AWM-2-LTH75-H Page 1 of 6
Installation Guide
AWMS-2-LTH75-H
Dual Vertical Heavy Duty Mount with
Heavy Duty F Clamp
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Do not remove/ throw away the plastic cap on channel clamp.
! This product is compatible with Atdec AWM Series products.
! Curved monitors, deep devices (such as all-in-one PCs) and offset VESA locations exert additional leverage that can exceed
the capacity of the mount even though the monitor weight may be within the stated range.
! The manufacturer accepts no responsibility for incorrect installation.
CONTENTS
Heavy Duty F Clamp
Page 2
750 Post with Guide Marks
Page 3
Channel Clamp
Page 4
Heavy Duty Tilt Head
Page 5
AWM-FH
Component Checklist + Clamp Installation
AWM-P75G
Component Checklist + Post Installation
AWM-LC
Component Checklist + Clamp Installation
AWM-LTH
Component Checklist + Head Installation
COMPONENT CHECKLIST RANGE
AWM-LC
Channel
Clamp
(x2)
AWM-LTH
Heavy Duty
Tilt Head
(x2)
AWM-FH
Heavy Duty
F Clamp
(x1)
AWM-P75G
750 Post with
Guide Marks
(x1)
• Phillips Head
Screwdriver
REQUIRED TOOLS
AWM-2-LTH75-H Page 2 of 6
1. Attach post to upper clamp
Fasteners
supplied
with post
NOTE: Post packaged separately
3. Fit xing to work surface
3.1 Place in desired location on worksurface 3.2 Screw in both pressure plates and
tighten evenly and rmly
Mounting
surface
5mm
allen key
2. Attach lower clamp to upper clamp
2.2 Attach lower clamp to upper clamp in the suitable
position using the two provided screws
2.1 Measure the worksurface thickness and
choose the suitable lower clamp position
NOTE: If there is only a small gap behind the
worksurface, perform Step 3.1 before this step.
T M B
Top
Middle
Bottom
0 - 38mm (0.00 - 1 ”) ½
11 - 53mm ( - 2 ””)
25 - 68mm (1” - 2 ”)
AWM-FH
Heavy Duty F Clamp
COMPONENT CHECKLIST
D
5mm Allen key
(x1)
B
Lower Clamp
(x1)
A
Upper Clamp
(x1)
C
Screw M8 x 16mm
(x2)
AWM-2-LTH75-H Page 3 of 6
AWM-P
Post
COMPONENT CHECKLIST
A
Post
(x1)
C
Screw
M8
(x2)
B
Post Cap
(x1)
E
Cable Cover
(x2)
D
Cable Cover Cap
(x4)
3. Position Cable Cover and t Post Cap
3.1 To reposition the cable cover, pull it straight up and out
of the post and insert it into any of the available channels
3.2 Fit post cap onto the top of the post
SQUEEZE
SQUEEZE
SQUEEZE
SQUEEZE
Optional cable
cover positions
Allen Key
(Supplied w/xing)
Post
Post Cap
NOTE: An allen key
may be stored in
the Post Cap.
1. Attach Post to Fixing
Supplied
Heavy Duty
F Clamp
AWM-FH
Also Compatible
Grommet
Clamp
AC-GC
1.1 Follow the Heavy Duty F Clamp installation
guide on pages 2 of this booklet or provided
with your alternate xing option.
2. Mount Clamp to Post
2.2 Do not mount monitor
arm on rear channel post
when using the supplied
Heavy Duty F Clamp
2.1 Slide clamp into post and
position to desired height. Turn
knob to lock in place.
If you are installing multiple mounts,
use the guide marks on post as
reference for setting the height of
each arm. Final ne-tuning may be
required once monitor is installed.
NOTE: Guide marks only available on
400 post, 510 post and 750 post.
4. Cable clips and cover
PUSH
4.1 Push the cable down
into the cable clip.
4.2 Insert one
side of the cable
clip into the
channel on the
post assembly,
then push
in the other side.
4.4 Feed
remaining
cable into
the cover.
Load cables
into cable
cover
4.3 Loop cable
and insert into
cable cover.
Cables can
exit from the
side of the
cable cover
PUSH
PUSH
