www.btechavmounts.com
B-TE AV mo sCH unt
BT4001
MEDIUM floor base
use with A BT8381 COLUMN OR A bt4116 / bt4118 pole
PARTS LIST
ITEM DESCRIPTION QTY
1
FLOOR BASE
1
1
**
*Note: Max weight also dependent on the height of the installed mount - see page 2 for more details
COLUMN POLE
2
MAXIMUM LOADS
INSTALLATION SAFETY INSTRUCTIONS
B-Tech AV Mounts, it’s distributors and dealers are not responsible for damage or injury caused by improper installation,
improper use, modications, installations over the specied weight capacity and/or failure to observe these safety
instructions. In such cases, any warranty will expire.
It is recommended that this product should only be installed by a qualied professional / installer.
B-Tech AV Mounts does not claim any liability for any diculties that may arise from the interpretation contained
in these instructions. Failure to mount this product correctly may lead to serious injury and/or death.
Please check carefully to make sure there are no missing or defective parts - defective parts must never be used.
In the event of missing and/or defective parts, or technical questions, please contact an authorised dealer.
Pay careful attention to where this product is located, some locations are not suitable for installation.
For indoor use only.
It is recommended that periodic inspections of the product are made as frequently as possible to ensure that safety is maintained.
Pl se ke these instructi s for future reference. ea ep on
CAUTION:
This is ntended f only with the product i or use
maximu weights indicated. Use with heavier tha the m equipment n
m imum ndi ted ma in nstabi ty causing ible nj y. ax i ca y result i li poss i ur
BT8381
COLUMN
BT4002-SCC
BT4118
POLE
BT4002-SPC
BT4001
BT4001
Max Load at 1.5m: 35kg (77lbs)
Max Load at 1.8m: 20kg (44lbs)
BT4001 with Column BT4001 with Pole
Max Load at 1.6m: 25kg (55lbs)
Max Load at 1.8m: 20kg (44lbs)
3
ATTACH COLUMN/POLE TO THE BASE
Use the xing screws supplied with the column/pole to connect base to column/pole and cover.
BT4002-SPC
COVER
BT4001
BASE
BT4116/18
POLE
10AF Hex Key
Supplied with
BT4116/18
5AF Hex Key
Supplied with
BT8381
M16 x 50mm
Hex Screw
Supplied with
BT4116/18
BT8381
COLUMN
BT4002-SCC
COVER
M8 x 35mm
hex screws
Supplied with
BT8381
BT4001
BASE
SINGLE POLE
FLOOR STAND
SINGLE COLUMN
FLOOR STAND
BT8441
SCREEN INTERFACE
BT7532
SCREEN INTERFACE
BT7052 (x2)
Ø50mm
COLLARS
INSTALLATIONs INSTRUCTIONS
EXAMPLE INSTALLATIONS
