PG-2

Studio-grade power conditioner and surge protector

Owner’s Manual

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat regis-

ters, stoves, or other apparatus that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other.

A grounding-type plug has two blades and a third grounding prong.

The wide blade or third prong is provided for your safety. If the pro-

vided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particular-

ly at plugs, convenience receptacles, and the point where they exit

from the apparatus. If the power cord becomes frayed, stop using

immediately.

11. Use only attachments/accessories specied by the manufacturer

12. Use only with a cart, stand, tripod, bracket or table specied by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid in-

jury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is re-

quired when the apparatus has been damaged in any way, such as

power supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the apparatus has been ex-

posed to rain or moisture, does not operate normally, or has been

dropped.

15. This apparatus shall not be exposed to dripping or splashing, and

no object lled with liquids, such as vases, shall be placed on the

apparatus.

16. Note that this apparatus is not completely disconnected from the

AC mains service when the power switch is in the OFF position.

17. The mains plug or power inlet on the product is used as the discon-

nect device, so the disconnected device shall remain readily opera-

ble when reconnected.

18. Any changes or modications not expressly approved in this manu-

al could void your authority to operate this apparatus.

IMPORTANT !

Be sure to use a three prong AC cable that properly ts the power

source. Please use the correct fuse designated on the rear panel be-

fore plugging in the power cord. Improper selection can result in dam-

age to the unit that will not be covered under the warranty.

The lightning ash with an arrow-

head symbol within an equilateral

triangle is intended to alert the

user to the presence of uninsu-

lated “dangerous voltage” within

the product’s enclosure that may

be of sucient magnitude to

constitute a risk of electric shock

to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the product.

The Black Lion Audio PG-2 complies with all applicable / RoHS/ WEEE

European Union directives.

Do not attempt to service this unit yourself, as it will void your warran-

ty. Please check your unit carefully upon receipt and return to place

of purchase immediately if there are any problems with the product.

After that, the standard Black Lion Audio 3 YEAR warranty will apply

to defects in materials and workmanship.

Should your Black Lion Audio product require service,

please contact us on our customer service site:

https://www.blacklionaudio.com/contact. You must obtain an RA #

(Return Authorization number) from us before shipping a unit back to

us. This RA # must be clearly written on the outside of the box.

Please safely pack the units…It is best to use the original packing

materials. Black Lion Audio cannot be responsible for any damag-

es incurred in shipping to us due to poor packaging. PLEASE PACK

CAREFULLY and FULLY INSURE THE SHIPMENT.

INTERNATIONAL

For service or warranty assistance, please contact the Black Lion Au-

dio distributor in your country through the dealer from whom you pur-

chased this product.

LIMITED 3 YEAR WARRANTY

Black Lion Audio’s PG-2 is warranted by Black Lion Audio to be free

from defects in materials and workmanship for the period of THREE

(3) YEARS to the original purchaser. In the event of such defects, the

product will be repaired without charge or, at our option, replaced with

a new one if delivered to Black Lion Audio prepaid, together with a copy

of the sales slip or other proof of purchase date. The warranty excludes

problems due to normal wear, abuse, shipping damage or failure to use

the product in accordance with the specications.

All parts and labor are covered under this Limited Warranty. However,

if it is determined by Black Lion Audio that the device was damaged or

made defective through abuse, we reserve the right to charge the cus-

tomer for the cost of the repair.

Black Lion Audio shall not be liable for damages based upon inconve-

nience, loss of use of the product, loss of time, interrupted operation or

commercial loss or any other damages, whether incidental, consequen-

tial or otherwise. This warranty gives you specic legal rights, and you

may have other rights, which will vary from state to state.

This warranty is not transferable.

QUICK START GUIDE

Once you have installed your PG-2 where you need it, plug it in to an ap-

propriate power source. If you are not sure your source is correct, con-

sult with your local power company.

Plug in your equipment to the correct outlets on the PG-2.

Turn on the power. The digital and analog outlets are switched with a

delay sequence. The digital and analog outputs turn on with the power

switch and turn off after a six second delay. The high current outputs

turn on after six seconds and turn off with the power switch. This allows

any startup sequences to be nished before the high current devices

are turned on.

1. ON/OFF Switch: Once the PG-2 is plugged into a grounded 230VAC

outlet, turning the front panel POWER switch to the ON position will

sequentially power the components plugged into the rear panel

outlets.

2. GROUND OK: When this is on, the PG-2 is plugged into a properly

grounded power source. If the LED is not on, unplug the unit from

the power source and correct the fault.

3. Wiring Fault: This indicates the LINE and NEUTRAL wires in the

source are reversed. Unplug the unit immediately and consult an

electrician to x the fault.

4. Clean Power On: This LED indicates that the PG-2 is providing

clean, beautiful AC power to all connected components.

5. Abnormal Voltage: When this LED is ON, the PG-2 is warning about

under/over voltage (greater than 240VAC or less than 200VAC).

6. Protection ON: When this LED is on, the PG-2’s power surge circuit-

ry is functioning correctly. If this LED is OFF, the circuit has mal-

functioned. If it is OFF, unplug the unit immediately.

7. Digital Audio (Switched) Outlets: These outlets have a special l-

ter circuit that is designed to reduce AC supply interference to your

digital components (workstation, digital effects, etc.). They also

isolate the rest of your system from noise generated by the digital

components themselves.

8. Analog Audio Filter (Switched) Outlets: These outlets have a spe-

cial lter circuit that reduces audible noise in your analog compo-

nents (mixers, dynamic effects, etc.)

9. High Current Filter (Timed) Outlets: These outlets have a special

lter circuit designed to handle high current components like power

ampliers or Active Speakers.

10. Gold-plated ground post: Provides a connection point for any un-

grounded components.

11. Thermal Circuit Breaker: protects the PG-2 from power overload.

12. Breaker Open: When this LED is on, the thermal circuit breaker has

tripped due to an overload. Before resetting the breaker, nd the

reason for the overload.

13. Ultra-high Current AC Power Cable: integral high power, heavy duty

AC cable to maximize power transfer to high current components

such as ampliers.

14. Front Dimmer: This know controls a exible accessory light. Push

on/off and turn clockwise for brightness.

15. Front 12V XLR Lamp Socket: Provides 12VDC on PIN-2 to an acces-

sory lamp.

16. Rear Dimmer: This know controls a exible accessory light. Push

on/off and turn clockwise for brightness.

17. Rear 12V XLR Lamp Socket: Provides 12VDC on PIN-2 to an acces-

sory lamp.

18. Voltage Meter: Three-character LED displays the line voltage at the

source.

19. Amperage Meter: Three-character LED displays the amperage

used by equipment plugged into the PG-2.

20. Unswitched Convenience Outlets: These are ‘always on’ ltered

power outlets.

21. USB Charger: 5V1A convenience charger for USB devices.

Note: For best performance we recommend plugging analog compo-

nents into the analog outlets and digital to digital. It will not harm any

components if they are plugged into any other outlet.

SPECIFICATIONS

Voltage 120VAC 15A max

AC Mains Input Edison 15A Plug

Dimensions Width 438mm (19”)

Height 88mm (2U)

Depth 250mm

Weight 6.8+kg

On with panel switch

off after six seconds

On after three seconds

off after three seconds

On after six seconds

off with panel switch

18 19 201412 21

16 10

11 1 15

7 8 9 17 13

2 4 5 63
