Thank you for purchasing your panel ready undercounter wine or beverage refrigerator from Avallon. Our brand set out with one parcular
goal: To present appliances that are as reliable and recognizable as they are aainable. We create products that invite enre kitchens to be
built around them, serving as an establishing feature in the very spaces they occupy.
In accordance with our ongoing mission to provide cung-edge and forward-thinking products to our loyal customers, we recently
introduced a line of panel ready appliances. These models are fully customizable, and in just a few short steps, you can match your
undercounter refrigerator with your adjacent cabinetry.
This document serves as a guide for installing custom door panels on any of these models. For more product informaon, including owner's
manuals, dimension guides, and more, visit Avallon.com.
P R O D U C T I N F O R M AT I O N
PA N E L I N S TA L L AT I O N I N S T R U C T I O N S
O V E R L AY PA N E L I N S TA L L AT I O N I N S T R U C T I O N S
T O O L S R EQ U I R E D
• Phillips Screwdriver • Drill and 7/64" Drill Bit • #6 Wood Screws* • Clamps (Recommended)
I M P O R TA N T
Warning: The weight of the overlay panel should not exceed 15 lbs.
N O T E
*Because the sizes of overlay panels vary, hardware for mounng your overlay is not included with your Avallon panel
ready refrigerator. #6 wood screws are recommended. The required length depends on the thickness of your overlay
panel. Take care to ensure the screws are not too long to avoid them protruding though the overlay panel.
1. Open the door to a 90° angle.
2. Use a Phillips screwdriver to remove the two (2) screws from the top hinge.
3. Remove the door by carefully sliding the top of the door forward while liing the door up and out of the boom hinge assembly.
2
AVALLON.COM
®
©2022 Ferguson Enterprises, LLC V1.0-08122022
4. Lay the door on a solid surface with the glass panel or door front facing downward. We recommend placing the door on a moving
blanket, sheet of cardboard, or other so material before proceeding.
5. Peel away and remove the door gasket from the inside of the door frame as shown below. We recommend starng at one corner and
gently pulling to avoid tearing the gasket. Set the gasket aside in a safe locaon.
6. Place the door (with the glass panel or door front facing downward) on top of the overlay panel as shown below. Align the top edge of
the overlay panel with the top edge of the door frame. We recommend clamping the two pieces together before proceeding to prevent
movement and misalignment.
Door Overlay
Avallon Door
7. Drill pilot holes into your overlay panel using the screw hole openings in the Avallon door for exact placement.
8. Use #6 wood screws of the correct length to secure the overlay panel to the door. The length of screw depends on the thickness of your
overlay panel. Take care to ensure the screws are not too long to avoid them protruding though the overlay panel.
9. Your Avallon refrigerator comes with a standard towel bar handle. If you choose to install this handle, do so using the designated holes in
the door. Hole posioning is shown on the Screw Placement diagrams on the following pages.
10. Replace the door gasket by lining the backside of the gasket up with the track in the top of the door. Press the gasket into the track when
properly aligned and work the gasket into the track all the way around the door.
11. Reinstall the door by placing the lower hinge pin into the lower hinge assembly then securing the two (2) Phillips screws to the upper
hinge axis.
3
AVALLON.COM
®
©2022 Ferguson Enterprises, LLC V1.0-08122022
D O O R D I M E N S I O N S F O R 1 5" M O D E L S
2-1/2”
(65mm)
2-1/2”
(65mm)
14-3/4” (374mm)
29-5/8” (752.5mm)
I M P O R TA N T
Warning: The images below are for reference only. Due to manufacturing tolerances, the locaon of the bores in the door
for screw placement may vary slightly. We strongly recommend having the Avallon unit on-site prior to drilling pilot holes
in the overlay panel.
MODELS: ABR152PRGLH, ABR152PRGRH, AWC152SPRGLH, AWC152SPRGRH, AWC152DPRGLH, AWC152DPRGRH,
ABR152PRSLH, ABR152PRSRH, AWC152SPRSLH, AWC152SPRSRH, AWC152DPRSLH, AWC152DPRSRH
