Ventilation Hood
Installation Instructions
Designer Hoods
TABLE OF CONTENTS
Safety Instructions 1
Safety Procedures 2
Wall Hood Installation
Installation Instructions 3
Wall Hood 600 CFM In-– Hood Fan (8” Round) 5
Wall Hood 600 CFM In-– Hood Fan (8” Transition) 6
Chimney & Island Hood 600 CFM In-Hood Fan 7 –
Wall Hood 1200 CFM In-Hood Fan 8 –
Chimney & Island Hood -1200 CFM In-Hood Fan 9
Island Hood Installation
Installation Instructions 10
Island Duct Cover Installation 11
Island Duct Work Installation 12
Remote Fan Installation 13
Metal Liner Installation
Installation Instructions 15
Transition Installation & Removal 16
Electrical Connections 18
Compact Metal Liner Sloped Sides 19
Metal Liner Sloped Sides 20
Professional Metal Liner Sloped Sides 21
Metal Liner Flat Sides 22
Chimney Hood Installation
Installation Instructions 23
Alternate Installation Instructions 26
Installing Rear Discharge Through Duct Cover 27
Installing a 600CFM Fan in a 30” Wide Hood 28
Wiring a Remote Fan 29
Use & Care
Bae Filters, Grease Troughs and Lights 30
Cleaning Recommendations 31
Troubleshooting Tips 32
PLEASE READ COMPLETE INSTRUCTIONS BEFORE PROCEEDING.
INSTALLATION MUST COMPLY WITH ALL LOCAL CODES.
IMPORTANT: Save these instructions for the local electrical inspector’s use.
INSTALLER: Please leave these instructions with this unit for the owner.
OWNER: Please retain the instructions for future reference.
SAFETY WARNING: Turn power circuit OFF at the service panel and lock panel door before
wiring this unit.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION To reduce the –
risk of a rangetop grease re.
1. Never leave cooktop surface
unattended while on high
setting
2. Boil overs cause smoke and
greasy spillovers may ignite.
Heat oils slowly on low or
medium settings.
3. Hood fan should always be
ON when cooking on high
heat or when ambeing
foods (i.e. Crepes Suzette,
Cherries Jubilee, Peppercorn
Beef Flambe.)
4. Clean in-hood fans
frequently. Do not allow
grease to accumulate on fan
or bae lters.
5. Always use cookware
appropriate for the size of the
surface element.
CAUTION To reduce the –
risk of re, electric shock, or
injury to people, observe the
following:
1. Use this rangehood only in
the manner intended by the
manufacturer. If you have
any questions, contact the
manufacturer – Prizer
Hoods.
2. Before servicing or cleaning
the unit, switch power o at
service panel and lock the
panel to prevent the power
from being switched on
accidentally. When switched
o for service, attach a tag to
the service panel to indicate
power has been switched o
for maintenance.
3. Install this rangehood only
with remote fan models rated
maximum 12.8A or in-hood
fans manufacturered by
Prizer Hoods, CFM300,
CFM600, CFM1200.
CAUTION To reduce the –
risk of injury to people, in the
event of a rangetop grease re,
observe the following:
1. SMOTHER FLAMES with a
tight tting lid, cookie sheet
or other metal tray.
Immediately turn the gas
burner OFF. NEVER USE
WATER, wet dish-cloths or
towels as a violent steam
explosion will occur.
2. PREVENT BURNS. If gas
ames do not extinguish
immediately: EVACUATE
AND CALL THE FIRE
DEPARTMENT.
3. NEVER PICK UP A
FLAMING PAN as you may
sustain burns.
4. Use re extinguisher only if:
•You know you have a class
ABC extinguisher, and you
know how to operate it.
•Fire is small & contained in
the area where it started.
•Fire department is being
called.
•You can ght the re with
your back to an exit.
CAUTION: FOR GENERAL VENTILATION
USE ONLY. DO NOT USE TO EXHAUST
HAZARDOUS OR EXPLOSIVE MATERIALS
OR VAPOR.
HOOD SHAPES & DIMENSIONS CAN VARY
WITHOUT NOTIFICATION. NO HARDWARE
IS SUPPLIED FOR INSTALLATION
3
