Owner’s Manual
(R1K1-V2)_OM_v 1.6
Base Serial Number: R ____________________
Console Serial Number: ___________________
Purchased Date: ___ / ___ / ______
Dealer’s Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
R1000-V2
Recumbent
Bike
Open your Camera
App and point it at
the QR Code
Base Serial
Number
To see in
FULL COLOR
& additional information,
scan this QR code.
This page intentionally left blank
Congratulations and Welcome to the BODYCRAFT Family
Thank you for selecting BODYCRAFT. Your choice reflects a wise investment in you and your
facility. We hope you use it for many healthy years!
BODYCRAFT offers a complete array of high-quality fitness equipment. Please refer to our website at
www.bodycraft.com to view more ways to enhance your lifestyle.
Your BODYCRAFT machine has all the quality and design elements to make your workout extremely efficient
and comfortable. Your new unit is a serious cardio machine that will keep you motivated, challenged and
within reach of your fitness goals. Strength & cardiovascular training is vital for all ages which will provide an
effective workout, producing results that will encourage you to reach your fitness goals and maintain the
body you have always wanted.
Spending 15 to 30 minutes a day, three times a week, is all you need to start seeing the benefits of
a regular exercise program.
As a premium exercise equipment manufacturer, we are committed to your complete satisfaction. If you
have questions, suggestions or find missing or damaged parts, we guarantee your complete satisfaction
through our authorized dealer network or by contacting us directly. Please call your local dealer or
BODYCRAFT.
BODYCRAFT (a division of Recreation Supply, Inc.)
7699 Green Meadows Dr.
Lewis Center, OH 43035
Phone: Email: 800-990-5556 9 am - 5 pm EST service@bodycraft.com
Proof of purchase must be supplied to validate warranty and the product must have been
registered with BODYCRAFT via online at www.bodycraft.com or by calling 800-990-5556
or 740-965-2442 M-F 9 a.m. - 5 p.m. EST.
For parts orders, owner’s manuals, software
update files, exercise guides and contact
information scan this QR code.
Or go to:
https://www.bodycraft.com/customer-support
Product Safety Information
FCC Information ……………………………………………………………
Product Safety ……………………………………………………………
Product Overview
Product Overview Components & Tools for Assembly .………………
Hardware Identification Chart ..................................................….……
Assembly Parts ……………………………………………………………
Shipping Boxes and What’s Inside Each One …………………………
How Assemble the Recumbent Bike
Product Assembly Instructions ..........................................………….
Operation Instructions
Operating Instruction …………………………………………………….
Cleaning your Bike ……..………………………………………………..
Heart Rate Monitoring Grips & Wireless Receiver ……………………
Erratic Heart Rate Readings & Exercise Tips …………………………
Installation Checklist …………………………………………………….
Energy Saving Function: These consoles are equipped with a power saving
function. This means after 10 minutes of inactivity, it will automatically power off.
Press any key on the console for X-9LCD or touch the screen for X-10TS/X-16TS
to wake up the console from power save mode.
Page
5
6 - 7
8
9
10
11
12 - 30
31 - 32
33
34
35
36
Table of Contents
NOTE: When you have downloaded the Assembly Manual into a PDF reader, go directly
to the desired page by touching any line in this Table of Contents. BLUE
Caution: Please note that changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Maintenance & Repairs
Information Needed Prior to Contacting Customer Support ……………
Circuit Diagram ………………………………………………………………
Detailed Parts Lists ……….………………………………………….…. 3
Detailed Parts Exploded View .…………………………………….………
Warranty
Product Warranty ..........................................................….……..….…
Product Warranty Registration ............................................….…..……
Contact Us Information ……………………………………………………
Table of Contents
FCC Information
Page
37
38
39 - 40
41
42
43
44
5
NOTE: When you have downloaded the Assembly Manual into a PDF reader, go directly
to the desired page by touching any line in this Table of Contents. BLUE
Safety and Warnings - Bike
There is a risk assumed by individuals who use this type of equipment.
A moment’s lack of attention can result in an accident, as can failure to
observe certain simple safety precautions.
Read, study and understand the Assembly Instructions and all the warning labels on this
product. Furthermore, it is recommended to familiarize yourself and others with the proper
operation and workout recommendations for this BODYCRAFT product prior to use.
● We recommend that two people be available for moving and assembly of this product.
● Keep children away from the . Do not allow children to use or play on the Bike Bike.
● Keep children and pets away from the when it is in use.Bike
● It is recommended that you place this exercise equipment on an equipment mat.
● Set up and operate the on a solid level surface. Do not position the on loose Bike Bike
rugs or uneven surfaces.
● Inspect the for worn or loose components prior to use.Bike
● Tighten/replace any loose or worn components prior to using the Bike.
● Always choose the workout which best fits your physical strength and flexibility level. Know
your limits and train within them.
● Always use common sense when exercising.
● Keep hands, limbs, loose clothing and long hair well out of the way of moving parts.
● Do not wear loose or dangling clothing while using the Bike.
● Never exercise in bare feet or socks; always wear correct footwear, such as running,
walking, or cross-training shoes.
● Be careful to maintain your balance while using, mounting, dismounting, or assembling the
Bike. Loss of balance may result in a fall and serious bodily injury.
6
Safety and Warnings - Bike
● Keep both feet firmly and securely on the Foot Pedals while exercising.
● This should not be used by persons weighing over 400 pounds /181 kgs.Bike
● The should be used by only one person at a time.Bike
● Make sure that adequate space is available for access to and passage around the Bike;
keep at least a distance of 3 feet from any object while using the machine.
● This s designed for commercial and home usage.
Bike i
●Maintenance:
○ Replace any defective components immediately and/or keep the equipment out of use
until the equipment is completely repaired.
○ Clean seat, plastic and frame on a regular basis. We recommend warm, soapy water.
Do not use harsh or abrasive chemicals.
WARNING: Before using this product or any exercise or conditioning program, you should consult
with your personal physician to see if you require a complete physical exam. This is especially
important if you have never exercised before, are pregnant, or suffer from any illness. Follow your
physician's recommendations in developing your own personal fitness program.
READ AND FOLLOW THE SAFETY PRECAUTIONS. FAILURE TO FOLLOW THESE
INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY.
7
Product Overview Components and Tools for Assembly
COMBINATION
WRENCH (13mm / 15mm)
THE FOLLOWING TOOLS ARE FOR ASSEMBLY: INCLUDED
T-HAND SOCKET
WRENCH (17mm)
SOCKET WRENCH
(13mm)
ALLEN WRENCH
(6mm)
ALLEN WRENCH
(4mm)
8
EXTRA LONG PEDAL
WRENCHES 15mm (min 8” long)
THE FOLLOWING TOOLS ARE FOR EASIER ASSEMBLY:RECOMMENDED
SOCKET SET ⅜ drive w/ 3“ & 6”
EXTENSION for 13mm & 17mm
OPEN & CLOSED WRENCHES
for 13mm & 17mm
ALLEN WRENCHES SET
4mm to 10mm
PHILLIPS SCREWDRIVERS
#2 w/ Magnetic TIP
TORQUE WRENCH ⅜ DRIVE
w/ 4mm & 6mm Allen Sockets
Unpack the box in a clear area. Use the below to check the contents of the hardware kit. This List of Hardware
chart is provided to help identify the hardware used in the assembly process. Place the washers, the end of bolts,
or screws on the circles to check for the correct diameter. Use the ruler to check the length of the bolts and
screws.
NOTICE: The length of all bolts and screws except those with flat heads is
measured from below the head to the end of the bolt or screw. Flat
head bolts and screws are measured from the top of the head to the
end of the bolt or screw.
Please review below to know the content of the hardware kit.
If a part is not in the hardware bag, check to see if it has been preassembled..
Hardware Identification Chart
9
Unpack the box in a clear area. Follow the below to check and make sure all assembly parts are List of Assembly Parts
present and in good condition. Do not dispose of the packing material until the assembly process is completed. Assembly
tools and hardware kit have included for you to use when assembling the product
Assembly Parts
NOTE: 9” LCD Console will NOT REQUIRE the Power Adaptor (151) & Power Cord (153) for use. The
Power Adaptor (153) & Power Cord (153) are REQUIRED for the 16” & 10” Touch Screen Consoles or
charging the battery, if needed, for the 9” LCD console.
(12DC / 3A)
10
