Sida 1/1
DocID: 420102_19.05.2021
Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • Germany • www.thomann.de
Features
The DMX splitter is equipped with a DMX input and
two DMX outputs.
2-way DMX splitter
1 × DMX input
2 × DMX output
Connections galvanically isolated
RDM capable
Protocols: DMX 512 and RDM
XLR in / out: 3-pin / 5-pin
EU safety plug with xed cable (approx. 1.3m)
Technical specications
Input connections: 2×DMX / RDM in,
XLR chassis plug,
1×3- and 5-pin each
Output connections: 4×DMX / RDM out,
XLR chassis socket,
2×3- and 5-pin each
Control protocols: DMX-512/RDM
Supply voltage: 230V~, 50Hz
Power consumption: 7.5W max.
Fuse: 5mm×20mm,
1A, 250V, fast-acting
Mounting options: wall mounting
Dimensions (W×H×D): 220×63×132mm
Weight: 1.10kg
Ambient conditions
%
nsing)
Safety instructions
Intended use
This device is meant to be used to distribute one DMX / RDM signal to
two units. Any other use or use under other operating conditions is con-
sidered to be improper and may result in personal injury or property
damage. No liability will be assumed for damages resulting from improper use.
Dangers for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard! Ensure that children
do not detach any small parts (e.g. knobs or the like) from the unit. They could
swallow the pieces and choke! Never let children unattended use electrical de-
vices.
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt,
and strong vibrations.
Protecting the environment
For the transport and protective packaging, environmentally friendly
materials have been chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of. Do not
just dispose of these materials with your normal household waste, but make
sure that they are collected for recycling. Please follow the notes and markings
on the packaging.
This product is subject to the European Waste Electrical and Electronic
Equipment Directive (WEEE) in its currently valid version. Do not dispose
of your old device with your normal household waste. Dispose of this
product through an approved waste disposal rm or through your local
waste facility. Comply with the rules and regulations that apply in your country.
If in doubt, consult your local waste disposal facility.
EN
DD-2 RDM | DMX-Splitter
