Ceiling Material up to 2"

Tile Bridge

Auxiliary Suspension int Po

Dogleg In Inverted sition Po

FAP6260T

Installation Instructions

ATS004631 RevA 7/13

FAP6260T

Installation Instructions

Mounting Template

9⁄16

" Diameter

The Atlas Sound Strategy Series® III assembly mounts easily into existing

construction drop ceiling or drywall materials.

Drop Tile Ceiling Installation

1. Remove 2' 2' or 2' 4' tile. x x

2. Align adjustable dual rail -ring assembly on rear of tile in& C

desired position.

3. Using template provided mark cut out circle with marker and cut hole. the ,

(99⁄16" FAP6260T)

4. Affix -ring assembly to rails using screws provided and position assembly on rear of ceiling tile. C

Replace tile into grid formed ends of tile bridge rails engage T-bar tile support rails.. Ensure

5. Bring service loop from rear of tile, through tile bridge C-ring to access panel located on of the / the top

enclosure. Terminate the service loop to Phoenix style connector provided (please note polarity).

6. Insert enclosure through front of tile. Using standard #2 Phillips screwdriver or screw-gun,

tighten four dogleg assemblies

until they engage C-ring assembly. the DO NOT OVER-TIGHTEN DOGLEG SCREWS!

7. Adjust front mounted switch to desired tap setting or 8power Ω* (See important note regarding 8 operation)Ω

8. Place grille on front of unit by aligning the tabs on the underside of grille with the notches on the unit bezel.

Allow magnets to hold the grille while rotating to lock the securing tabs.

9. For safety and seismic considerations a suspension ring is integrated into input panel section of unit. the

Atlas Sound strongly suggests that a support wire be installed from this support point to a suitable anchor point above ceiling grid.

In drop tile applications, this wire can usually be installed from an adjacent tile access near speaker location.

Dry Wall ("Hard Deck") Installation

1. Using the template provided, mark cut out circle in desired mounting location and cut hole. ( 9 9⁄16" FAP6260T)

2. Place tile bridge rails and C-ring through hole. Use V shaped edge of C-ring to align tile bridge assembly above ceiling-

(alignment screws provided are not required for this type of installation)

3. Bring service loop from rear of tile, through the tile bridge / C-ring to access panel located on side of the enclosure. Terminate service loop to the

Phoenix style connector provided (please note polarity).

4. Insert enclosure into hole. Using standard #2 Phillips screwdriver or screw-gun, tighten dogleg assemblies until they engage the C-ring assembly.four

DO NOT OVER-TIGHTEN DOGLEG SCREWS!
