MODEL HRS88N1B
SECURITY SAFE
INSTALLATION AND USAGE INSTRUCTIONS
Your Avanti Room Security Safe is supplied with the following:
1 – Security Safe Unit
2 – Emergency Access Keys
1 – Installation / Usage Guide
4 – 1.5V Batteries
1 – Felt Liner
Installation Screws
4 – Rubber Feet
INSTALLING YOUR SECURITY SAFE
When installing your safe, be sure the location is sturdy enough to support the unit and is both
secure and easy to access.
Safe can be installed onto either a concrete or wooden surface.
When installing use a 25/64” (10mm) drill bit and screws.
To prevent removal of your security safe, it is recommended to use Allen type screws (not included)
to affix the unit to the installation location.
INITIAL SETUP AND CONFIGURATION.
After you have installed the unit in its final location, proceed to set up digital access controls.
1) Using the emergency Access Key, open the safe.
2) Open the battery compartment cover.
3) Following the image shown in the battery compartment install 4 AA sized batteries.
4) Close the battery compartment cover.
5) The words “ALL READY” will be displayed on the LCD display for approximately 1 second; the
security safe will then go into “STANDBY Mode”.
6) Once in “STANDBY Mode” the LCD display will show the date and time (YY, MM, DD).
7) Using the keypad, enter the initial setup password “1234” or the administrator password
“8888”.
NOTE:
Battery Life / Level indicator The battery indicator on the LCD display will show the current status :
of the batteries. Always replace all of the batteries at the same time. If at any time the battery level
is too low to operate the security safe, use the emergency access key.
Safety / Security Feature: If the passcode is entered incorrectly more than 3 times the keypad will
go into lock mode. After approximately (5) five minutes the keypad will return to normal working
function.
Interior Light: When the safe is unlocked using the keypad, the interior light will turn on and will
turn off automatically after approximately 45 seconds.
Automatic Door Opening: When the safe is unlocked using the keypad the door will automatically
open slightly outward to allow easy / quick access to contents stored in the safe.
RESE TTING THE ADMINISTRATOR PASSWORD
To reset the access code read and follow the steps below.
1) With the door open, press the “#” key to activate the keypad, then press the “0” key twice, then
press the “red” button on the battery compartment once to enter the programming mode.
2) Once in the programming mode you will hear a “DI” sound and “- - - -“ will be shown in the LCD
display.
3) Enter the new 4 – 8 administrator password and press the “#” key to confirm.
4) The word “INTO” will show on the LCD display to confirm the new password has been set
successfully.
GUEST / USER CODE SETUP
To reset the access code read and follow the steps below.
1) With the door open, enter a new 4 – 8 digit code and press the “#” key to confirm the new pass code.
2) You will hear and see the security lock engage and the word “CLOSE” will be displayed on the LCD
screen.
3) Enter the new pass code and press the “#” key again to open the security safe. The security lock will
disengage and the word “OPEN” will be displayed on the LCD screen.
4) Close the door and enter the new code set up in step # 1 and press the “#” key. The word “CLOSE”
will be displayed on the LCD screen and the security lock will engage.
5) If the Guest / User enters the wrong pass code three (3) times in a row the keypad will go into
security-lock mode and will remain locked for approximately (5) five minutes. After the (5) five
minutes has elapsed the keypad will return to normal operation.
Avanti Products
Miami, FL 33172
In the event of service issues, please call the
Customer Hotline at 1-800 220 5570– -
Additional Instructions:
Manual Operation (Open using the key).
• User will need to remove the key hole cover by placing a small pin or similar object in the hole below the
keyhole and key hole cover.
• Insert the emergency access key into the lock and turn clockwise to open the safe.
• While the door is open, change the batteries on the control panel or reset the passcode as described in the
“Resetting the Administrator Password” section.
Setting the Date, Time and Weekday:
• After the batteries have been installed, the LCD display will show “00-01 Month-01” (Year- -Date) and “Week
1” (Monday) “00- 00” (Time).
• Press the “*” to enter the programming mode, the “00” will begin to flash.
• Increase by pressing the “ 8 “ or Decrease by pressing the “ 0 “, when finished press the “#” to move to the
next item.
When finished programming, do not touch any key for approximately 7 seconds and the program will take
effect.
Tips:
For your convenience four (4) rubber feet are included with each safe and can be installed if needed.
Rubber Feet
Avanti Products
Miami, FL 33172
In the event of service issues, please call the
Customer Hotline at 1-800 220 5570– -
