Sida 1/7
User Manual
User Manual
Introduction 3 ..........................................................................................................
Features 3 .................................................................................................................
Specications ........................................................................................................3
Package Contents 4 .................................................................................................
Front 4 .......................................................................................................................
Back 4 .......................................................................................................................
Connection Diagrams 5 ...........................................................................................
Repair 6 .....................................................................................................................
Warranty 6 ................................................................................................................
Disclaimer 6 ..............................................................................................................
Copyright 7 ...............................................................................................................
The Micro Clock MkIII XB is the most accurate word clock we’ve developed to date. With
only 0.6pS RMS of jitter at the BNC outputs, it has less than one third of the jitter of the
standard Micro Clock MkIII! It boasts incredibly accurate crystal oscillators and superior
quality galvanic isolation, both of which contribute to the extraordinarily low jitter
measurement.
The Micro Clock MkIII XB’s small form factor and its ability to drive up to 1,000 feet of
coaxial cable make it not only the perfect solution for improving the conversion quality of
an audio interface, but also for re-clocking digital mixing consoles at live shows or houses
of worship, and as the master word clock in large post-production or broadcast facilities.
It can easily sync all of your digital gear together, even if it’s located in dierent rooms, or
dierent buildings!
We spent the better part of a year eld-testing the Micro Clock MkIII XB prior to its release,
and got a lot of positive feedback on the impact it made in a wide variety of setups. We
hope to continue this trend by making it available to the public. Thanks for your purchase
and for your continued support of Black Lion Audio!
INTRODUCTION
FEATURES
SPECIFICATIONS
Jitter: 0.6pS RMS (BNC outputs)
Outputs: 6 BNC, 1 XLR AES, 1 RCA S/PDIF, 1 Optical S/PDIF (recommended max. cable
length = 1,000ft of high quality, 75Ω coaxial cable)
• BNC: 75 Ω, 5V unterminated
• RCA S/PDIF: 75 Ω, unbalanced
• AES XLR: 110 Ω, balanced
Clock Frequencies
• BNC (kHz) - 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384
• RCA S/PDIF & AES (kHz) - 44.1, 48, 88.2, 96, 176.4, 192
• Optical S/PDIF (kHz) – 44.1, 48, 88.2, 96
Power: 9VDC (6W power consumption)
Power connector: 2.1mm barrel connector with 5.5mm outer diameter (center pin positive)
• Ultra-low jitter, harmonically-enhanced
word clock signal generation
• Dimmable frequency display
• 8 selectable sample rates (44.1kHz,
48kHz, 88.2kHz, 96kHz, 176.4kHz,
192kHz, 352.8kHz, and 384kHz)
• 6 BNC outputs with dedicated output
drivers for maximum isolation
• RCA S/PDIF output
• Optical S/PDIF output
• AES output
• Full & 1/2 rack removable rack ears
• Locking frequency selector knob
User Manual
