www.avsl.com 128.8 User Manual 49UK

4K HDMI 2.0 Matrix 4x2

Item ref: 8128. 49UK

User Manual

A 4K HDMI matrix to switch between 4 source devices and 2 display outputs. Use with HDMI cables of a combined 30m

per input/output for 4K@30Hz and FHD resolutions, or a combined 10m per input/output for 4K@ 60Hz. SPDIF and

3.5mm stereo outputs allow the audio signal for each source device to be simultaneously channel through a separate ed

sound system and/or headphones. Compatible with the latest 4K digital TV boxes making it ideal for hospitality a nd

entertainment venues. Supplied with IR remote to switch between sources for both outputs.

Technical specifications:

HDMI version

2.0b

Video resolution

Up to 3840 x 2160 @ 60Hz

Display colours

8/10/12bit deep colour

Audio format

DTS-HD, Dolby True, S, Dolby-AC3 and DSD DT

Input connections

4x HDMI

Output connections

2x HDMI, 2x Optical (Toslink), 2x 3.5mm Stereo

Max. bandwidth

600 MHz

Max. baud rate

3x 6Gbps

Transmission distance

30m max HD or 10m max 4K (20m input/output @ 1080p and 10m input/ou ut @ 4K) tp

Max. working current

600mA

Power adaptor

Input: AC (50Hz, 60Hz) 100-240V, Output: DC5V/1A

Dimensions

99 x 70 x 27mm

Weight

300g

Application diagram:

Connection instructions:

• Connect the outputs of up to 4 source devices to the inputs of th matrix ( ). Use HDMI cables of up to 15m per e 2

d ice for 4K@30Hz or FHD signals or 5m per device for 4K@60Hz signals ( to maintain 4K resolution, always ev NOTE:

use 4K certified cables).

• Connect the outputs of th matrix ( to the inputs of up to 2 display devices. U HDMI cables of up to 15m per e 1) se

output for 4K@30Hz or FHD signals or 5m per o put for 4K@60Hz signal ut s.

www.avsl.com 128.8 User Manual 49UK

• Connect the 5V power adaptor (supplied) to the matrix ( ); plug into a mains outlet and power on. 4

• Use Key1 and Key2 buttons ( on the ont of the unit or the IR remote control (supplied) to switch between 8,9) fr

source devices for both output displays.

• To channel audio from the source devices to separate sound systems, amplifie or headphones use the digital 2 rs

SPDIF ( or analogue 3.5mm jacks ( on the side of the unit (additional cables required, not supplied). 10) 11)

1. HDMI output 1-2

2. HDMI input 1-4

3. EDID management switches

4. DC/5V power in

5. Power LED

6. IR remote sensor

7. HDMI input LED s ’

8. Key2 switching button

9. Key1 switching button

10. Optical outputs 1-2

11. 3.5mm s eo outputs 1-2 ter

EDID management settings (3):

NOTE: EDID switch upward = 0,

ID switch downwards ED =1

In the b : ox

1. HDMI Matrix 4x2

2. IR Remote Control

3. 5V DC Power Adaptor

4. User Manual

Warning:

• For reasons of electrical safe , this de ce must never be immersed in water, exposed to damp conditions or ty vi

excessive force.

• Do not use this device if you find that it is damaged in any way.

• Only use the power supply provided by the manufacturer.

• When not in use for long periods, dis nnect the power supply from the mains. co

• Do not attempt to repair this device or take apart under any circumstances, as this will invalidate your warranty.

This product is classed as Electrical or Electronic equipment and should not be dispo ith other house ld or commercial waste at the end of its sed w ho

useful life. The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.
