Ventilation Hood

Installation Instructions

Designer Hoods

TABLE OF CONTENTS

Safety Instructions 1

Safety Procedures 2

Wall Hood Installation

Installation Instructions 3

Wall Hood 600 CFM In-– Hood Fan (8” Round) 5

Wall Hood 600 CFM In-– Hood Fan (8” Transition) 6

Chimney & Island Hood 600 CFM In-Hood Fan 7 –

Wall Hood 1200 CFM In-Hood Fan 8 –

Chimney & Island Hood -1200 CFM In-Hood Fan 9

Island Hood Installation

Installation Instructions 10

Island Duct Cover Installation 11

Island Duct Work Installation 12

Remote Fan Installation 13

Metal Liner Installation

Installation Instructions 15

Transition Installation & Removal 16

Electrical Connections 18

Compact Metal Liner Sloped Sides 19

Metal Liner Sloped Sides 20

Professional Metal Liner Sloped Sides 21

Metal Liner Flat Sides 22

Chimney Hood Installation

Installation Instructions 23

Alternate Installation Instructions 26

Installing Rear Discharge Through Duct Cover 27

Installing a 600CFM Fan in a 30” Wide Hood 28

Wiring a Remote Fan 29

Use & Care

Bae Filters, Grease Troughs and Lights 30

Cleaning Recommendations 31

Troubleshooting Tips 32

PLEASE READ COMPLETE INSTRUCTIONS BEFORE PROCEEDING.

INSTALLATION MUST COMPLY WITH ALL LOCAL CODES.

IMPORTANT: Save these instructions for the local electrical inspector’s use.

INSTALLER: Please leave these instructions with this unit for the owner.

OWNER: Please retain the instructions for future reference.

SAFETY WARNING: Turn power circuit OFF at the service panel and lock panel door before

wiring this unit.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION To reduce the –

risk of a rangetop grease re.

1. Never leave cooktop surface

unattended while on high

setting

2. Boil overs cause smoke and

greasy spillovers may ignite.

Heat oils slowly on low or

medium settings.

3. Hood fan should always be

ON when cooking on high

heat or when ambeing

foods (i.e. Crepes Suzette,

Cherries Jubilee, Peppercorn

Beef Flambe.)

4. Clean in-hood fans

frequently. Do not allow

grease to accumulate on fan

or bae lters.

5. Always use cookware

appropriate for the size of the

surface element.

CAUTION To reduce the –

risk of re, electric shock, or

injury to people, observe the

following:

1. Use this rangehood only in

the manner intended by the

manufacturer. If you have

any questions, contact the

manufacturer – Prizer

Hoods.

2. Before servicing or cleaning

the unit, switch power o at

service panel and lock the

panel to prevent the power

from being switched on

accidentally. When switched

o for service, attach a tag to

the service panel to indicate

power has been switched o

for maintenance.

3. Install this rangehood only

with remote fan models rated

maximum 12.8A or in-hood

fans manufacturered by

Prizer Hoods, CFM300,

CFM600, CFM1200.

CAUTION To reduce the –

risk of injury to people, in the

event of a rangetop grease re,

observe the following:

1. SMOTHER FLAMES with a

tight tting lid, cookie sheet

or other metal tray.

Immediately turn the gas

burner OFF. NEVER USE

WATER, wet dish-cloths or

towels as a violent steam

explosion will occur.

2. PREVENT BURNS. If gas

ames do not extinguish

immediately: EVACUATE

AND CALL THE FIRE

DEPARTMENT.

3. NEVER PICK UP A

FLAMING PAN as you may

sustain burns.

4. Use re extinguisher only if:

•You know you have a class

ABC extinguisher, and you

know how to operate it.

•Fire is small & contained in

the area where it started.

•Fire department is being

called.

•You can ght the re with

your back to an exit.

CAUTION: FOR GENERAL VENTILATION

USE ONLY. DO NOT USE TO EXHAUST

HAZARDOUS OR EXPLOSIVE MATERIALS

OR VAPOR.

HOOD SHAPES & DIMENSIONS CAN VARY

WITHOUT NOTIFICATION. NO HARDWARE

IS SUPPLIED FOR INSTALLATION
