Sida 1/10
Monitor Arm with Mec
Monitorarm met Mechanisch
Bras d’Écran PC avec Ressort
Monitorhalterung mit Mecha
FLYING START.
Whoooo.
935000 - BBMAG1UM V1.1
SET UP MONITOR ARM.
EN
Feed-through mount (B)
Drill a hole in your desk and feed the clamp through it.
Clamp mount (A)
Mount your monitor arm to your desk with the clamp.
2
CHECKLIST.
Does the tick.
Check the VESA size of your
monitor. at way, you can
be sure it fits on the monitor
arm. e screw holes of the
VESA plate and your
monitor have to match.
Do you have a question?
Coolblue.nl/en/
customer-service
Coolblue isn’t liable for any
injury, damage, or arguments
with your partner caused by a
wrong installation.
STEP 4A.
Clamp mount.
STEP 2A.
Clamp mount.
STEP 1A.
Clamp mount.
STEP 1B.
Feed-through mount.
STEP 2B.
Feed-through mount.
STEP 3A.
Clamp mount.
Attach the clamp attachment to the
stand
4
and tighten the bolts
8
.
Suitable for desks with a thickness
between 10 and 40mm.
Attach the plastic protective plate
6
to
the clamp attachment
5
.
Suitable for desks with a thickness
between 40 and 80mm.
Unscrew the desk clamp
5
from the
clamp attachment. Unscrew the disc from
the clamp and then unscrew the clamp
attachment from the clamp.
Place the clamp on the desk and tighten
the screw upwards until the stand is
fastened tightly.
Screw the triangular mounting plate
7
to the bottom of the stand.
Determine the thickness of your desk.
Depending on that, you place the desk
clamp
5
in the upper or lower notches
and tighten the bolts.
EN
44
