HELLBABE HB01

Ultimate Wah-Wah Pedal with Optical Control

Thank you for showing your condence in us by purchasing the Behringer

HELLBABE HB01. This professional Wah-Wah pedal is specially designed

to provide everything you need for all-style classic and modern sounds.

Thanks to its high-performance features like exible Q control, freely

adjustable heel-down frequency range (perfect for use with bass guitars),

tunable boost function and much more you’re armed with a tool for serious

musicians yearning for the most up-to-date sounds to add new dimensions

to their creativity.

WHERE TO PUT YOUR WAH-WAH

Most guitar players put their Wah-Wah pedal before time based eects

like reverb, anger, chorus, vibrato etc. This assures that the eects are

added to the Wah-Wah sound. Even all kinds of distortion/overdrive

eects should be placed before this unit to achieve best tone results.

Controls

(1) This is the of the HB01. The unit will be activated as soon PE DAL

as you put your foot on and move it. By taking your foot from

the pedal the eect will be deactivated. Depending on the timer

adjustment (see ) the HB01 remains active for a few seconds (10)

after that.

(2) The control lets you extend the heel-down frequency RANGE

to match the frequency range of bass guitars for example

(440 Hz to 250 Hz).

(3) The switch activates the boost function. The output level BOOST

is then increased - but only if the Wah eect is switched on.

(4) The control adjusts the level of output boost BOOST

(max. +15 dB). This control is only active if the BOOST switch

is set to ON (and if the Wah is switched on).

V 1.0

(13) (12) (14)

(1) (3) (5) (6) (8) (9)

(4) (7) (2)(11) (10)

2HELLBABE HB01

(5) The control allows to change the shape of the lter peak. Q

High Q settings (turned to right position) produce a large,

selective lter peak with a high output level. Low Q settings

(turned to left position) provide a lower output level

with a subtle, broad lter peak producing less vocal eect.

(6) Turning the FINE control allows to extend the toe-down

frequency of the sweep range up to 2.2 kHz.

(7) Use this ¼" TS connector to plug in the instrument cable. IN

(8) The ¼" TS connector sends the eected signal to your amp. OUT

(9) The ¼" TS connector can be used as second output or OUT/BYPASS

as bypass, hard wired to the input, to play out the uneected signal.

(10) The control (accessable through a hole in the housing) TIMER ADJ

is needed to adjust the time the eect remains active

after taking your foot from the pedal.

(11) Use the connection to plug in a 9 V power supply (not included). 9 V

(12) The -LED illuminates when the eect is activated. STATUS

(13) The -LED illuminates when the boost function is activated. BOOST

(14) The ROCKER SCREW allows to adjust the resistance

of the rocker mechanism.

The is located at the bottom of the unit. BATTERY COMPARTMENT

Open the lid to install or replace the 9 V battery.

◊

◊ ◊ The HB01 has no on/o switch. As soon as you insert the jack

into the IN connector, the HB01 begins running. When not

using the HB01, remove the jack from the IN connector. This

extends the life of the battery.

The is located at the bottom of the unit.SERIAL NUMBER

Safety Instructions

Do not use near water, or install near heat sources. Use only authorized

attachments/accessories. Do not service product yourself. Contact our

qualied servicing personnel for servicing or repairs, especially when

power supply cord or plug is damaged.

Limited Warranty

For the applicable warranty terms and conditions and additional

information regarding Music Tribe’s Limited Warranty, please see

complete details online at musictribe.com/warranty.

3HELLBABE HB01

Specications

Input

Connector ¼" TS

Impedance 1 MΩ

Out

Connector ¼" TS

Impedance 1 kΩ

Output/Bypass

Connector ¼" TS

Impedance 1 kΩ

Power Supply

9 V , 100 mA regulated

PSU-SB-CN Behringer 220 VAC adaptor China

PSU-SB-EU Behringer 230 VAC adaptor Europe

PSU-SB-JP Behringer 100 VAC adaptor Japan

PSU-SB-SAA Behringer 240 VAC adaptor Australia

PSU-SB-UK Behringer 240 VAC adaptor UK

PSU-SB-UL Behringer 120 VAC adaptor USA

Power connector 2 mm DC jack, negative center

Battery 9 V type 6LR61

Power consumption 30 mA

Physical/Weight

Dimensions 3.8 x 4.7 x 10"

(H x W x D) 99 x 120 x 254 mm

Weight 2.6 lbs / 1.2 kg

Behringer is constantly striving to maintain the highest professional standards. As a result

of these efforts, modifications may be made from time to time to existing products without

prior notice. Specifications and appearance may therefore dif fer from those listed or shown.
