user manual
guide de l’utilisateur
RC107
v4.0 (1.0.4.0) (EN/F)
Before you begin Clock
EN/F
It is important to read this user manual prior to using your new product for the fi rst time.
Nous vous recommandons de lire ce manuel d’instructions avant d’utiliser votre
nouveau produit pour la première fois.
Plugging in for power
• Connect the supplied power adapter
to the unit’s AC IN jack at the back,
and connect to a convenient wall
outlet.
• Refer to the “Clock” section and
follow the instructions to set the
clock.
Battery back-up operation
• This clock radio is equipped with
a timekeeping system that can be
powered with a 9-volt alkaline
battery (not included). The power
failure protection circuit will not
operate unless battery is installed.
• When normal household power
is interrupted, or AC line cord
is unplugged, the batteries will
power the clock radio to keep
track of time and alarm settings
programmed into memory.
• When the battery backup functions,
the digital display will not light,
however, the function of alarm
still occurs during the power
interruption if remaining battery
power is adequate.
• Normal operation will resume after
AC power is restored so you will not
have to reset the time or the alarm.
To install the battery:
1. Remove battery compartment door
(located at the bottom of the radio)
by applying thumb pressure to the
tab on battery door and then lift
the door out and off the cabinet.
2. Connect a 9-volt alkaline battery
(not included) to the connector
plug.
3. Replace the compartment door.
Power failure indicator
When AC power is interrupted
(disconnected) for a short period of
time, both time and alarm settings
will be lost (unless batteries are
installed). After AC power is restored
(reconnected), the Digital Display
will blink to indicate that power was
interrupted and you should re-adjust
the time and alarm settings.
General controls
To set the clock:
1. Slide the / WAKE 1 / WAKE 2
/ switch to to enter the clock
setting mode.
2. Press or to set the time.
• Press and hold to decrease or
increase the time value quickly.
• The “:” fl ashes on the display in
clock setting mode.
3. Slide the / WAKE 1 / WAKE 2 /
switch to .
• The clock is in 12 hour
format. The AM indicator
lights to show AM time.
• The clock time blinks
if it is not set or after power
interruption (without back-up
battery installed).
Alkaline (NEDA 1604A/
IEC 6LR61) battery is
recommended. Carbon-zinc
battery may be used but memory
holding time will be substantially
reduced. Memory holding time
for a fresh alkaline battery is
approximately 8 hours (if alarm
is not operated) which should
take care of short, nuisance-type
AC power failures. To preserve
battery life, the unit should remain
plugged into an AC outlet. As the
battery gets older, its voltage drops
and memory may be lost. Be sure
to replace the battery periodically.
Battery should be removed if the
unit will be stored for more than
one month. Leaky battery can
badly damage the clock radio.
FCC Information
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
Some of the following information may
not apply to your particular product;
however, as with any electronic product,
precautions should be observed during
handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near
water.
• Clean only with dry cloth.
• Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
• Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifi ers) that produce heat.
• Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the
other. A grounding type plug has
two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. If
the provided plug does not fi t into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
• Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
• Only use attachments/accessories
specifi ed by the manufacturer.
• Use only with
the cart, stand,
tripod, bracket,
or table
specifi ed by the
manufacturer,
or sold with
the apparatus.
When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from
tip-over.
• Unplug this apparatus during
lightning storms or when unused
for long periods of time.
• Refer all servicing to qualifi ed
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
ADDITIONAL SAFETY INFORMATION
• The AC/AC adapter supplied with
this product is intended to be
correctly oriented in a vertical or
fl oor mount position.
• Do not use unauthorized chargers
or power adapters. Use only
chargers or power adapters that
came with your product or that is
listed in the user’s guide.
• Apparatus shall not be exposed to
dripping or splashing and no objects
fi lled with liquids, such as vases,
shall be placed on the apparatus.
• Always leave suffi cient space around
the product for ventilation. Do
not place product in or on a bed,
rug, in a bookcase or cabinet that
may prevent air fl ow through vent
openings.
• Do not place lighted candles,
cigarettes, cigars, etc. on the
product.
• Care should be taken so that objects
do not fall into the product.
• Do not attempt to disassemble
the cabinet. This product does
not contain customer serviceable
components.
• The marking information is located
at the bottom of apparatus.
• To be completely disconnect the
power input, the AC/AC adapter
of apparatus shall be disconnected
from the mains.
• AC/AC adapter is a disconnect
device. The AC/AC adapter should
not be obstructed OR should be
easily accessed during intended use.
• The ventilation should not be
impeded by covering the ventilation
openings with items such as
newspaper, table-cloths, curtains etc.
• No naked fl ame sources, such as
lighted candled, should be placed
on the apparatus.
• Attention should be drawn to the
environmental aspects of battery
disposal.
• The use of apparatus in moderate
climates.
Important battery
precautions
• Any battery may present a risk of
fi re, explosion, or chemical burn
if abused. Do not try to charge a
battery that is not intended to be
recharged, do not incinerate, and
do not puncture.
• Non-rechargeable batteries, such as
alkaline batteries, may leak if left in
your product for a long period of
time. Remove the batteries from the
product if you are not going to use
it for a month or more.
• If your product uses more than one
battery, do not mix types and make
sure they are inserted correctly.
Mixing types or inserting incorrectly
may cause them to leak.
• Discard any leaky or deformed
battery immediately. They may
cause skin burns or other personal
injury.
• Please help to protect the
environment by recycling or
disposing of batteries according to
federal, state, and local regulations.
WARNING: The battery (battery or
batteries or battery pack) shall not
be exposed to excessive heat such as
sunshine, fi re or the like.
Ecology
Help protect the environment - we
recommend that you dispose of used
batteries by putting them into specially
designed receptacles.
Note: This equipment has been tested
and found to comply with the limits
for a Class B digital device, pursuant
to Part 15 of FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee
that interference will not occur in a
particular installation. If this equipment
does cause harmful interference to
radio or television reception, which
can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician for
help.
Changes or modifi cations not expressly
approved by Audiovox could void
the user’s authority to operate the
equipment.
]
Portable Cart Warning
This Class B digital apparatus
complies with Canadian ICES-003.
Cet appareil numérique de la classe
B est conforme à la norme NMB-003
du Canada.
Electrical power
information
AC/AC adapter power supply:
120 V ~ 60 Hz
AC output: 10.5V @ 1 A
Right view Left view
• – VOLUME + – To adjust volume
• TUNING – To adjust radio frequency
• USB Charging – To charge your cell
phones via this USB connector
Top view
• ON/OFF – To turn radio on or off;
cancel the wake function.
• / WAKE 1 / WAKE 2 / – To
select setting mode ( : lock
mode, : wake WAKE 1 / WAKE 2
setting mode, : clock setting
mode)
• SNOOZE/SLEEP OFF – To quiet
the wake alarm or wake radio
temporarily (default: 9 minutes);
cancel the sleep function
• – To decrease value when setting
clock, wake, snooze and sleep
modes.
• – To increase value when setting
clock, wake, snooze and sleep
modes.
• WAKE 1 MODE – To activate the
Wake 1 settings; change wake 1
mode (radio/alarm).
• WAKE 2 MODE – To activate the
Wake 2 settings; change wake 2
mode (radio/alarm).
• SLEEP – To activate the sleep
function
• AM/FM – To select radio band
• AM – AM time
• 1 – Wake time 1 to alarm
• 1 – Wake time 1 to radio
• 2 – Wake time 2 to alarm
• 2 – Wake time 2 to radio
Display
Indicator
Setting wake time
1. Slide the / WAKE 1 / WAKE 2 /
switch to select or WAKE 1
WAKE 2 setting mode.
2. Press or to set the wake time.
• Press and hold to decrease or
increase the time value quickly.
• The “:” fl ashes on the display in
wake time setting mode.
3. Slide the / WAKE 1 / WAKE 2 /
switch back to .
Selecting wake source
• Press WAKE 1 or WAKE 2
repeatedly to select a wake source
(alarm / radio ).
• A green indicator will light next to
the corresponding wake setting icon
when the wake source is selected.
Wake to alarm
When wake to alarm is selected, the
green indicator will light next to the
icon.
• The unit is equipped with GRAD-
U-WAKE. The alarm volume will
increase gradually to its maximum
in about 30 to 45 seconds.
• Note that the Alarm mode is not
affected by the volume control. If
you set the SLEEP function with a
low volume setting for the Radio
before going to bed, it is advisable
to use Wake to Alarm mode to
In sleep mode, the unit will turn off
automatically after a specifi ed time.
To set sleep time:
1. Press . The time display will SLEEP
show “0:59” and the radio will turn
on.
2. While holding , press SLEEP or
to set the time for sleep mode.
• The time range is from 1 minute
to 2 hours. (The default time is 59
minutes.)
3. Release and the display will SLEEP
revert to the current time.
• You may select radio stations as
usual in sleep mode. The radio
will turn off when the preset time
elapses.
To cancel the sleep function:
• If you decide to turn off the radio
sooner, press SNOOZE/SLEEP OFF
or .ON/OFF
To view remaining time in sleep
mode:
• Press SLEEP once.
The last setting in SLEEP
mode is saved for future use.
Use the USB charging port to charge
your smartphone or to power usb
powered devices such as a USB type
lamp or fan.
If you are using a smartphone:
The unit can charge your smartphone if
its jack for charging is a micro USB jack.
If its jack for charging is not a micro
USB jack, the unit may not be able to
charge it.
If you are using an iPhone:
The unit can charge iPhone 2G, iPhone
3G, iPhone 3GS and iPhone 4G.
To connect your cell phone for
charging:
Use a USB cable (not included) to
connect your cell phone to the USB
connector of the unit. Your cell phone
should start charging.
Sleep function USB charging
Warranty information
12 Month Limited Warranty
Applies to RCA Clock Radios
AUDIOVOX ACCESSORIES CORP. (the
Company) warrants to the original retail
purchaser of this product that should
this product or any part thereof, under
normal use and conditions, be proven
defective in material or workmanship
within 12 months from the date of
original purchase, such defect(s) will be
repaired or replaced with reconditioned
product (at the Company’s option)
without charge for parts and repair
labor.
To obtain repair or replacement
within the terms of this Warranty, the
product is to be delivered with proof
of warranty coverage (e.g. dated bill
of sale), specifi cation of defect(s),
transportation prepaid, to the Company
at the address shown below.
This Warranty does not extend to the
elimination of externally generated
static or noise, to correction of
antenna problems, loss/interruptions of
broadcast or internet service, to costs
incurred for installation, removal or
reinstallation of product, to corruptions
caused by computer viruses, spyware or
other malware, to loss of media, fi les,
data or content, or to damage to tapes,
discs, removable memory devices or
cards, speakers, accessories, computers,
computer peripherals, other media
players, home networks or vehicle
electrical systems.
This Warranty does not apply to any
product or part thereof which, in the
opinion of the Company, has suffered
or been damaged through alteration,
improper installation, mishandling,
misuse, neglect, accident, or by removal
or defacement of the factory serial
number/bar code label(s). THE EXTENT
OF THE COMPANY’S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE
REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE
COMPANY’S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
This Warranty is in lieu of all other
express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED
TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH
OF ANY WARRANTY HEREUNDER
INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY MUST BE
BROUGHT WITHIN A PERIOD OF 24
MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY. No person or
representative is authorized to assume
for the Company any liability other than
expressed herein in connection with the
sale of this product.
Some states do not allow limitations on
how long an implied warranty lasts or
the exclusion or limitation of incidental
or consequential damage so the above
limitations or exclusions may not apply
to you. This Warranty gives you specifi c
legal rights and you may also have
other rights which vary from state to
state.
Recommendations before returning
your product for a warranty claim:
• Properly pack your unit. Include
any remotes, memory cards, cables,
etc. which were originally provided
with the product. However DO NOT
return any removable batteries,
even if batteries were included
with the original purchase. We
recommend using the original
carton and packing materials. Ship
to the address shown below.
• Note that product will be returned
with factory default settings.
Consumer will be responsible to
restore any personal preference
settings.
Audiovox Electronics Corp.
Attn: Service Department.
150 Marcus Blvd.
Hauppauge N.Y. 11788
1-800-645-4994
For Canada Customers, please ship to:
Audiovox Return Centre
c/o Genco
6685 Kennedy Road,
Unit#3, Door 16,
Mississuaga, Ontario
L5T 3A5
Illustrations contained within this
publication are for representation only
and subject to change.
The descriptions and characteristics
given in this document are given as
a general indication and not as a
guarantee. In order to provide the
highest quality product possible,
we reserve the right to make any
improvement or modifi cation without
prior notice.
© 2011 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
Trademark(s) ® Registered
Printed in China
Visit http://store.audiovox.com to find the best
accessories for your products.
wake you up since the Alarm will be
at a louder volume setting than the
Radio mode.
Wake to radio
When wake to radio is selected, the
green indicator will light next to the
icon.
To set wake station:
1. Select radio band.
2. Select desired station.
3. Adjust the volume by + VOL –.
Turning off alarm
To silence the alarm momentarily:
• Press SNOOZE/SLEEP OFF or any
one of the SmartSnoozeTM buttons
( / ). The alarm will sound again
when the snooze period is over.
(Read “SmartSnoozeTM”)
To stop the alarm completely:
• Press ON/OFF. The alarm will
activate again at the same time on
the following day.
To disable the wake function
completely:
• Press WAKE 1 WAKE 2 or MODE
MODE repeatedly until no indicator
lights next to the wake icons
( / ) on the display.
• Charging function may
not be supported for
all phones or electronic
devices.
• Charging function is not
available in AM mode.
• Before charging your cell
phone, please ensure the radio
is connected to the supplied AC
adapter.
Radio Wake function
Turning on/off the Radio
Press the button on the top ON/OFF
of the unit to turn on the radio. Press
again to turn off the radio.
Switching bands
Slide the band switch on the top of
the unit to select between AM and FM
band.
Tuning to stations
Rotate the knob on the TUNING
right of the unit to adjust the radio
frequency with reference to the tuning
dial scale.
Built-in AFC
The Built In Automatic Frequency
Control (AFC) works only on FM. It helps
to reduce drift on FM reception and
keeps the radio locked in on the FM
station to which it is tuned.
When tuning in FM stations, you may
notice that the station you are tuning
can be well-tuned on two or three
nearby points on the dial. Always tune
carefully at the loudest and clearest
point.
SmartSnoozeTM
• This operation allows extra sleep
time when the alarm sounds. The
alarm can be turned off temporarily
by pressing SNOOZE/SLEEP OFF
or any one of the SmartSnoozeTM
buttons until the snooze period is
over.
• SmartSnoozeTM buttons include:
/ / SNOOZE/SLEEP OFF.
• Snooze function can be used
repeatedly up to 2 hours. After this,
the alarm will turn off until the
next alarm conditions are met.
• SmartSnoozeTM will be activated
only when the / WAKE 1 /
WAKE 2 / switch is set to .
To set the “quiet” period with
Snooze:
1. Press and hold SNOOZE/SLEEP
OFF in clock mode, radio mode,
clock setting mode or alarm setting
mode.
2. Press or to adjust snooze time.
Then release SNOOZE/SLEEP OFF
button to save the setting.
• The Snooze Period range can be
from 1 to 30 minutes. (The default
time is 9 minutes)
AM antenna
A built-in ferrite rod antenna eliminates
the need for an outside antenna for
AM reception. Rotating the unit slightly
may improve reception of distant AM
stations.
You can activate the
previously set alarm time by
pressing the WAKE 1 MODE
or button.WAKE 2 MODE
your cell phone
USB cable (not included)
Produktspecifikationer
| Varumärke: | Audiovox |
| Kategori: | Radio |
| Modell: | RC107 |
Behöver du hjälp?
Om du behöver hjälp med Audiovox RC107 ställ en fråga nedan och andra användare kommer att svara dig
Radio Audiovox Manualer
18 September 2024
18 September 2024
18 September 2024
18 September 2024
18 September 2024
18 September 2024
18 September 2024
18 September 2024
18 September 2024
Radio Manualer
- Radio Sony
- Radio Xiaomi
- Radio Bosch
- Radio AEG
- Radio Philips
- Radio Panasonic
- Radio Daewoo
- Radio DeWalt
- Radio Garmin
- Radio Grundig
- Radio JVC
- Radio JBL
- Radio Kenwood
- Radio Karcher
- Radio Motorola
- Radio Medion
- Radio Quigg
- Radio Topcom
- Radio Yamaha
- Radio Adler
- Radio Aiwa
- Radio Albrecht
- Radio Akai
- Radio Acoustic Energy
- Radio Argon
- Radio OneConcept
- Radio Lexibook
- Radio Sharp
- Radio Telefunken
- Radio Silvercrest
- Radio Makita
- Radio Hitachi
- Radio Nedis
- Radio Thomson
- Radio Tristar
- Radio Lenco
- Radio Pyle
- Radio Vonroc
- Radio Audizio
- Radio Stanley
- Radio Manta
- Radio GPO
- Radio Caliber
- Radio Timex
- Radio OK
- Radio Hyundai
- Radio Sonoro
- Radio Renkforce
- Radio ECG
- Radio Moulinex
- Radio Ryobi
- Radio Bush
- Radio Clatronic
- Radio Lowrance
- Radio Sencor
- Radio GPX
- Radio Festool
- Radio Blaupunkt
- Radio Metabo
- Radio Logik
- Radio Milwaukee
- Radio Telestar
- Radio Salora
- Radio Denver
- Radio Imperial
- Radio Schneider
- Radio Sanyo
- Radio Vitek
- Radio Einhell
- Radio Hama
- Radio Soundmaster
- Radio Brigmton
- Radio Denon
- Radio Sunstech
- Radio Sennheiser
- Radio Maginon
- Radio Midland
- Radio GlobalTronics
- Radio Technisat
- Radio GoGEN
- Radio Rockford Fosgate
- Radio Marquant
- Radio Nordmende
- Radio AudioAffairs
- Radio Krüger And Matz
- Radio Binatone
- Radio Steren
- Radio Kicker
- Radio Bose
- Radio Audiosonic
- Radio Clarion
- Radio Proline
- Radio Coby
- Radio Crosley
- Radio Envivo
- Radio Muse
- Radio Teufel
- Radio Bigben Interactive
- Radio Kathrein
- Radio Olympia
- Radio Pure
- Radio Powerplus
- Radio Porter-Cable
- Radio Uniden
- Radio Ion
- Radio Roberts
- Radio Yaesu
- Radio Tesco
- Radio Artsound
- Radio Dual
- Radio Boss
- Radio Terris
- Radio Oricom
- Radio Camry
- Radio Cobra
- Radio MB Quart
- Radio Switel
- Radio Bigben
- Radio Auna
- Radio Alba
- Radio Clas Ohlson
- Radio Naxa
- Radio Lexon
- Radio Sven
- Radio Ricatech
- Radio Konig
- Radio Boston Acoustics
- Radio Icom
- Radio Mpman
- Radio Trevi
- Radio Sogo
- Radio JL Audio
- Radio Zebra
- Radio Technaxx
- Radio Nikkei
- Radio PerfectPro
- Radio Peaq
- Radio Freecom
- Radio Jensen
- Radio Roadstar
- Radio Gira
- Radio Scott
- Radio Jung
- Radio Sangean
- Radio Basetech
- Radio Dnt
- Radio Balance
- Radio Audio Pro
- Radio HQ
- Radio Be Cool
- Radio Noveen
- Radio Karcher Audio
- Radio CRUX
- Radio Fusion
- Radio IHome
- Radio August
- Radio Infinity
- Radio AIC
- Radio Ruarkaudio
- Radio Tivoli Audio
- Radio Go Green
- Radio Victrola
- Radio Linn
- Radio Numan
- Radio Elta
- Radio Iluv
- Radio Monitor Audio
- Radio TELEX
- Radio Multiplex
- Radio Tangent
- Radio SPC
- Radio Stabo
- Radio Clint
- Radio Soundstream
- Radio Xoro
- Radio Sagemcom
- Radio Woxter
- Radio Xhdata
- Radio Monacor
- Radio Noxon
- Radio Orava
- Radio Geneva
- Radio Ferguson
- Radio Wet Sounds
- Radio DAP Audio
- Radio Reflexion
- Radio Duronic
- Radio Scansonic
- Radio TFA Dostmann
- Radio Audisse
- Radio ETON
- Radio Lenoxx
- Radio H-Tronic
- Radio Equity
- Radio Intertechno
- Radio Schwaiger
- Radio EKO
- Radio Pinell
- Radio Aquatic AV
- Radio Digitalbox
- Radio Ruark Audio
- Radio NUVO
- Radio Narex
- Radio Tiny Audio
- Radio Klein Tools
- Radio E-bench
- Radio Peha
- Radio Sanwa
- Radio Sailor
- Radio SSV Works
- Radio Microlab
- Radio QFX
- Radio Voxx
- Radio SACK It
- Radio BasicXL
- Radio Roth
- Radio Majestic
- Radio Ices Electronics
- Radio AmpliVox
- Radio Memphis Audio
- Radio AMX
- Radio Elbe
- Radio GBS Elettronica
- Radio Sang
- Radio Gewiss
- Radio Lutron
- Radio Axxess
- Radio Majority
- Radio Retekess
- Radio Wintal
- Radio Acoustic Solutions
- Radio Atlantis Land
- Radio Ranger
- Radio BLUEPALM
- Radio Weather X
- Radio Data-Tronix
- Radio Aconatic
- Radio Mebby
- Radio Yamazen
Nyaste Radio Manualer
27 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
23 Oktober 2024
22 Oktober 2024
20 Oktober 2024
19 Oktober 2024
18 Oktober 2024
