EDITION 1: JUNE 2013
Have you registered your Samurai Blade yet? Upgrade to 3 year warranty now.
Atomos Samurai Blade
User Manual
Website: www.atomos.com | Sales: sales@atomos.com | Support: support@atomos.com
Warranty & Conditions .............................................................................1
Introduction ...............................................................................................2
1. What’s included ..................................................................................3
2. What you also need ...........................................................................4
Spinning Disk Drives (HDD) ................................................................4
Solid State Drives (SSDs) ...................................................................4
Mechanical Shock and Vibration ........................................................4
Backing up and archiving ...................................................................4
HD-SDI Cables ...................................................................................5
Standard 1/4” Camcorder Mount ......................................................5
3. Mounting disks in the Master Caddy ..............................................6
4. Connecting and powering up ...........................................................7
Batteries ..............................................................................................7
Power ON/Power OFF ........................................................................8
5. Samurai Blade connections .............................................................8
6. Master Caddy and Screw Mounts ...................................................9
Master Caddy / Screw Mounts / Modularity ......................................9
7. Using the Samurai Blade ................................................................10
Using the Samurai Blade ..................................................................10
Category 1: Operating Settings ........................................................10
Category 2: Shot Setup & Monitor Tools ..........................................10
Category 3: Main Controls, REC, PLAY & MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Home Screen / Menu functions ........................................................11
File Naming / Date & Time / Display Options / Screen Lock
...........12
Batteries Screen / Auto Switching / Manual Switching ...................13
Storage Capacity Indicator / Formatting HDD/SSD / Unit Name
. . . .13
Audio In / Audio during playback .....................................................14
8. Monitoring and Recording ..............................................................15
Connect to Input
...............................................................................15
Before recording / Choosing your recording format ........................15
SmartControl / 6 ways to start recording
........................................ 16
Waveform Monitoring ...................................................................... 17
Luma Overlay / RGB Parade / Vectorscope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Monitor Assist .................................................................................. 19
Focus Assist / Zebra / False Colour ................................................ 20
Blue Only / Grid Lines / Focus Assist Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SmartLog ........................................................................................ 22
Exporting .xml ................................................................................. 23
Organising material on disk
..............................................................24
Anti-shock technology
......................................................................25
File Recovery ....................................................................................25
9. Timecode ..........................................................................................26
10. Pulldown ...........................................................................................27
11. Playback & Playout ..........................................................................28
exFAT / FAT32 disks ..........................................................................28
Playback controls .............................................................................29
Loop mode ........................................................................................30
12. Connecting and Editing ..................................................................31
Connect to Input ...............................................................................31
NLE Support ....................................................................................31
exFAT compatibility ...........................................................................31
Transferring files
................................................................................31
Importing / Import into Final Cut Pro
................................................32
SmartLog with FCPX ........................................................................33
13. External Power Supply ....................................................................34
14 . Using Connect Converters .............................................................34
15. Software Upgrades ..........................................................................35
Updating AtomOS (Firmware) ..........................................................35
16. Technical Specifications .................................................................36
The Samurai Blade is designed to a high standard but there are some
things you should be aware of to prolong the life of the unit and for your
own safety.
Batteries and power supplies
The battery supplied with the Samurai Blade is a powerful professional device,
designed to retain enough energy to supply the Samurai Blade for hours.
You should avoid short-circuiting the battery connections because this can
cause a high current to flow which can damage the cells and even pose a fire
hazard. For example, you should not carry batteries in a bag or pocket where
they may contact other metal objects such as coins.
The power supply and battery charger included are intended for use with the
Samurai Blade only. Keep the power supply, plug and cable away from water and
unplug from the mains electricity socket when not in use.
Disconnect power supplies before cleaning the Samurai Blade or its
components.
Using the Samurai Blade safely
Although the Samurai Blade is very lightweight compared to all the devices it
replaces, it is still a solid object that could cause injury if misused.
• Always make sure that the Samurai Blade is mounted securely and is
unable to fall onto anyone nearby. This is especially important when there
are children present who might be tempted to pull on cables.
• Always ensure that cable runs to the Samurai Blade are clearly visible and
do not present a trip hazard.
• Do not place on uneven or unstable surfaces.
• Do not insert anything but Samurai Blade Master Disk caddies in the Master
Disk slot on the side of the Samurai Blade.
• Do not touch the Samurai Blade’s screen with sharp, metallic or abrasive
objects.
• The Samurai Blade can become warm or hot with prolonged use. Do
not place it in contact with your lap or any part of your body where such
warming could cause discomfort or injury.
• Do not expose to strong electrical or magnetic elds.
• Do not expose to or use near liquids, rain or moisture.
• Do not dispose of the Samurai Blade or its batteries in municipal waste and do
not incinerate it or its batteries, but follow local regulations for safe disposal
Care of disk drives
Spinning disks and SSDs are very sensitive to damage from static electricity.
Please observe all the usual precautions when handling them.
Please see the section Mechanical shock and vibration later in this manual for
information about how to handle and care for your disk drives.
SDI Cables
Please remember that SDI cables use locking connectors and will not simply
pull out if they are jerked or tripped over. They are therefore a significant trip
hazard, and also a hazard to your equipment, which may be damaged if the
cables are misused.
To keep things simple but clear, we’ve only adopted two
conventions in this manual:
A helpful tip, suggestion or something to note because it’s
not obvious at first
Monospaced text indicates a menu or touch action
Contents Safety Instructions
Menu
Contents
User Manual Conventions
Atomos Samurai Blade – User Manual Edition 1: June 2013 1
Notice
Copyright © 2013 ATOMOS Global Pty Ltd (‘referred to as ATOMOS’).
