Blackmore BJS-152BT Bruksanvisning

Blackmore högtalare BJS-152BT

Läs nedan 📖 manual på svenska för Blackmore BJS-152BT (5 sidor) i kategorin högtalare. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/5
Samson Electronics Inc.
3400 E. Slauson Ave.
Maywood, CA 90270
Ph: 323.585.6393
Fax: 323.585.6202
Web: hp://www.blackmoremobile.com
BJS-152BT Portable Amplied Loudspeaker
Introducon:
The BJS-152BT is an amplied speaker with built in audio playback funcon and PA capabilies that produces 2100W of power.
This unit has USB, SD/MMC, Analog RCA Audio, dual ¼” Microphone and dual XLR inputs as well as Bluetooth connecvity for
wireless music streaming. It can funcon as a music player or a PA system with no extra components or accessories required. It
also includes an array of accent LED lights to lighten the mood of any party. Sound is reproduced via its 15” Subwoofer driver and
Titanium domed tweeter matched to the pre molded horn of the cabinet. The unit is constructed from durable and strong,
molded ABS plasc with steel mesh grills for the drivers, built in caster wheels and a speaker pole slot for integraon with
mounng hardware and trusses.
Features:
Amplied
Audio playback and PA capabilities
USB/SD/RCA In/RCA Out/dual XLR inputs/dual ¼” mic input
Bluetooth
2100W
LED lighng
Wireless Remote
Speaker pole slot
Wired Microphone Included
Weight: 33 pounds
Dimensions: 17 ½ “ X 27” X 13
Power Supply AC 110-240V 50/60 Hz
Cauon:
Please read All Operang Instrucons before using this product
Avoid electrical shock, DO NOT OPEN THIS UNIT, THERE ARE NO REPLACEABLE PARTS INSIDE. Please refer to
your warranty informaon for service.
Do not Expose this product to Moisture, Water, Rain or Snow. Keep away from direct heat sources. Damaged
items will not be accepted for warranty
Do not clean this unit with solvents or chemicals
Insure that all volume and gain controls are set to “0” when connecng source units
Only line level Signals should be used for source
1.LED Power Indicator 2. Previous track/volume down LED Display Play/pause EQ preset select Repeat track 3. 4. 5. 6.
MP3 Source Selector 7.
8. IR Receiver
9. SD Card Input
10. USB Input
11. Microphone Volume . Microphone Volume 14
12. XLR MIC input XLR MIC input 15.
13. ¼” MIC Input 16. ¼” MIC Input
. RCA Stereo line in/out 17
18. Line in/MP3 selector Line in gain control 19.
20. Master Volume Control . Master Treble Control 21
22. Master Bass Control . Amplier Heat Sink 23
24. Input Voltage Selector . Master power on/o switch 25
AC power plug input 26.
Funcons:
1. LED Power on indicator: This led will illuminate when the unit is receiving power and switched
to the “ON” posion.
2. Previous Track/Volume down: This button allows you to play a previous track when in MP3(USB
or SD) playback mode and Volume down when on the main menu
3. LED Display: The display shows track informaon and menu opons
4. Play /Pause : Press this button to start or stop an MP3 track played via USB or SD
5. EQ : This buon allows you to scroll through the dierent EQ preset opons.
6. Repeat: Press this button to repeat an MP3 track that is currently being played via USB or SD
7. Mode: This buon allows you to select between, USB, SD, BT, Or FM Radio for playback.
8. IR receiver: This is the receiver that receives instrucons from the supplied remote control
unit.
9. SD Card input: This is a standard full size SD card input. Capable of reading cards up to 4GB.
Music les must be formatted as MP3 in order to be played via SD card.
10. USB Input: This is a full size USB2.0 female input. It has a read capacity of 4GB. Music les must
be formatted as MP3 in order to be played via USB.
11. Microphone gain control: This controls the amount of electrical signal received from the
microphone.
12. XLR Input: This connecon allows the use of professional microphones with XLR terminals.
13. ¼” Microphone input: This connecon allows the use of microphones and playback devices
with ¼” audio plugs.
14. Microphone gain control: This controls the amount of electrical signal received from the
microphone.
15. XLR Input: This connecon allows the use of professional microphones with XLR terminals.
16. ¼” Microphone input: This connecon allows the use of microphones and playback devices
with ¼” audio plugs.
17. RCA Stereo line in/out: These connections provide an input for playback devices equipped with
RCA Stereo connections. The output provides RCA stereo signal to external audio sources and
amplied speakers with Stereo RCA inputs.
18. Line In/MP3 Selector: Use this button to select between receiving an audio source from an
external source via the RCA stereo inputs or the built in MP3 player.
19. Line In Gain Control: This controls the amount of electrical signal received from the RCA stereo
inputs.
20. Master Volume Control: This controls the overall output of the speakers. This volume control
supersedes all other built in volume controls.
21. Master Treble Control: This controls the overall treble level of the master audio signal.
22. Master Bass Control: This controls the overall treble level of the master audio signal.
23. Amplier heat sink: This component is responsible for dissipang the heat generated by the
built in amplier. It is normal for this item to become hot aer hours of continual use at high
volume.
24. Input Voltage selector: This switch allows the unit to be compable with 120V and 240V power
sources. Ensure that the correct posion is selected for your power source. Improper selection
will severely damage this unit and could cause an electrical re.
25. AC power plug input: This is the power supply input. Please use only provided AC power plug.

Produktspecifikationer

Varumärke: Blackmore
Kategori: högtalare
Modell: BJS-152BT
