Aruba IAP-175 Outdoor Instant Access Point
Installation Guide
0511096-02 | November 2012 1
The Aruba IAP-175 is a resilient, environmentally hardened, outdoor rated, dual-radio, dual-band IEEE
802.11 a/b/g/n wireless access point. This outdoor access point is part of Aruba’s comprehensive wireless
network solution. The IAP-175 can operate as an Aruba virtual controller or as a member of an Aruba
Instant wireless network.
There are two versions of the IAP-175, which mainly differ in the way they receive power.
IAP-175P: PoE+ powered (802.3at)
IAP-175AC: AC powered (100 - 240 VAC)
Guide Overview
"IAP-175 Hardware Overview" on page3 provides a detailed hardware overview of the three IAP-175
models.
"Outdoor Planning and Deployment Considerations" on page7 provides key questions to ask and items
to consider when deploying an outdoor wireless network.
"Installing Antennas" on page12 describes how to installing antennas.
"Weatherproofing Connections" on page12 provides instructions on weatherproofing the AP’s
connectors.
"Installing the IAP-175" on page19 describes the multi-step process for a successful installation and
deployment of an IAP-175.
"Safety and Regulatory Compliance" on page30 provides an overview of safety and regulatory
compliance information.
IAP-175 Operations
Wireless access point (IEEE 802.11 a/b/g/n)
Wireless air monitor (IEEE 802.11 a/b/g/n)
Enterprise mesh point
Enterprise mesh portal
Protocol-independent networking functionality
IAP-175P: IEEE 802.3at Power over Ethernet+ (PoE+) compatible
IAP-175AC: IEEE 802.3af Power Sourcing Equipment (PSE) device
The IAP-175 requires Aruba 3.0 Instant or later.
The IAP-175AC can function as a Power Sourcing Equipment (PSE) device by providing power through its Ethernet
port in compliance with the IEEE 802.3af standard.
2 Aruba IAP-175 Outdoor Instant Access Point | Installation Guide
Package Contents
IAP-175 Access Point
IAP-175 Mounting Bracket
Solar Shield
Pole Anchors x 2
M4 x 16 bolts, flat washers, and spring washers x4 (These bolts are attached to the solar shield)
M6 x 30 bolts, flat washers, and spring washers x2
M4 x 12 bolt, external-tooth washer, and OT copper lug x1
M8 x 110 bolt, flat washers, spring washers, and nuts x4
Metal Weatherproof Caps x2 for use on unused antenna interfaces
RJ-45 Connector Kit with plastic RJ-45 connector (IAP-175P only)
RJ-45 Connector Kit with metal RJ-45 connector (IAP-175AC only)
USB Console Cable
Installation Guide
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including
the original packing materials. Use these materials to repack and return the unit to the supplier if needed.
Aruba IAP-175 Outdoor Instant Access Point | Installation Guide 3
IAP-175 Hardware Overview
The following section describes the hardware features of the IAP-175.
Figure 1 IAP-175 Overview (IAP-175P shown)
Antenna Interface
The IAP-175 requires the use of detachable outdoor-rated antennas. Select the correct antenna type to
support the required frequency band (2.4 or 5 GHz) and the desired coverage pattern.
The IAP-175 is equipped with four, female N-type antenna interfaces; two on the top of the AP and two on
the bottom. The interfaces are grouped into diversity pairs, one pair is marked R0 (Radio 0) and the other
pair marked as R1 (Radio 1). R0 supports the 5 GHz frequency band and R1 supports the 2.4 GHz radio
band.
1 Antenna Interface (Radio 1) 5 Antenna Interface (Radio 0)
2 USB Console Interface 6 Antenna Interface (Radio 1)
3 Reserved (IAP-175P) or
Power Interface (IAP-175AC)
7 Ethernet Interface (PoE)
4 Antenna Interface (Radio 0) 8 Grounding Point
2
1
3
4
8
7
65
