Sida 1/8
GM ONSTAR LAN DATA BUS INTERFACE
GMOS-LAN-01
Installation Instructions
1-800-221-0932
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION Rev. 12-1-10
www.axxessinterface.com
APPLICATIONS
Not compatible with amplified sound systems
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
The is GMOS-LAN-01
designed to retain Onstar and retain the warning
chimes that are normally lost when the OEM radio is removed. It
also provides a 12 volt accessory output for proper aftermarket
radio operation. THE GMOS-LAN-01 also PROVIDES a MUTE,
PARKING BRAKE, VSS OR SPEED SENSE, AND A REVERSE OUT-
PUT TO MAKE INSTALLING AN AFTERMARKET NAVIGATIONAL
RADIO SIMPLER AND LESS TIME CONSUMING.
Buick
• Enclave 2007-11
• Lucerne 2006-10
Cadillac
• DTS 2006-10
• SRX 2007-09
Chevrolet
• Avalanche 2007-10
• Aveo 2009-10 *
• Equinox 2007-09
• Express 2008-10
• Impala 2006-10
• Monte Carlo 2006-07
• Silverado (new body)
2007-11
• Suburban 2007-10
• Tahoe 2007-11
• Traverse 2009-11
GMC
•Acadia 2007-11
•Savanna 2008-10
•Sierra (New body) 2007-11
•Yukon / XL 2007-10
Hummer
•H2 2008-09
Pontiac
•Torrent 2007-09
• Vibe 2010 *
*( Only required for retention of Onstar-
NAV outputs not applicable)
Saturn
•Outlook 2007-09
•Vue 2008-09
Suzuki
•XL-7 2007-09
INTERFACE COMPONENTS
• GMOS-LAN-01 Interface
• 14 pin harness with stripped leads
• 12 pin to 30 pin GM harness
GMOS-LAN-01
1
* READ IMPORTANT WARNING
BEFORE ATTEMPTING ANY INSTALLATION
* IMPORTANT WARNING
THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH
MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED IN
SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE OF COM-
PLETING THESE TYPE OF ELECTRONIC INSTALLATIONS. IF YOU ARE
UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR BELIEVE THAT
YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS TO PROPERLY AND
SAFELY COMPLETE THE INSTALLATION YOU SHOULD CONSULT A TECHNI-
CIAN WHO DOES HAVE THIS KNOWLEDGE AND UNDERSTANDING.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAREFULLY AND TO
INSTALL THE INTERFACE AS DESCRIBED COULD CAUSE HARM TO THE
VEHICLE OR TO SAFETY SYSTEMS ON THE VEHICLE. INTERFERENCE
WITH CERTAIN SAFETY SYSTEMS COULD CAUSE HARM TO PERSONS
AS WELL.
IF YOU HAVE ANY QUESTIONS IN THIS REGARD PLEASE CALL THE
METRA HELP LINE AT: 1-800-221-0932 FOR ASSISTANCE.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
towa a better tomorrord w.
We recommend MESA
certified technicians
We recommend MECP
certified technicians
GMOS-LAN-01
2
TOOLS REQUIRED FOR INSTALLATION
INSTALLING THE INTERFACE
* Important: Before beginning any of the following, disconnect the negative battery terminal to prevent acci-
dental short circuit.
FOR INSTALLATION OF AFTERMARKET RADIO ONLY:
From the 14 pin harness:
1.
Connect the wire to the ignition/accessory wire of the aftermarket radio.red
2.
Connect the wire to the illumination wire of the aftermarket radio. If the aftermarket orange
radio has no illumination wire just tape off the wire.orange
3.
Connect the wire to the amp turn on wire of the aftermarket radio.Blue/white
4.
Connect the wire to the left front positive speaker output of the aftermarket radio.white
5. white/black Connect the wire to the left front negative speaker output of the aftermarket radio.
6. grayConnect the wire to the right front positive speaker output of the aftermarket radio.
7. gray/black . Connect the wire to the right front negative speaker output of the aftermarket radio
8. brown Connect the wire to the mute wire of the aftermarket radio. If the after market radio does not have
a Mute wire, tape up the wire.brown
The following wires on the 14 pin harness are for the aftermarket radios that have navigation built in:
1. green Connect the wire to the parking brake wire of the aftermarket navigation radio.
2. blue/pink Connect the wire to the VSS or speed sense wire of the aftermarket navigation radio.
3. green/purple Connect the wire to the reverse wire of the aftermarket navigation radio.
From the 12 pin harness:
1.
Connect theYellow wire to the 12 volt constant/battery wire of the aftermarket radio.
2.
Connect the wire to the ground wire of the aftermarket radio.Black
3.
The Black/Yellow Black/Whiteand wires will be discussed later in this manual.
From the 30 pin GM harness:
1.
Connect the wire to the left rear positive speaker output of the aftermarket radio.Green
2.
Connect the wire to the left rear negative speaker output of the aftermarket radio.Green/Black
3.
Connect the wire to the right rear positive speaker output of the after-market radio.Purple
4. Connect the wire to the right rear negative output of the aftermarket radio.Purple/Black
• Cutting Tool Tape Crimping Tool • Connectors (ie: butt-connectors, bell caps, etc.)
(See wiring diagram 1 on page 3
