Sida 1/10
Fusion Remote /Fusion Remote Black
User’s Manual
Manuel de l’utilisateur
Anwenderhandbuch
Manuale per l’operatore
Manual del usuario
পᡅ䂀ᯢ
TM Media Components
Ё᭛Փ⫼ݞ
1
At Antec, we continually refine and improve our products to ensure the highest
quality. As such, it’s possible that your new case may differ slightly from the
description in this manual. This isn’t a problem; it’s simply an improvement. As of
the date of publication, all features, descriptions, and illustrations in this manual
are correct.
Fusion Remote / Fusion Remote Black User’s Manual
Fusion Remote / Fusion Remote Black – Media Center Case
The Fusion Remote comes without a power supply. Make sure you choose a
power supply that is compatible with your computer components and has a long
enough power harness to reach your motherboard and peripheral devices. We
recommend our TruePower Trio, or NeoPower power supplies for the latest ATX
specification compliance, broad compatibility, and power savings capability.
Although care has been taken to prevent sharp edges in your Antec case, we
strongly recommend taking the appropriate time and care when working with it.
Avoid hurried or careless motions and the use of excessive force.
Please use reasonable precaution.
Setting Up
1. Place the case upright on a flat, stable surface.
2. Remove the thumbscrew from the back of the top panel. Slide the panel towards
the rear to remove it from the case.
3. Inside the case you should see some wiring with marked connectors (USB,
PWR etc.), an installed I/O panel and a toolbox containing all the screws you
need to install the components.
The Triple Chamber structure
Upon opening the top panel, you will find that the case is divided into three chambers:
the power supply chamber, the motherboard chamber and the HDD chamber. This
triple chamber structure isolates the heat and noise within each chamber,
resulting in much quieter and cooler operation than a traditional desktop case design.
Installing the Motherboard
This manual does not cover CPU, RAM, or expansion card installation.
Please consult your motherboard manual for specific mounting instructions and
troubleshooting.
The motherboard is located inside the main chamber with two 120mm TriCool™
fans preinstalled at the side of the case next to the CPU for effective CPU cooling.
1. Lay the case down, with the top open. The drive chamber and power supply
should be visible.
Disclaimer
This manual is intended only as a guide for Antec’s Computer Enclosures. For more
comprehensive instructions on installing the motherboard and peripherals, please
refer to the user’s manuals that come with those components.
2
2. Make sure you have the correct I/O panel for your motherboard. If the panel
provided with the case isn’t suitable, please contact your motherboard
manufacturer for the correct I/O panel.
3. Line up your motherboard with the standoff holes, and remember which holes
are lined up. Not all motherboards will match with all the provided holes; this
is normal and won’t affect functionally.
4. Remove your motherboard by lifting it up.
5. Screw the brass standoffs into the threaded holes that line up with your
motherboard. Do not over-tighten the standoffs. Some standoffs may be
pre-installed for your convenience.
6. Place your motherboard on the brass standoffs.
7. Screw in your motherboard to the standoffs with the provided Philips-head
screws. Your motherboard is now installed.
Installing the Power Supply
1. Set it on the four rubber pads at the bottom of the PSU chamber.
Note: Fusion Remote provides mounting holes for power supplies with
standard mounting layouts to be installed upside up or upside down.
2. Push the power supply to the back of the case and align the mounting holes.
3. Secure the power supply to the case with the screws provided.
4. Loosen the screw on the sliding black plate and widen the opening so you can
feed the necessary power cables through to the other side.
5. Slide the plate back to constrict the opening and secure it with the screw,
so that the airflow in the case works as designed.
Connecting the Switches and LED
1. Connect the Reset switch (labeled RESET SW) to the motherboard at the RST
connector. Polarity (positive and negative) does not matter for switches.
2. Connect the Power Switch (labeled POWER SW) from the front LCD display
to the PWR connector on the motherboard.
Note: The Power Switch from the front I/O is connected to the LCD display
module by default. This will allow you to turn your system on and off using
the remote control. If you choose to connect the Power Switch from the front
I/O directly to the motherboard instead of via the LCD display, you won’t be
able to control system power using the remote control.
3. The Power LED (labeled POWER LED) connector is located behind the Reset
connector. For LEDs, colored wires are positive (+). White or black wires are
negative (–). If the LED does not light up when the system is powered on, try
reversing the connection. For more info on connecting LEDs to your mother-
board, see your motherboard manual.
4. The Hard Drive LED (labeled HDD LED) connects to the hard drive activity
header on your motherboard or RAID card.
Connecting the USB Ports
You will find a single 10-pin connector on a cable attached to the front USB ports.
This is an Intel® standard connector that is keyed so that it can’t be accidentally
reversed when connected to a proper Intel® standard motherboard header. Connect
the 10-pin connector to the motherboard headers so that the blocked pin fits over
the missing header pin.
Note: Please check the motherboard manual for the USB header pin layout and
make sure it matches the following table.
