Sida 1/5
1
Installation Guide
AT-GAIN-VOL
GAIN Volume Control Wallplate
AT-GAIN-VOL
The Atlona AT-GAIN-VOL is a volume control wallplate for use with the AT-GAIN-M50-LZ mixer
amplier. It provides a convenient, easy-to-use manual interface for controlling audio levels
of the amplier. Volume control range is from no audio (mute) to maximum output level. The
GAIN-VOL is housed in a US one-gang enclosure intended for wallplate openings and includes
interchangeable black or white trim kits.
1 x AT-GAIN-VOL
1 x White faceplate
1 x White Decora® wallplate
1 x Black faceplate
1 x Black Decora® wallplate
1 x 3-pin captive screw connector
1 x Insert w/ QR code
Package Contents
2
Installation Guide
AT-GAIN-VOL
1 Volume Knob
Rotate this knob clockwise to increase
the output volume. Rotate clockwise to
decrease the output volume.
2 Control
This port connects to the top port of the
CTRL / RS-232 port on the AT-GAIN-M50-
LZ.
Panel Descriptions
+
-
AT-GAIN-VOL
V C
12
Front Back
3
Installation Guide
AT-GAIN-VOL
Installation
1. Connect the included 3-pin captive screw connector from the Control port to the top port of
the CTRL / RS-232 port on the AT-GAIN-M50-LZ.
2. Install the AT-GAIN-VOL into the electrical box or mud ring.
3. Attach the wallplate.
V C
V C
AT-GAIN-M50-LZ
GND To CTRL / RS-232 port
on AT-GAIN-M50-LZ
}
C
V
1
Wiring Diagram
AT-GAIN-M50-LZ
