Product Overview
Troubleshooting
Have you got everything?
Unpack the box and make sure all
of these items are there:
Note: only one power board
(white/black) is supplied.
You will need a Philips head
screwdriver (not included) to
detach the desk clamp from
the power board.
User Guide
Model: AP5ODM-0224-W, AP5ODM-0224-B
5-Way Surge Protection Power Board
with Detachable Desk Clamp
A. 5-Way Surge Protection Power Board
with Detachable Desk Clamp
B. User Guide
C. Warranty Certicate
Power On/Off Switch
Press to supply/cut off power to the outlets.
Overload Circuit Breaker (Resettable)
Protects against current overload at 10 amps.
AC Sockets
All 5 sockets are the same protected sockets
and can be used interchangeably.
Detachable Desk Clamp
For mounting the power board on a desk with
a 15-50mm thickness.
USB-C and USB Charging Ports
For charging phones, tablets or other devices.
Surge Protected LED Indicator
When lit, the green light indicates that all
connected devices are surge protected.
Using The Detachable Desk Clamp
1. Position the desk clamp (B) on the edge of a table at
the desired location.
2. Twist the clamp lock (C) until the clamp stopper sits
ush against the bottom of the table. Ensure the
clamp is secure and not loose.
3. To detach the desk clamp from the power board, use
a Philips head screwdriver (not included) to unscrew
the 2 Philips head screws (D) on the back of the
clamp to detach the clamp from the power board.
Give us a call
What? You mean this User Guide didn’t have ALL the answers? Speak to us!
We’d love to help you get up and running as quickly as possible.
Call our on . After Sales Support 1300 002 534
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
No power
output from
one of the
sockets
• Try other sockets. If the other sockets have power output, it’s probably the
contact of one faulty socket that is loose or not connected; avoid using
that socket.
No power
output from
any of the
sockets
• Check that the power switch is turned on (you can try to turn it on and off
a few times to make sure it’s switched on) and that the Active Power LED
Indicator is lit green.
• Check the overload circuit breaker button to see whether it’s tripping, push
it down to reset the circuit breaker.
• Make sure the input socket for the power board has power output.
No output
from the USB
ports
• Check that the USB cable is connected securely to the USB port and/or try
a different USB port.
• The total output current for the USB ports are 4.5A. Remove devices using
the other USB ports.
• Use another USB cable.
Power board is
not turning on
• Check that there is no visible damage to the plug or cord.
• Ensure that the devices connected do not exceed the total maximum load
(2400W, 10A). If exceeded, unplug the devices and press the overload
reset button.
Well done, you made it.
Now sit back and relax... your power board is automatically
covered by a 1-year warranty.
How nice!
1
1
2
2
3
3
4
4
5
5
Enjoy using your power board!
66
A
B
C
D
Specications
Ratings
Input: 230-240Vac, 50Hz 10A
USB-C Output: 5V/3A MAX
USB-A Output: 5V/2.4A MAX
USB Output: total 5V/4.5A MAX
Total Loading Max. 2400W
Surge Protection
Maximum Energy 175J
USB Output DC 5V, 4.5A
Desk Clamp Thickness Suitable for desks 15-50mm thickness
Power Cable 1.5m
Net Weight 450g
Dimensions (W x H x D) 365 x 34 x 53 mm
GENERAL SAFETY WARNINGS
General Safety Warnings
For the safety of yourself and others, follow all instructions and take notice of all the warnings.
When adhered to, these safety precautions can reduce the risk of fire, electric shock and injury.
This product complies with Australian Safety standard AS/NZS 3105, AS/NZS 61558.2.16 to
ensure the safety of the product.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.
IMPORTANT
• Damage: If the power board or
cord is damaged, contact the After
Sales Support line for advice. Do not
attempt to open the board or replace
the cord. The cord must be replaced
by appropriately qualied personnel.
• Repair: If the power board requires
repair, contact the After Sales Support
line; never disassemble or modify the
power board or attempt to service it
yourself.
• Run the power supply cord in such
a way that there will be no risk of
anyone pulling it inadvertently or
tripping over it.
• If power supply cord is damaged, it
must be replaced by an authorised
service agent or similarly qualied
person to avoid a hazard.
• The power board is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction by a person responsible
for their safety.
• Young children should be supervised
to ensure they do not play with the
power board. Close supervision is
always necessary when any appliance
is used by or near children.
• The product is not suitable for use in
locations where children are likely to
be present.
• The surge power board is designed
for indoor use in dry places only.
• Do not exceed a maximum loading of
2400 watts.
• For safety reasons, always use earth
connections.
• Only use the power board with the
power supply cord fully unwound.
• Before installing the power board,
make sure to place it away from: heat
sources, radiators or other products
that produce heat; areas with high
temperatures, high humidity or direct
sunlight; excess dirt and dust; open
windows and any place where water
may get to the unit.
• Do not immerse the cord, plug or
the surge power board in water or
other liquid, or expose the electrical
connections to water or other liquid.
• Unpack the power board and keep
the original packaging carton and
materials in a safe place. It will help
prevent any damage if the power
board needs to be transported in the
future, and you can use it to store the
power board when it is not in use.
• The power board should always be
repacked in its original packaging
whenever transporting to prevent any
possible damage to the product.
• When not in use: Disconnect from
the power source and store in a cool,
dry and well ventilated location out
of direct sunlight, and not subject to
humidity.
• Warning: The socket outlet should
be located near the equipment and
should be easily accessible.
Responsible disposal of the product
At the end of its working life, do not throw
this product out with your household
rubbish. An environmentally friendly
method of disposal will ensure that
valuable raw materials can be recycled.
Contact your local authority for your
nearest recycling centre. Electrical and
electronic items contain materials and
substances which, if handled or disposed
of incorrectly, could potentially be
hazardous to the environment and human
health.
Responsible disposal of the packaging
The packaging of the product has been
selected from environmentally friendly
materials and can usually be recycled.
Please ensure these are disposed of
correctly. Plastic wrapping can be a
suffocation hazard for babies and young
children, please ensure all packaging
materials are out of reach and are safely
disposed of. Please ensure they are
offered for recycling rather than throwing
these materials away.
Cleaning the product
Only use a soft, dry cloth for cleaning the
product; do not use a damp cloth. Never
clean with industrial strength polish, wax,
benzene, paint thinner, air freshener,
lubricant, detergent or other chemicals.
Wipe off any moisture, dirt or dust on the
power sockets and plug pins with a clean,
dry cloth.
