www.avsl.com 500.210UK
Full HD USB Webcam
with Microphone
Item ref: 500.210UK
User Manual
A full HD USB webcam that delivers on all levels, providing both crystal clear images and high-quality audio at a price that won t hurt ’
your pocket. The 2 Megapixel sensor refreshes at 30fps to produce stunning colour and detail and the 95° viewing angle generates a
natural 16:9 widescreen ratio. The 1.5m, USB lead provides simple plug and play connection and the versatile fixing clip offers
flexibility for both monitor mounting or freestanding on your work surface. Suitable for a wide range of communication applications
and compatible with most Microsoft and MAC operating systems, this compact, well-made webcam is a perfect addition for your home
or office environment.
• Produces crystal clear, FHD images at 1080p resolution
• Built in microphone for crisp, clean audio
• 2.0MP sensor delivers stunning clarity and detail at 30fps
• 95° viewing angle provides true 16:9 screen ratio
• Simple plug and play connection via USB2.0
• Flexible fixing clip for monitor mounting or freestanding on a work surface
• Ideal for use with communication apps such as Microsoft Teams, Zoom, Skype, Cisco Webex, Google Meet and more
Technical Specifications:
Max resolution
1920 x 1080p
Frame rate
30 FPS
Sensor
2.0 Me pixel ga
Viewing angle
95°
Compatible O/S
Windows XP2, Vista, Win7, Win8, Win10, MAC OS
Lead length
1.5m
Dimensions
85 x 58 x 60mm
Weight
122g
Operation guide:
The AV:Link USB Webcam is a plug and play device. connect to your PC or laptop simply insert the USB2.0 adaptor to a vacant To in
USB port and wait for the O/S to install the default drivers. Once this is complete you ll receive a notification from your O/S and the wi
red power light on the camera will be lit. In Microsoft Windows to check the camera and microphone are connected and working
correctly please follow the steps below. These steps are also needed if your PC or laptop has another camera, in which case you will
need to select the correct one in the system settings. Position your camera securely either on the top of your monitor or notebook
screen or on the desktop rface using the adjustable fixing bracket. For additional grip remember to remove the protective plastic film su
from the rubber surfaces on the inside of the bracket.
www.avsl.com 500.210UK
Checking Connections in Windows : 10
1. In the Windows search box which is in the ,
bottom left-hand corner of your desktop type
“ ”device manager and select the icon.
2. To check the camera settings, open the
Camera section and check that the option
selected is UVC Camera (see image). “ ”
3. If you have any issues with the video quality,
you can update the driver by right clicking and
selecting update driver . “ ”
4. To check the microphone settings, open the
Audio inputs and outputs section and check
that the option selected is pture Input “Ca
Terminal (2-AC Interface) (see image). ”
5. If you have issues with the sound you can
always update the driver by right clicking and
selecting update driver “ ”
6. If you open the device manager and don’t see
the UVC camera present, try unplugging the
camera and inserting in another vacant USB
port.
NOTE: If you are using an older version of Windows or alternative O/S you may need to manually install software for the web camera.
This can be found at https://potplayer.en.softonic.com/
Testing and adjusting the camera in Windows 10:
Open the Camera app in Windows 10 by typing camera in the search box and selecting the Camera app icon. Once opened image “ ” an
should be visible on the screen and the green video light on the camera should be lit Next adjust the position of camera so that . the
your target image is positioned centrally. It may also be necessary to adjust the focus if the lens has been moved during the shippi ng
process. The focus can be adjusted by carefully turning the silver bezel around the lens clockwise or anti-clockwise.
In the B ox:
1pc USB HD Webcam
1pc User manual
FAQ
Q) A) Why is there no image when connected to the webcam? Check that both the red power light and green video lights are If lit.
one or both are out, unplug the camera and try again in the same or an alternative USB port.
Q) y is the image on my screen not the image I expected from the webcam Maybe your devic s another webcam Wh ? A) e ha
connected?! G the device mana r i control panel and ensure that UVC camera is selected in the Camera section. o to ge n “ ”
Q) Why is there no sound being received from my webcam? A) Go to the device manager i control panel and ensure that Capture n “
Input Terminal is selected in the Audio inputs and outputs section. ”
Safety Disclaimer
Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock or equipment damage and
will also invalidate the warranty. This product is only designed for indoor e and must be kept away from water and high humidity along us
with high temperatures and direct sunlight.
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its
useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 21 AVSL Group Ltd Unit 2 Bridgewater Park, AVSL (Europe) d, Unit 3D North Point House,20 , Lt
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
