METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
INSTALLATION INSTRUCTIONS FOR PART INSTGMOS-08
REV. 12/21/11
CuttingTool•CrimpingTool•Tape•Connectors(example:butt-connectors,bellcaps,etc.
IGNITIONTERMINALS
WIRECUTTER
M 3.5
M 2.6
M 3
M 5
M 4
IS O
6
2.5
1.5
TOOLS REQUIRED
GM amplified OnStar Class II Data Bus
Interface 2005-2006
•GMOS-08interface•16-pinharnesswithstrippedleads
•18-pinharnessto12-and24-pinGMharnesswithstrippedleads
INTERFACE COMPONENTS
KIT FEATURES
APPLICATIONS
• Providesaccessory(12-volt10-amp)
• RetainsR.A.P.(RetainedAccessoryPower)
• Usedinamplifiedsystems
• Retainschimes
• ProvidesNAVoutputs(parkingbrake,reverse,mute,V.S.S.)
• ASWCharnessincluded(ASWCnotincluded)
• RetainsOnStar/OEBluetooth
• AdjustablevolumeforchimesandOnStar
• Highlevelspeakerinput
• USBupdatable
• Retainsbalanceandfade
See inside front cover
Applications
GMOS-08
Caution: Metra recommends disconnecting the negative battery terminal before beginning
any installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*NOTE: Refer also to the instructions included with the aftermarket radio.
CHEVROLET
Equinox 2005-2006
PONTIAC
Torrent 2006
(Note: This interface will also work in vehicles listed below that are not equipped with OnStar)
From the 16-pin harness:
• Connectthe wiretotheignitionwireoftheaftermarketradioRed
• Connectthe wiretotheilluminationwireoftheaftermarketradio.IftheOrange/White
aftermarketradiohasnoilluminationwirejusttapeoffthe wire.Orange/White
• Connectthe wiretotheleftfrontpositivespeakeroutputoftheaftermarketradioWhite
• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black
aftermarketradio
• Connectthe wiretotherightfrontpositivespeakeroutputoftheaftermarketradioGray
• Connectthe wiretotherightfrontnegativespeakeroutputoftheGray/Black
aftermarketradio
• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green
• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black
• Connectthe wiretotheradio’srightrearpositivespeakeroutput.Purple
• Connectthe wiretotheradio’srightrearnegativespeakeroutput.Purple/Black
• Connectthe wiretotheradio’sampturnonwireBlue/White
• Connectthe wiretothemutewireoftheaftermarketradio.IftheaftermarketBrown
radiodoesnothaveaMutewire,tapeupthe wire.Brown
• Connectthe wiretotheparkingbrakewireoftheaftermarketLight Green
navigationradio.
• Connectthe wiretotheVSSorspeedsensewireoftheaftermarketBlue/Pink
navigationradio.
• Connectthe wiretothereversewireoftheaftermarketnavigationradio.Green/Purple
• Plugthe16-pinharnessintotheGMOS-08
Connections to be made
