Austrian Audio MiCreator Studio Bruksanvisning
Austrian Audio
mikrofon
MiCreator Studio
Läs nedan 📖 manual på svenska för Austrian Audio MiCreator Studio (21 sidor) i kategorin mikrofon. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/21
User Manual
Introduction
MiCreator is a microphone system consisting of several microphones and accessories. Depending on
the application, you only need the main microphone, MiCreator Studio, or you can combine a
plurality of system MiCreator is also available as a devices to expand your application scenarios.
system set, in which you get MiCreator Studio and MiCreator Satellite including all necessary cables
combined in a practical case.
Since this is a manual for the entire system, you will find the appropriate section for your device(s) in
the table of contents.
Please read, comprehend and follow all instructions in this guide before using these devices.
• Please use these devices only for their intended purposes. Austrian Audio shall not assume
any liability for damage resulting from improper handling or misuse.
• Wearing headphones at full volume for long periods of time can damage your hearing.
• If a fault occurs, please stop using the devices.
• Always store the equipment in a dry and safe place.
• Do not operate the equipment outside the intended operating temperature range of 0 °C to
45 °C (32 °F – 113 °F).
• Do not use the devices in a damp or wet environment.
• Please do not drop.
• These devices are professional microphones; keep them away from small children.
• If you need to clean the devices, please use a soft, dry cloth.
• Do not use third-party accessories unless otherwise noted.
• Do not disassemble the devices, as there are no user serviceable parts inside.-
• The devices (MiCreator Studio + MiCreator Satellite) contain magnets for the
interchangeable cover plates.
Thank you very much for reading the notes so far and, of course, for placing your trust in Austrian
Audio.
Table of Contents
MiCreator Studio ..................................................................................................................................... 3
Controls and connections .................................................................................................................... 3
Switching on and off ............................................................................................................................ 3
Positioning and alignment ................................................................................................................... 4
Establishing the USB-C® connection.................................................................................................... 4
Plugging in headphones and starting up ............................................................................................. 5
Setting the monitoring (volume of the microphone signal in the headphones) 5 ................................
Adjusting the microphone gain ........................................................................................................... 6
Connecting other devices and adjusting the input gain ...................................................................... 6
Additional input gain for signal transmission via the USB- C® connection .......................................... 8
Interchangeable cover plate.............................................................................................................. 10
Transport of the MiCreator Studio .................................................................................................... 10
Technical specifications ..................................................................................................................... 11
MiCreator Satellite ................................................................................................................................ 12
Connections ....................................................................................................................................... 12
Positioning and alignment ................................................................................................................. 12
Plugging in headphones and starting up ........................................................................................... 13
Adjusting microphone and headphone gain ..................................................................................... 13
Interchangeable cover plate.............................................................................................................. 14
Transport of the MiCreator Satellite ................................................................................................. 14
Technical specifications ..................................................................................................................... 15
- MiCreator Y Lav .................................................................................................................................... 16
Positioning and alignment ................................................................................................................. 16
Plugging in headphones and starting up ........................................................................................... 16
Adjusting the microphone gain ......................................................................................................... 16
Transport of the MiCreator Y- Lav...................................................................................................... 17
Technical specifications ..................................................................................................................... 18
Troubleshooting .................................................................................................................................... 19
MiCreator Studio ............................................................................................................................... 19
MiCreator Satellite ............................................................................................................................ 19
MiCreator Y- Lav................................................................................................................................. 19
Legal information .................................................................................................................................. 20
MiCreator Studio
MiCreator -Studio is a studio microphone with USB C® connection to the partner device (such as
computer, tablet, mobile phone, etc.).
In addition to a primary headphone output, MiCreator Studio has another jack that can be used both
as a second headphone output o connect the included instrument cable to record two signals or t
simultaneously.
Alternatively, MiCreator Satellite or MiCreator Y-Lav can be connected to this socket see the –
corresponding sections for more information.
Note: The microphone can also be powered by a USB power adapter (not included) and used as an
analogue microphone.
Controls and connections
Switching on and off
The device does not have an on/off switch but starts automatically as soon as it is powered by the
USB-C® socket (5V, 250mA). When starting, a red light animation is briefly visible on the LED bar. The
LED bar then switches to volume mode (green).
Produktspecifikationer
| Varumärke: | Austrian Audio |
| Kategori: | mikrofon |
| Modell: | MiCreator Studio |
