Montage- / und Bedienungsanleitung
Umluft-Deckenhaube AURA
1
INSTRUCTIONS FOR USING, MAINTAINING AND INSTALLING THE HOOD
ATTENTION: The hood must only be installed by a qualified technician.
The company accepts no liability if it is installed by an unauthorized person.
Please read these instructions carefully before beginning the installation. Conserve
this handbook together with the hood
WARNINGS
This appliance can be used by children aged from 8 years and above and persons
with reduced physical sensor your mental capabilities, or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
Before cleaning or performing any periodic or urgent maintenance to the hood,
ensure the power is turned off by removing the plug from the socket and turning
the main switch to 0 (off).
Do not to connect the hood to any piping used for combustion appliances, such as
burners, boilers or fireplaces.
Check that the main power supply corresponds to the voltage required by the hood,
which is given on the silver label stuck inside the hood. Ensure that the electric
system is correctly earthed and that the earth discharge works correctly.
When cooking, do not use any materials that could form high or unusual flames. Oil
that has been used twice and fats are very dangerous and could easily fire. Do not
prepare flambé dishes under the hood.
Once the specialized technician has completed the installation of the the hood
2
equipped, all the leads, connectors, ground connections must not be accessible to
the user.
Only the authorized service point is granted access by removing the screwed on
panels.
Respect local legislation and regulations issued by the relative authorities regarding
the exhaust air when the suction is operating. Failure to respect and perform all the
maintenance and cleaning operations described in this handbook could cause a fire
hazard.
ATTENTION: Accessible parts may become hot when the hood is used with cooking
appliances.
INSTALLATION
The minimum safety distance between the bottom of the hood and the top of the
cooking hob must be 65 cm. smaller distances must be previously authorized by the
manufacturer. (see installation drawings)
The hood can be only used in recirculation mode, thus it has a patented odor
removal system. There is not an option to connect it to a piping system to exhaust
outside your kitchen.
ASSEMBLY INSTRUCTIONS
Attention: Before proceeding with the installation, make sure that the screws and
the anchors are already supplied, are suitable for the type of all the hood will be
fixed to.
To assemble the hood, use the accessories that are supplied and follow the
instructions given in the enclosed handbook.
First of all, mark your ceiling by a pencil before drilling, according to the sizes at
“Figure A” and set the hood mains cable outlet will be from the top or from the side,
depending on your wall plug place according to “Figure B and Figure C”
ELECTRIC WIRING
The electrıc wiring must be performed by a specialized electrician fully respecting
current standards and legislation in force. Check that the power supply corresponds
to the voltage requested by the hood, which is given on the silver label stuck
inside the hood. Ensure that the wiring system conforms to current standards and
the earth discharge works efficiently. Pay special attention to the hood power cable,
ensure that it does not pass through any holes without a cable clamp. For direct
connection to the electrical mains is necessary to provide a device that ensures
disconnection from the electrical mains, with an opening distance of the contacts
that allows the complete disconnection under the conditions of overvoltage
category III. in accordance with the rules of installation
The plug or omni polar switch must be accessible when the unit is installed.
3
