Sida 1/7
T
RUE
P
OWER
N
EW
750-W
ATT
P
OWER
S
UPPLY
U
SER
’
S
M
ANUAL
U
SER
’
S
M
ANUAL
T
RUE
P
OWER
N
EW
S
ERIES
TP-750/TP-750
B
LUE
P
OWER
S
UPPLY
T
HE
A
DVANCED
PSU
S
OLUTION
The TruePower New series is Antec’s full featured line of high-quality, reliable power supply units (PSUs). Combining
cutting-edge technology and an efficient design, the TruePower New series is the ideal solution for elite system
builders and quality-minded enthusiasts alike. With +12V rails that are regulated to ±3%, the TruePower New series
delivers full rated power and tight voltage regulation.
S
TANDARDS AND
F
EATURES
The TP-750/750 Blue PSU is compatible with ATX12V v2.3 and EPS12V v2.91 specifications. The TP-750 features
Universal Input, which automatically senses when you connect the power supply to any AC power source between
100 ~ 240V without having to worry about setting a voltage switch. This power supply also features Active Power
Factor Correction (Active PFC), which improves the power factor value of the power supply by altering the input
current wave shape, which helps power transmission across the grid.
S
YSTEM
P
ROTECTION
A variety of industrial-grade safety circuitry will help protect your computer: OVP (Over Voltage Protection), SCP
(Short Circuit Protection), and OCP (Over Current Protection). Sometimes the PSU will “latch” into a protected
shutdown state. This means that you will need to power off the PSU and clear the fault before it will function again.
There are no user-replaceable fuses in your TP-750.
80
PLUS®
B
RONZE
C
ERTIFICATION
80 PLUS® certification is the most widely recognized independent standard in power supply efficiency. An 80 PLUS®
certified power supply uses less energy and generates less heat to stay cooler, run quieter and last longer. The
TP-750/TP-750 Blue PSUs earn the rare 80 PLUS® Bronze level of efficiency, meaning that it has been certified to be
at least 82% efficient at a wide range of operating loads; this will lower your operating costs and help protect the
environment.
NVIDIA™
SLI™-R
EADY
C
ERTIFICATION
Antec’s TruePower New power supplies are NVIDIA™ SLI™-Ready certified for use with pairs of high-end graphics
cards for superior parallel graphics processing.
A
DVANCED
H
YBRID
C
ABLE
M
ANAGEMENT
S
YSTEM
The TP-750 uses Advanced Hybrid Cable Management. Cables that are important or mandatory are connected
directly to the PSU. There are also modular connectors on the back of the PSU to add additional cables as needed.
Using only the power cables you need will reduce clutter and improve airflow inside your case. For the list of
connected and optional cables, see Table 1.
DC
TO
DC
C
ONVERSION
Antec’s TruePower New series uses DC to DC conversion for the 5V and 3.3V rails. The DC to DC voltage regulation
module is the most advanced design, usually found on high-end motherboards, to step down DC voltage. This
module operates at 85% efficiency, as opposed to traditional magnetic amplifiers that operate at only 75%
efficiency. Another benefit is that transient response time is almost 100 times faster, providing remarkably stable
power output in response to changing loads.
P
ULSE
W
IDTH
M
ODULATION
(PWM)
F
AN
Pulse Width Modulation technology allows the TruePower New series to finely control the speed of the power
supply’s fan. By using this method instead of the traditional voltage controlled fans, this PSU’s fan can run up to
50% quieter than standard fans. A PWM fan can run as slow as 10-15% of the fan’s rated top speed, whereas a
voltage regulated fan can only go as low as 40%.
D
OUBLE
L
AYER
PCB
Designed with a double layer printed circuit board, the TruePower New series utilizes a low-density component
layout to provide better airflow throughout the casing. In addition, double layer PCBs allow for heavy-duty
components and larger traces, reducing electrical interference and resistance. This ensures greater reliability for
the power supply and components connected to it.
H
IGH
-Q
UALITY
J
APANESE
C
APACITORS
The TruePower New series features high-quality Japanese capacitors. These capacitors enhance stability and
increase the unit’s MTBF, ensuring greater reliability.
