www.avsl.com 100.596UK
Bluetooth 2- - Transmitter & Receiver in 1
BTTR2
Item ref: UK 100.596
User Manual
An amazing and compact Bluetooth device that will open a new world of wireless audio enjoyment both at home or on
the move. Simply connect using the audio cable provided to your TV, projector or other audio device and stream
wirelessly to Bluetooth headphones, speakers or sound-bars. Alternatively connect to a set of traditional headphones,
amplifier or in-car entertainment system and you can then pair with your smartphone, tablet or other Bluetooth devices.
With Multi-point support for shared listening, a 10m transmission/reception range and in-built rechargeable battery
providing up to 8 hours playback from a single charge, this handy little device really is your perfect Bluetooth partner!
• Make any device with a 3.5mm or RCA audio connection Bluetooth compatible
• Improved design that's compact and easier to use
• Transmitter will connect Bluetooth headphones, speakers or sound-bars to LED TV's and projectors
• Receiver will connect smartphones, tablets and MP3 players to headphones, amplifiers or car audio systems
• Multi-point Bluetooth capability allows you to connect to 2 devices at the same time, ideal for shared listening
• Wireless Bluetooth range of up to 10m
• Transmits audio for up to 8 hours on a single charge
• Receives audio for up to 6 hours on a single charge
Technical Specifications
Bluetooth version
v4.2 with multipoint support
Bluetooth profile
APTX, A2DP, AVRCP
Bluetooth range
Up to 10m (in clear line of sight)
Operating time
Up to 8 hours (transmit), 6 hours (receive)
Charge time
2 hours
Battery
2 00mAh
Dimensions
42 x 42 x 10mm
Weight
20g
Overview
Powering on/off:
Press and hold the Multifunction button (2) il the LED light ) unt (3
goes blue. To power off, press and hold the Mulitifunction button
again until the LED light goes red, indicating the unit is power down
mode.
Pairing with your device in Transmission mode:
Insert the 3.5mm audio lead provided into the input/output socket
(1) on the back of the unit and the other end into the piece of
equipment you wish to send the audio from (i.e the headphone
socket on a TV, projector, stereo system or MP3 player). Set the
TX/RX switch to transmitter mode (5) and press and hold the
Multifunction button until the LED blinks blue quickly, this is to
indicate the unit is now in Bluetooth transmission pairing mode. Set
your Bluetooth headphones, speakers or sound-bar to pairing mode
and wait for the devices to connect. Please be aware that due to the
different protocols of some devices the connection time can be a few
minutes. If after this time you are still unsuccessful, turn off both
devices and try again. Once connected successfully, a voice message
can be heard and the LED on the unit blinks blue intermittently.
www.avsl.com 100.596UK
Pairing with your device in receiving mode:
Insert the jack from a set of wired headphones or alternatively the 3.5mm audio lead provided, into the put/output in
socket on the back of the unit and other end into the piece of equipment you wish to send the Bluetooth audio to (i.e
stereo systems, amplifiers or car audio systems). Set the TX/RX switch to receive mode (6 and press and hold the )
Multifunction button until the LED blinks red and blue alternately, this is to indicate the unit is now in Bluetooth receiving
pairing mode. When searching for the device in a list on a PC, smartphone or tablet, the pairing name is AV:Link BTTR2
and if your device asks for a pairing code the default setting is 0000. Once connected successfully, a voice message can
be heard and the LED on the unit blinks blue intermittently. You can now play the audio from your PC, smartphone or
tablet wirelessly to the device you are connected to.
Pairing a second device in transmission or receiving mode:
This unit also has multi-point support, meaning it can connect to 2 Bluetooth devices at the same time. To pair a second
device, press the Multifunction button again after the initial pairing is successful and the red light will blink. Once pairing
is successful on a second device, both the red and blue lights will blink intermittently. Using this feature, you can either
share your listening transmission mode or listen to two devices alternately in receiving mod in e.
Charging the device:
To charge the device only use the USB cable supplied and ensure you charge fully on first use Whilst charging a red LED .
will stay on, which will turn blue when the unit is charged. Charging time is normally around 2 hours from flat and the
device will last up to 8 hours from a single charge. keep the device constantly charged using a USB port It’s possible to
on a TV or PC/Laptop and leave it connected when not in use. This means the unit will only be charging when the TV, PC
or la n needed. ptop is switched on and shouldn’t run out of power whe
Connecting to Audio Equipment:
You can connect the unit to any audio device with a 3.5mm input or output using the stereo connection lead supplied or
to devices with twin RCA inputs or outputs, with the RCA adaptor cable a supplied. lso
In the B ox:
1pc Bluetooth transmitter/receiver unit
1pc 3.5mm audio cable
1pc RCA adaptor cable
1pc USB charging cable
1pc User manual
FAQ
Q) A) Bluetooth unit cannot pair with your device. Check that the unit n pairing mode and that the Bluetooth mode is is i
enabled on your device and in scan mode. If after a few minutes you are still unsuccessful, turn off both devices and try
again. If possible, place the 2 devices closer together and ensure they are in clear line of sight until paired.
Q) A) Bluetooth unit sconnects with my device well within the stated 10 transmission distance. di m The maximum
transmission distance stated is dependent on clear line of sight between the unit and your device. If there are large a
metallic objects or other devices transmitting radio or wireless signals in the vicinity, they can impact on the reception of
the unit.
Q) Bluetooth unit won t switch on. Check that the unit is charged sufficiently before operation. ’A)
Safety Disclaimer
Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock or equipment damage and
will also invalidate the warranty. This product is only designed for indoor use and must be kept away from water and high humidity along
with high temperatures and direct sunlight.
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its
useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted.
Copyright© 8. AVSL Group Ltd. 201
