NEEDLE SIZE THREAD SIZE
12 and 14 monolament, 100 wt. silk, 60 wt. poly, mylar
16 monolament, hologram, 100 wt. silk, 60 wt. poly, 50 wt. poly, 50 wt. cotton, some 40 wt. threads
18 40 wt. cottons and poly, 30 wt. cottons and poly
20 Any thread 30 wt. and heavier such as 12 wt., 19 wt., 30 wt.
QUICK REFERENCE CARD
Download a complete Gallant XL Stationary user manual from
the BabyLock website: www.BabyLock.com/manuals
Use only the correct needle system as recommended by BabyLock. For the Gallant XL Stationary,
this is needle system 134. This needle system is designed to withstand high stitching speeds.
Choose among sizes 12 through 20 according to the type of thread you are using.
NEEDLE AND THREAD GUIDE
TO THREAD THE GALLANT XL STATIONARY
© Tacony Corporation ● www.BabyLock.com ● 1-800-313-4110
1. Place thread cone onto spool post 1, insert the thread through the thread-mast eyelet 2 from right to left,
continuing to the 3-hole thread guide 3.
2. Thread all three holes from back to front 4, wrapping as you go, and being careful not to cross threads.
NOTE: This is recommended for most threads. Very delicate threads, e.g. metallic threads or monolament,
may require less tension. If you have problems with thread breaking, try threading only one or two holes 4.
3. The thread continues down through thread guide 5 and then to the tension assembly 6.
IMPORTANT: The thread must be ossed up between two tension discs. If not ossed all the way up, the
thread will lay on top of the tension discs (no tension) and thread looping on the bottom of the quilt can occur.
4. After the thread is in the tension disks, be sure that the thread catches on the take-up spring and then pull it
down under the stirrup thread guide 7.
5. Bring the thread up and through the take-up lever from back to front 8, and then through the lower thread
guide 9. Almost there! Thread through the needle bar thread guide hole, this time from front to back 10 .
6. Make sure the thread follows the groove down the front of the needle 11 and insert thread through the
eye of the needle from front to back. While pulling thread through the eye of the needle be careful that the
thread does not twist around the needle.
2
1
3
4
5
7
8
6
9
10
11
GALLANT XL STATIONARY SCREEN ICONS AND NAVIGATION
Home Screens: Where you’ll be when sewing! (See Stitching Modes section for more information.)
For more information about tools and settings, see the
Machine Tools
and
Information Screen
sections of the Gallant XL Stationary manual.
QM11070-BL • August 2024
MACHINE TOOLS ICONS
Access from the Home screen by clicking this icon.
Manual Stitching Mode
: Select the Manual icon and then
specify the stitches per minute (speed).
When using manual stitching mode, the length of the stitch
is determined by how quickly or slowly you move the quilt, in
combination with the number of stitches per minute (up to 2100)
that you choose.
For a consistent stitch length, move the quilt at a consistent speed.
Experiment with dierent combinations of quilting speed and
stitches per minute to nd what optimally works for you.
Precision Stitch Regulation
: Select the Precision icon and
then specify the stitches per inch. Ideal for ruler work.
Stitch regulation maintains a consistent stitch length (stitches
per inch), regardless of how quickly or slowly you move the quilt.
When quilting in Precision mode, the needle only moves when you
move the quilt. After you press the play key on the display or press
the foot pedal, move the quilt to begin quilting according to the
stitches-per-inch setting. When you pause moving the quilt, the
needle will pause until you move it again. Press the pause key on
the display or release the foot pedal to fully stop quilting.
Cruise Stitch Regulation
: Select the Cruise icon and then
specify the cruise speed (stitches-per-minute) setting.
When quilting in Cruise mode, the needle will start to move
immediately when you press the play key on the display or the foot
pedal, according to the cruise speed (stitches-per-minute) setting.
Once you begin to move the quilt, the needle will move according
to the stitches-per-inch setting.
The needle continues to move at the Cruise speed (stitches per
minute) anytime you stop moving the quilt, until you press the
pause button on the display or release the foot pedal.
Needle-stop position:
Select the arrow for the
desired end needle position for when you stop
stitching. The blue arrow is the selected stop
position. Push the blue arrow once and it does
a half stitch. Push and hold the blue arrow and
it does a walking stitch until released.
Lights:
Select this icon to adjust the brightness
of lights. Press to return to the menu.
Overspeed Alarm: Select to toggle the alarm
on or o. The alarm lets you know if you are
quilting too fast for stitch regulation. Press
to return to the menu.
Stitch Count: Select this to view your project
stitch count and your machine’s lifetime stitch
count. Press the Project count button to reset
the count to zero when starting a new quilt.
Press to return to the menu.
Diagnostics
: Contact your locally authorized
Baby Lock Retailer for assistance when running
diagnostics. Press to return to the menu.
Updates:
Display and machine updates can be
found on https://babylock.com/software-
support-and-downloads. Press to return
to the menu.
System Information: Show machine and
display hardware and rmware versions.
Press to return to the menu.
Return Home: Returns you to your most recent
home screen. Press to return to the menu.
STITCHING MODES
Select from the Menu screen.
Precision Cruise
Manual
The needle cycles continuously, but it
changes speeds to maintain the stitch
length when the quilt is moved.
The needle cycles continuously at
the same speed, regardless of the
movement of the quilt.
The needle cycles according to the
movements of the quilt to maintain the
stitch length.
Note: FP (Foot Pedal) and OSR (Optical Stitch Regulation) show orange only when the FP cable and OSR cable are connected.
