B-tech BT8538 Bruksanvisning
B-tech
Videokonferenssystem
BT8538
Läs nedan 📖 manual på svenska för B-tech BT8538 (16 sidor) i kategorin Videokonferenssystem. Denna guide var användbar för 6 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/16
BT8538
Installation Guide
www.btechavmounts.com
■ Universal design suitable for mounting two XL
screens side by side
■ Recommended screen size: 70-86" (177-218cm)
■ Max load: 100kg (220lbs) per screen
■ VESA® and non-VESA fixings: up to 1000 x 800mm
■ Integrated VC shelf with an adjustable arm allows
a camera to be fitted above or below the screen
■ Small footprint, ideal for installs where floor
space is limited
■ Simple ‘hook-on’ screen installation
■ Stand dimensions:
3000mm (118") 2408mm (95") 240mm (9.5")W. H. D.
XXL Twin Screen VC Bolt-Down Stand
Recommended
Max Screen Max
Load
Max
VESA
Post Install
Alignment
1000
x
800
218cm
86"100kg
[220lbs]
2
Installation Safety Notes 2
Parts List 4
Installation Instructions 6
Product Dimensions 15
B-Tech Contact Details 16
Installation Safety Instructions
Contents Pg
Caution: This mount is intended for use only with the
maximum weights indicated. Use with equipment heavier than the
maximum indicated may result in instability causing possible injury.
Do not attempt to install this product until all instructions and warnings have been read and properly understood.
Please keep these instructions for future reference.
Please check carefully to make sure there are no missing or defective parts - defective parts must never be used.
B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper
installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.
General
B-Tech AV Mounts recommends that a professional AV installer or other suitably qualif ied person install this product.
Great care must always be taken during installation as most AV equipment is of a fragile nature, possibly heavy and easily
damaged if dropped. If you do not fully understand the instructions or are not sure how to install this product safely, then
please consult a professional for advice and/or to install this product for you. Failure to mount this product correctly may
cause serious injury or death both during installation and at any time thereafter. Do not mount any AV equipment that
exceeds the specific weight limit of the product you are installing. This weight limit will be clearly stated on each product
and its packaging and will vary from product to product.
Product location
Please pay careful attention to where this product is located. Check load capacity of the floor prior to installation as some
surfaces are not suitable for installation. Designed for indoor use, this mount is suitable for public or home installation. If
located in a public or frequently populated area ensure that the product is out of the immediate reach of people. If any
AV equipment is to be suspended over the likely path or location of people then great care should be taken to secure all
parts of the installation from falling. When drilling holes it is essential to avoid contact with electrical cables and water or
gas pipes contained within. Use of a good quality live wire detector and hidden object locator is therefore recommended.
Only drill into structures when you are sure it is safe to do so.
Fixing hardware
It is highly recommended that all fixing screws be used where supplied and that the purpose of all other fixing hardware
is fully understood. In some cases more AV equipment fixing hardware will be supplied to accommodate different models
of equipment and set up configurations. The installer must be satisfied that any supplied fixing hardware is suitable for
each specific installation. The fixing kit supplied with the product may not be suitable for all walls. If any fixing screws or
included hardware are deemed not sufficient for a safe installation then please consult a professional or your local
hardware store.
Hazard limitation
When routing cables take advantage of any built in cable management features that the product might provide and ensure
that all cables are tidy and secure. Check to see that any moving aspect of the product can do so unhindered by any cabling.
Some products have moving parts and the potential to cause injury through the crushing or trapping of fingers or other
body parts. Particular attention to the nature of moving parts is required especially when assembling installing and
adjusting during set up. Immediately after installation double-check that the work done is safe and secure. Double-check
all necessary fixings are present and are of ample tightness. It is recommended that periodic inspections of the product
and its fixing points are made as frequently as possible (no more than 6 months apart) to ensure that safety is maintained.
If in doubt consult a professional AV installer or other suitably qualified person.
BT8538
3
B-Tech AV Mounts 建议本产品由专业AV安装人员或其他合格人员安装。 B-Tech AV Mounts 及它的代理商、经销商不对由于
不恰当的安装而造成的损失或伤害负责。 本产品必须安装在合适的架构上，并仅用于不超过所标示的最大承重。
Společnost B-Tech AV Mounts doporučuje provést instalaci tohoto produktu instalátora AV či jinak způsobilé osoby.
Společnost B-Tech AV Mounts, její distributoři a prodejci nenesou prostřednictvím odborného odpov ědnost za škody
nebo zranění zp ůsobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné konstrukce a používat jen
po uvedenou maximální výšku.
B-Tech AV Mounts empfiehlt, dass dieses Produkt durch einen qualifizierten AV-Techniker oder eine andere Person mit
geeigneter Qualifikation installiert wird. B-Tech AV Mounts, ihre Distributoren und Händler können nicht für durch
fehlerhafte Montage verursachte Beschädigung oder Verletzung haftbar bzw. verantwortlich gemacht werden.
Dieses Produkt muss auf einem geeigneten Untergrund montiert werden und darf nur bis zum angegebenen
Höchstgewicht verwendet werden.
B-Tech AV Mounts recommends that this product be installed by a qualified AV technician or other suitably qualified
person. B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by im-
proper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.
This product must be mounted on a suitable surface and may only be used up to the specified maximum weight.
B-Tech AV Mounts recomienda que un instalador de audio y video profesional u otra persona debidamente cualifica-
da instalen este producto. B-Tech AV Mounts, sus distribuidores y concesionarios no se hacen cargo ni se responsa-
bilizan de ningún daño o lesión provocados por una instalación inapropiada. Este producto se debe montar en una
estructura adecuada y se debe utilizar soportando solamente hasta el peso máximo indicado.
B-Tech AV Mounts recommande de confier l’installation de ce produit à un installateur AV professionnel ou à une
autrepersonne dûment qualifiée. B-Tech AV Mounts, ses distributeurs et ses revendeurs ne sauraient être tenus re-
sponsables de tout dégât ou de toute blessure résultant d’une installation incorrecte. Ce produit doit être monté sur
un support approprié et utilisé dans la limite du poids maximum indiqué.
B-Tech AV Mounts consiglia di affidare l’installazione di questo prodotto a un installatore specializzato o ad altra per-
sonaadeguatamente qualificata. B-Tech AV Mounts, i suoi distributori e rivenditori non accettano alcuna responsa-
bilità nei riguardi di eventuali danni o infortuni causati da un’errata installazione. Questo prodotto deve essere fissato
a una struttura idonea e utilizzato unicamente sino al peso massimo indicato.
B-Tech AV Mounts はAV設置の専門家または適合した知識を備えた人が製品を設置することを推奨します。 B-Tech AV Mountsと
販売店、取引先はこうした安全指針に従わない場合に随伴される製品の損傷や傷害に対する責任を負いません。 場合によって製
品が設置されるに適していないところもあるので設置位置に特別な注意を傾けてください。この製品の位置に注意を傾けて設置
に適していない壁がいるかを確認してください。 指定した重さ制限を超過するAV装備を装着しないでください。
B-Tech AV Mounts 는 AV 설치 전문가 또는 적합한 지식을 갖춘 사람이 제품을 설치하도록 권장합니다. B-Tech AV Mounts 와 판매
점, 거래처는 이러한 안전 지침을 따르지 않을 경우에 수반될 제품의 손상이나 상해에 대한 책임을 지지 않습니다. 경우에 따라 제품
이 설치되기에 적합하지 않은 곳들도 있으므로 설치 위치에 특별한 주의를 기울여 주시기 바랍니다. 제품의 설치 위치에 주의를 기울
여 확인하십시오. 지정된 무게 제한을 초과하는 AV 장비를 장착하지 마십시오.
B-Tech AV Mounts adviseert om dit product te laten installeren door een professionele AV-installateur of andere
hiervoor gekwalificeerde persoon. B-Tech AV Mounts , haar distributeurs en dealers zijn niet aansprakelijk of verant-
woordelijk voor schade of letsel die is veroorzaakt door onoordeelkundige installatie. Dit product moet worden gem-
onteerd aan een geschikte constructie, waarbij het aangegeven maximum gewicht niet mag worden overschreden.
Firma B-Tech AV Mounts zaleca, aby ten produkt był instalowany przez profesjonalnych instalatorów AV lub inny od-
powiednio przeszkolony personel. Firma B-Tech AV Mounts, jej dystrybutorzy i dealerzy nie ponoszą odpowiedzialności
za uszkodzenia lub obrażenia ciała powstałe w wyniku nieprawidowej instalacji. Niniejszy produkt musi być amontowa-
ny na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia.
A B-Tech AV Mounts recomenda que a instalação deste produto seja efectuada por um instalador de AV instalador
de AV profissional ou outra pessoa devidamente habilitada. A B-Tech AV Mounts e os seus distribuidores e conces-
sionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta. Este produto tem de ser
montado numa estrutura adequada e utilizado somente até ao peso máximo indicado.
Компания B-Tech AV Mounts рекомендует, чтобы установка данного изделия производилась инженером по
установке аудtио-видеотехники или другим специалистом с соответствующей квалификацией. Компания
B-Tech AV Mounts ее дистрибьюторы и дилеры не несут ответственности за повреждения или травмы,
полученные в результате неправильной установки.
-
AV
. -
.
.
CN
CS
DE
EN
ES
FR
IT
JP
KR
NL
PL
PT
RU
Produktspecifikationer
| Varumärke: | B-tech |
| Kategori: | Videokonferenssystem |
| Modell: | BT8538 |
