Bajaj Pulsar AS 200 Bruksanvisning
Läs nedan 📖 manual på svenska för Bajaj Pulsar AS 200 (39 sidor) i kategorin Motor. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/39
Table of Contents
Description
1. Technical Specifications 1
2. Identification Data 3
3. Location of Parts 5
4. Steering cum Ignition lock 8
5. Fuel Tank Cap / Fuel Tap 9
6. Speedometer Details 10
7. Speedometer Setting 12
8. Control Switches 14
9. Rear seat / Tool kit 16
10. Front Seat / Battery 17
11. Fitment of Front & Rear Seat 18
12. Removal & Fitment of Side Cover LH & RH 19
13. Daily Safety Checks 20
14. How to ride your Bike 21
15. Safe Riding Tips 25
16. Engine Oil 26
17. Wheels - Tube less Tyre 27
18. Battery 28
19. Engine Cooling System / Coolant 29
20. Periodic Maintenance Information 30
21. Brake Fluid 32
22. Periodic Maintenance & Lubrication Chart 33
23. Non Use Maintenance
Notice:
The description and illustration in this booklet
are not to be taken as binding on the
manufacturers. The essential features of the
type described and illustrated herein remaining
unaltered. Bajaj Auto Limited reserves the
right to carry out at any moment without
being obliged to bring this booklet upto-date
& to do modifications on the vehicle, parts or
accessories as may be convenient and
necessary.
Safety and Warning information :
Caution : This indicates that a potential
hazard which could result in vehicle
damage, if advice provided is not
followed.
Warning : This indicates that a potential
hazard or injury to you or other persons &
to the vehicle can happen, if advice
provided is not followed.
Engine 4 Stroke, Single Cyl.:
Bore x Stroke 72.0 mm x 49.0 mm:
Engine Displacement 199.5 cc:
Compression Ratio 11 : 1:
Idling Speed 1350 ~ 1450 RPM:
Max. Net Power 23.5 PS at 9500 RPM:
Max. Net Torque 18.3 Nm at 8000 RPM:
Ignition System DC:
Spark Plug 3 Nos:
Spark Plug Gap 0.7 ~ 0.8 mm:
Transmission 6 speed constant :
mesh
Gear Shifting Pattern 1 Down 5 Up:
Engine Lubrication Pressurized oil supply:
Engine Cooling Liquid cooling:
Starting Aid Electric starter:
Front Brake Hydraulic Disc type:
Rear Brake Hydraulic Disc type:
Fuel Tank Capacity
Full 12 liters:
Usable Reserve 2.4 liters:
Unusable Reserve 0.2 liters:
Dimensions : Pulsar NS Pulsar AS
Length 2017 mm 2070 mm:
Width 804 mm 804 mm:
Height 1195 mm 1205 mm:
Wheel base 1363 mm 1363 mm:
Ground clearance 167 mm 167 mm:
Tyre Size
Front 100/80-17,52P tubeless:
Rear 130/70-17,61P tubeless:
Tyre Pressure
2
Front 1.75 kgf/cm (25 PSI):
2
Rear (Solo) 2.00 kgf/cm (28 PSI):
2
Rear (with pillion) 2.25 kgf/cm (32 PSI):
Technical Specifications
1
Note :
• All dimensions are under UNLADEN condition.
• Above information is subject to change without
any notice.
Electrical System 12 Volts DC:
Head Lamp H4, 55/60W:
Position Lamp 3W (2 nos.):
Tail /Stop Lamp LED type:
Side Indicator lamp 10W :
Neutral Indicator Green LED:
Hi Beam Indicator Blue LED:
Turn Signal Indicator Green LED:
Side Stand Indicator LED :
Speedometer Lamp LED :
Rear No. Plate Lamp 3W :
Horn 12V DC:
Battery 12V - 8 Ah VRLA:
Vehicle Kerb Weight 145 kg.(For NS 200):
153 Kg.(For AS 200)
Gross Vehicle Weight 275 kg. (For NS 200):
283 kg. (For AS 200)
(Including rider & pillion)
Max. Speed 136 km/hr.:
2
Technical Specifications
