherboard and right side panel.
1. Remove both side panels.
2. Choose the cables you would like to pass through the holes behind
the motherboard tray and pull them out of the power supply chamber towards
the right side of the case.
3. Route them up through the gap in the bar and use the cable ties to hold them
in place.
4. Feed the cables back through the insertion point nearest the destination of
the cable. Connect the cable and then pull the slack back to the right side of
the case.
5. When finished, secure all cables with ties and put the right panel back in place.
Connecting the Ports and LEDs
1. Connect the Reset switch (labeled RESET SW) to your motherboard at the
RST connector. Polarity (positive and negative) does not matter for switches.
2. Power Switch (labeled POWER SW) connects to the PWR connector on
the motherboard.
3. Power LED (labeled POWER LED) connects to the PWR header on
the motherboard. For LEDs, colored wires are positive (+). White or black
wires are negative (–). If the LED does not light up when the system is powered
on, try reversing the connection. For more info on connecting LEDs to your
motherboard, see your motherboard manual.
4. Hard Drive LED (labeled HDD LED) connects to the hard drive activity header.
Connecting the USB Ports
You will find a single 10-pin connector on a cable attached to the front USB ports.
This Intel standard connector is keyed so that it can’t be accidentally reversed, as
long as it is connected to a proper Intel standard motherboard header. Connect the
10-pin connector to your motherboard headers so that the blocked pin fits over the
missing header pin.
