Anywhere Cart AC-MINI Bruksanvisning

Anywhere Cart Laddare för mobil enhet AC-MINI

Läs nedan 📖 manual på svenska för Anywhere Cart AC-MINI (6 sidor) i kategorin Laddare för mobil enhet. Denna guide var användbar för 10 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/6

Thank you for choosing Anywhere Cart!

The AC-MINI is designed to charge and store 1-12 Chromebooks, tablets, and laptops.

The AC-MINI-16 is designed to charge and store 1-16 Chromebooks, tablets, and laptops.

Adjustable device divider bays allow tment of any width device in 1/2” increments.

Please review this manual before installing your equipment to learn how to safely use your cabinet.

AC input: 120V AC 60 Hz

Max amps: 15A

Max wattage: 1875W

Users Guide

for AC-MINI, AC-MINI-16

Changing The Way You Think About Carts

Identifying Components

Front (closed)

1. Top Panel Latch (Left)

2. Top Panel Latch (Right)

3. Top Panel Lock

4. Door Lock

Front (open)

5. Wall Anchor Holes

6. Retracting Doors

7. Adjustable Dividers

Top (open)

8. Device Cable Pass-Thru

9. Replaceable Power Cord

10. Power Strip

11. Fan Controller

Specications subject to change without notice

710

Follow these

important safety tips:

• Do not allow children to climb

or sit on cabinet.

• Do not use this unit outdoors.

• Liquids should not be set on or

placed near the cabinet.

• Never unplug from the outlet

when your hands are wet.

• Do not use an extension cord

with this unit.

• Improper repairs can create

signicant hazards to users and

is not covered by the warranty.

Repairs should always be

performed by a qualied

electrician.

• Before using any new charging

cabinet, have a qualied

electrician verify the current

draw does not exceed the rating

of the unit when all the devices

are installed.

• Never plug in if the switch,

receptacles, or power cord are

broken, cracked, torn or

inadequately repaired.

• Never mount directly on a wall

without have base supported.

IMPORTANT: The electrical

system is designed to handle a

MAXIMUM of 1875 Watts

at one time

Mounting Instructions

3. For added security, access the bottom mounting

holes by unlocking and opening the front retracting

doors and remove the 4mm hex bolts from the left &

right side of the device shelf. Then slide the shelf

forward and set aside.

4. Using heavy duty bolts and washers, drill holes as

needed into surface and fasten.

Verify it cannot be lifted or pulled off.

5. Replace device shelf and shelf hex bolts.

The AC-MINI is designed to be placed on top of or mounted

to a at surface such as a desk or counter top and can be

anchored to a wall for additional security.

NEVER mount directly to a wall without having the base

fully supported. Falling objects may cause serious injury.

1. Unlock the Top Panel Lock with the supplied

Top Panel Key. Remove Top Panel by pressing

the left & right latches at the same time, then lift

Top Panel upward and set aside.

2. Using the top mounting holes, measure and drill into

wall studs based on placement, then bolt into place.

WARNING

Specications subject to change without notice

Setting Up Large Devices

For devices which are larger than 14” in length, conguring the AC-MINI

is as simple as adjusting the device shelf.

The factory default position (Position 1), is perfect for Chromebooks, iPads, tablets and

Netbooks. The optional position (Position 2), is meant for 15” to 17” Laptops.

The AC-MINI can accommodate up to a 17” laptop using these simple steps:

1. Open up the front doors and slide them into cabinet.

2. Locate and remove the 4mm hex bolts from the left and right side of the device shelf.

3. Slide the shelf back until Position 2 holes are visible.

Verify your device ts properly and re-install the hex bolts.

Specications subject to change without notice

Produktspecifikationer

Varumärke:	Anywhere Cart
Kategori:	Laddare för mobil enhet
Modell:	AC-MINI
