128.835 User Manual UK

4K HDMI Switch / Splitter 2x4

Item ref: 8128. 35UK

User Manual

A 4K HDMI splitter to switch between 2 source devices, with up to 4 display outputs. Use with HDMI cables of

a combined 20m per output for HD resolution, or a combined 10m per output for 4K resolution, without signal

loss. SPDIF and 3.5mm jack outputs allow the audio signal of the selected source device to simultaneously be

channeled through a separate sound system; ideal for hospitality and entertainment venues. Supplied with IR

remote to switch between sources.

• Simple connection and installation

• Gold plated HDMI connectors for optimum signal transfer

• Supports HDMI v2.0a resolutions up to 3840 x 2160 @ 60Hz

• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats

• Digital SPDIF and analogue 3.5mm jack audio outputs

• Ideal for entertainment, hospitality and other commercial venues requiring multiple display feeds from a

single HDMI source

• IR Remote and UK power adaptor supplied

Technical Specifications and Features

HDMI Version

2.0a

Video Resolution

Up to 3840 x 2160 @ 60Hz

Display Colours

8/10/12bit deep colour

Audio Format

DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD

Max. Bandwidth

600 MHz

Max. Baud Rate

6Gbps

Transmission Distance

20m max HD or 10m max 4K (20m input/output @ 1080p and 10m input/output

@ 4K)

Max. Working Current

500mA

Dimensions

200 x 70 x 25mm

Weight

305g

Back/Front View

128.835 User Manual UK

Connection Instructions

• Connect the outputs of the source devices to the inputs of the splitter. Use HDMI cables of up to 10m per

d ice for HD signal or 5m per device for 4K signal (NB: to maintain 4K resolution, always use 4K certified ev .

cables)

• Connect the outputs of the splitter to the inputs of the display devices. U HDMI cables of up to 10m per se

output for HD signal or 5m per o put for 4K signal. (NB: to maintain 4K resolution, always use 4K ut

certified cables).

• Connect the 5V power adaptor (supplied) to the splitter; plug into a mains outlet and power on.

• Green LEDs on front of the splitter will illuminate when the source and di lay devices are connected and sp

switched on.

• Use the ‘select’ button on the front of the splitter or the IR remote control (supplied) to switch between

source devices.

• To channel audio from the source devices to a separate sound system or amplifier, use e her the digital it

SPDIF or analogue 3.5mm jack on the side of the unit (additional cables required, not supplied).

In The Box

1. HDMI Switch / Splitter 2x4

2. IR Remote Control

3. 5V DC Power Adaptor

4. User Manual

Warning

• For reasons of electrical safety, this de ce must never be immersed in water, exposed to damp conditions vi

or excessive force.

• Do not use this device if you find that it is damaged in any way.

• Only use the power supply provided by the manufacturer.

• When not in use for long periods, disconnect the power supply from the mains.

• Do not attempt to repair this device or take apart under any circumstances, as this will invalidate your

warranty.

This product is classed as Electrical or Electronic equipment and should not be disposed with other house ld or commercial waste at the end of its ho

useful life. The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.

Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
