TECHNICAL SPECIFICATIONS
Headphone
Transducer type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Closed
Sound coupling to the ear . . . . . . . . . . . . . . . . . . Circumaural
Frequency response . . . . . . . . . . . . . . . . . . . . . . . . 5 - 30,000 Hz
Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Ω
Max. sound pressure level @1 mW / 500 Hz . . . . . 116 dB SPL
T.H.D.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5%
Headband pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5 N
Length and type of the cable . . . . Analogue: 1.2 m (3.9 ) /
detachable / raight cable
Digital: 2.4 m (7.9 ) / detachable /
raight cable
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . Analogue: USB-C
to 4-pole mini jack (3.5 mm)
Digital: USB-C to USB-A cable
Weight (headphone) . . . . . . . . . . . . . . . . . . . . . . 304 g (10.72 oz)
Microphone
Transducer type . . . . . . . . . . . . . . . . . . . . . Electret condenser
Capsule diameter . . . . . . . . . . . . . . . . . . . . . . . . . . 9.9 mm (0.39")
Polar pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioid
Frequency response. . . . . . . . . . . . . . . . . . . . . . . . . 5 - 18,000 Hz
Max. sound pressure level . . . . . . . . . . . . . . . . . . . . . . . . . 118 dB
Signal-to-noise ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 dB
APPLICATIONS
MMX 150 is a USB gaming headset that connects to PC’s
and consoles with andard USB connection.
The beyerdynamic driver syems are the Meta Pick
when it comes to premium sound in udio quality. This
is also demonrated by the high-resolution sound
image of the MMX 150. The 40 mm driver syems built
into the MMX 150 are specially optimised for gaming.
The result is a clear and precise sound.
Typical gaming noise such as mouse and keyboard
clicks are eectively suppressed by the META VOICE
cardioid microphone. Its 9.9 mm capsule reproduces
the voice image lifelike and naturally.
With the practical control wheel, the MMX 150 can be
controlled quickly and precisely without having to
leave the game. In addition, the control wheel has a
click function for full access to the mute function and
Augmented Mode during the game.
The switchable Augmented Mode creates a similarly
spatial sound as if using open headphones. The
contact to the outside world is maintained, so that the
ringing of a telephone or at the door is not overheard;
the awareness of one’s own voice reproduction is also
preserved.
Memory foam-filled leatherette ear pads and an
aluminium headband with a leatherette headband
also equipped with memory foam ensure hours of
wearing comfo. The bayonet mechanism allows the
ear pads to be replaced quickly and easily.
FEATURES
• Closed USB gaming headset
• Ideal for PC and consoles with
standard USB connection
• Augmented mode for contact with the outside world
• META VOICE microphone for professional sound
• High wearing comfort due to memory foam in ear
and headband pads
• Soft, replaceable ear pads
• Single-sided, detachable cables:
analogue and digital
SUPPLIED ACCESSORIES
• 1 x USB-C to USB-A cable, 2.4 m, to connect the head-
set to a computer/console
• 1 x USB-C to 4-pole jack (CTIA) cable, 1.2 m, to connect
the headset to analogue/mobile devices *
• 1 x pop shield for the microphone
*Control elements and Augmented Mode
are not available when using this cable
ACCESSORIES / REPLACEMENT PARTS
Various accessories and replacement parts can be
found at: www.beyerdynamic.com
MMX 150
USB Gaming Headset
Order # 745.553 (black)
Order # 729.892 (grey)
beyerdynamic GmbH & Co. KG
Theresienr. 8 | 74072 Heilbronn – Germany
Tel. +49 (0) 71 31 / 617 - 300 | info@beyerdynamic.de | www.beyerdynamic.de
For fuher diributors worldwide, please go to www.beyerdynamic.com
Non-contractual illurations. Contents subject to change without notice. E1 / MMX 150 (11.21)
1 of 1
