Sida 1/16
®
®making good sound better®
Line Driver / Volume Control
You have just purchased a high-performance autosound product, the
AudioControl OVERDRIVE PLUS Line Driver. The OVERDRIVE PLUS
will allow you to utilize every last bit of performance and sound quality
that you’ve always strived for from your vehicle’s sound system. In addi-
tion, your new OVERDRIVE PLUS provides you with an input to accept
an dash mounted remote level control. The OVERDRIVE PLUS optional
can now be both a line driver and a remote volume/bass control. Find a
nice dry spot well away from the rainforest drizzle, and take in the clean
air along with this Enjoyment Manual for the OVERDRIVE PLUS Line
Driver.
Key Features of the OVERDRIVE PLUS:
• High signal voltage capability: 9.5 volts RMS output
• 24 dB of gain
• Input for optional Dash Control for remote level
• Ultra-low distortion, ultra-quiet operation
• Low noise, high current output circuitry
• High-headroom PWM switching power supply
• Selectable ground isolation
• Voltage indicator LEDs
- 2 -
High-Voltage Line Driver
The OVERDRIVE PLUS is a line driver that takes the input voltage
of a high performance source unit and increases it (up to 13 volts peak).
It then delivers this punched up signal to the amplier for more lifelike
sound with less noise, less distortion and more dynamic range. In short: it
makes music played on your system sound more like live music.
Input for Optional Dash Control
An optional dash control (sold separately) can be plugged into the
OVERDRIVE PLUS to allow you to adjust the output gain remotely. You
can use this to have a remote system volume control or to have a remote
amp volume control.
Low Noise / High Current Output Circuitry
Driving long lengths of cable can present a nasty capacitive load to the
source that has to drive them. The OVERDRIVE PLUS’s low-impedance,
high-current output circuitry can easily handle long cable runs without
their associated problems.
Output Voltage Indicators
Setting voltage levels for best signal-to-noise performance can be a real
pain — especially when you have to get out the old digital voltmeter and
nd a way to make those probes stay put while you try to read the dancing
LCD display. With the OVERDRIVE PLUS’s voltage indicator LEDs,
we remove some of the pain. The rst LED indicates that you are in the
OVERDRIVE PLUS’s comfortable working range. The second LED lets
you know you are over 8 Volts and better make sure your amp can take
that much input.
- 3 -
At full gain, this unit has enough output to “overdrive”, Remember:
no pun intended, many amps. The LEDs read voltage not sound and are
only used to warn you of potential clipping issues. If you get plenty of
volume without lighting the LED’s … Don’t Worry! It just means you’re
not clipping and you have lots of Headroom in the signal.
Selectable Ground Isolation
Avoiding ground loops and grounding-related noises are of paramount
importance in any installation. For this reason we have provided a exible
scheme of isolating grounds.
AudioControl’s Bulletproof Reliability
That’s right, your AudioControl OVERDRIVE PLUS comes with a
full 5 year parts and labor warranty when it is installed by an authorized
United States AudioControl dealer. These seasoned pros have the training
and the equipment to take care of the job quickly. Keep in mind that if
you or your friends are “good with electronics” and you choose to install
it yourselves, your OVERDRIVE PLUS still has a 1 year parts and labor
warranty. To activate your warranty, simply go on-line to www.audiocon-
trol.com. Click “Mobile Audio” then “Warranty Registration” and ll in
the blanks. Or, you can go directly to http://audiocontrolregistration.com
to register.
Also, save your invoice or sales slip as proof of purchase. Not only
are these necessary for warranty purposes, they are also important if the
unforeseen disappearance of your OVERDRIVE PLUS should happen
while you are socializing at the local espresso and salmon bar. Insurance
companies have very little imagination.
AudioControl Sound Quality
Yes, when all is said and done, this is the most important feature we
offer. Amazing AudioControl Sound Quality. Our mantra is right there
with our logo: making good sound better. We believe every car system
should sound just like a live concert and your new OVERDRIVE PLUS
has been built to do just that.
