Installation Guide
AT-VTP-1000VL-BL and AT-VTP-1000VL-WH
1
Velocity 10” Touch Panel
AT-VTP-1000VL-BL and AT-VTP-1000VL-WH
1 x AT-VTP-1000VL
1 x Wall/Glass mount
4 x Mounting screws
2 x Safety screws
1 x Glass mount cover sticker
2 x Glass mount adhesive strips
1 x Installation Guide
Package Contents
Operating Notes
The Velocity 10” Touch Panel (AT-VTP-1000VL) must be on the same network as the Velocity
Gateway (AT-VGW-HW or AT-VGW-SW) or it will be unable to sync for control.
The AT-VTP-1000VL is PoE capable, to power the unit, simply plug it into a 802.3at
compatible network switch. If the network switch is not PoE capable, a PoE injector
(purchased separately) can be used.
IMPORTANT: Velocity Gateway (AT-VGW-HW or AT-VGW-SW) must be set up before the
AT-VTP-1000VL is fully functional.
The Atlona AT-VTP-1000VL is a Velocity System 10” touch panel with integrated surround
LED lighting. It features contemporary, rened styling with 1280×800 native resolution, and a
capacitive glass surface that supports multi-touch. The large 10” touch panel provides additional
space for more complex user control of video walls, high density matrix switchers, audio
DSP’s, or other applications that have greater control function requirements. Bright LED lighting
surrounding the edge of the panel is ideal for providing a visual representation of room status
in scheduling applications or for adding emphasis to AV control functions. The panel ships with
a dual-purpose one-gang wall/glass mount kit, that is a standard VESA 75 pattern to provide
compatibly with a wide variety of other options. The VTP-1000VL features Power over Ethernet
(PoE), enabling a single network connection for data and power. Setting up the touch panel
is easy, with room scheduling and AV control GUIs automatically uploaded from the Velocity
System hardware or software server gateway during system conguration.
Installation Guide
AT-VTP-1000VL-BL and AT-VTP-1000VL-WH
2
The AT-VTP-1000VL has two mounting options. In-wall or an optional stand (available through
atlona.com).
Mounting Instructions
In-wall
1 Connect the included mounting screws into the back of the wall plate. Do not over-tighten
the screws, as they should stick out a few mm from the wall plate for axing to the wall/
glass mount.
Installation Guide
AT-VTP-1000VL-BL and AT-VTP-1000VL-WH
3
2 Ax the wall/glass mount to the back box. This will dier per region.
US
