Sida 1/12
1
BIG ASS FANS VESPER® ELECTRIC HEATER
MODELS
VOLTAGE (V)
TOTAL POWER (W)
CURRENT(AMPS)
BAFDS15120B
120
1500
12.5
BAFDS32080B
208/240
1800/2400
8.7/10
BAFDS32240B
208/240
2400/3200
11.5/13.3
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
BIG ASS FANS dba DELTA T LLC 2348 INNOVATION DR. LEXINGTON KY 40511 PHONE: 877.BIG.FANS
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
RADIANT INFRARED ELECTRIC HEATER
FOR OUTDOOR COVERED OR INDOOR USE, IN BOTH COMMERCIAL AND RESIDENTIAL
LOCATIONS IN MODERATE CLIMATES
2
TABLE OF CONTENTS
1 - SAFETY ............................................................................................................................................................ 3
2 - INSTALLATION INSTRUCTIONS 5 .......................................................................................................................
2.1 INSTALLATION CLEARANCES WALL MOUNT –............................................................................................ 5
2.2 INSTALLATION CLEARANCES CEILING MOUNT –........................................................................................ 6
2.3 INSTALLATION ON HIGH CEILINGS 7 .............................................................................................................
2.4 ELECTRICAL INSTALLATION ......................................................................................................................... 8
2.5 WALL-MOUNTED INSTALLATION ................................................................................................................ 8
2.6 CEILING MOUNTED INSTALLATION 9 ............................................................................................................
2.7 ADJUSTING DIRECTIONAL POSITIONING ..................................................................................................10
3 - MAINTENANCE .............................................................................................................................................11
3.1 CLEANING .................................................................................................................................................11
WARNINGS
THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, FAILURE FOLLOW WARNINGS AND TO
INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, INJURY. OR
Heater must be installed by a certified electrician and installation must
adhere to all local, state and national electric codes.
READ AND SAVE THESE INSTRUCTIONS
Please read this owner’s manual carefully before using the unit and keep this manual for future reference.
USE THIS HEATER ONLY AS DESCRIBED IN THIS MANUAL. ANY OTHER USE NOT RECOMMENDED BY THE
MANUFACTURER MAY CAUSE FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS.
Notice: Changes or modifications not approved by the party responsible for compliance will void the user's
authority to operate the equipment.
3
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following outlined in section 1 SAFETY. –Read all instructions before
installing or using this heater.
1 - SAFETY
WARNING: FIRE OR EXPLOSION HAZARD
●Failure to precisely follow safety warnings could
result in serious injury or property damage.
●This heater has hot surfaces and arcing or sparking
parts inside. Do not use the heater in areas where
gasoline, paint or flammable vapors or liquids are
used or stored.
●This Heater is not to be installed or used in an area
containing hazardous or flammable materials
including but not limited to rags, fabrics, spray or
aerosol cans, cleaning compounds, plastic
containers, paper products, organic dusts,
straw/hay, gasoline, kerosene, lighter fluid, etc.
●To prevent a possible fire, do not block air intakes
or exhaust in any manner.
●Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage to the heater.
●Do not cover the heater in any manner, do not hang
clothing on or near the heater.
●Caution! Do not use the heater together with
another appliance connected to the same supply
line or connected to the same breaker.
●This heater must be properly grounded.
●The power cord must not be left on or around the
heater body.
●Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, curtains, etc. at
least 6 feet (1.8m) from the front of the heater and
keep them away from the sides and rear.
WARNING: PERSONAL INJURY HAZARD - OPERATION
●This heater is hot when in use. To avoid burns, do
not let bare skin touch hot surfaces.
●Extreme caution is necessary when any heater is
used by or near children or other persons with
reduced physical, sensory or mental capabilities.
●Never leave the heater unattended while it is
operating.
●Do not operate any heater after it malfunctions.
Disconnect power at the service panel and have
the heater inspected by an electrician before
reusing.
●Do not use the heater to light cigarettes or similar
materials.
●Do not insert objects in heater openings. Electrical
shock could result.
●To disconnect heater, turn controls to off, and turn
off power to the heater circuit at the main
disconnect panel
