Bowers Wilkins Formation Flex Bruksanvisning

Bowers Wilkins högtalare Formation Flex

Läs nedan 📖 manual på svenska för Bowers Wilkins Formation Flex (76 sidor) i kategorin högtalare. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/76
2
ENGLISH
www.bowerswilkins.com
Welcome to Bowers & Wilkins and Formation Flex.
Thank you for choosing Formation. When John Bowers rst established Bowers
& Wilkins he did so in the belief that imaginative design, innovative engineering
and advanced technology were keys that could unlock the enjoyment of audio
in the home. That belief continues to inspire every product we design and in
Formation has found its most advanced expression yet.
Formation Flex is a network connected, wireless active speaker that provides
extremely high performance reproduction of Formation audio streams. Formation
Flex is primarily intended to be congured and controlled using the Bowers &
Wilkins Home app. The app is available for both iOS and Android devices. Some
commonly used control functions are also available via touch buttons on the
Formation Flex top panel. It is only possible to install and congure a Formation
Flex using the Bowers & Wilkins Home app.
Formation Flex will enable you to:
• Listen to audio from streaming services like Spotify, Apple Music, and Roon.
• Listen to network stored audio les.
• Listen to audio over Bluetooth from appropriately enabled Bluetooth
source devices.
• Listen to audio from devices such as turntables (via a phono preamp) and
CD players that are connected to a Bowers & Wilkins Formation Audio.
• Listen to audio, such as Internet Radio, from Airplay or Bluetooth
compatible services and apps.
• Listen to audio playing anywhere in your home on any Formation device
connected to your home network.
The Bowers & Wilkins Home app is required to connect your Formation Flex
to your home network and also to establish a connection with other Formation
products in your home. The Bowers & Wilkins Home app also provides some
control and conguration functions during use. Before you begin your Formation
Flex installation please download and install the Bowers & Wilkins Home app on
your iOS or Android device. The Bowers & Wilkins Home app requires iOS V11.4
or later, or Android V8.1 or later. Bluetooth, and WiFi services must be enabled
on your iOS or Android device. You will also need to know your WiFi network
password.
Note: Location Services must be enabled on Android devices during the
Formation setup process. This is because Formation products use a low power
form of Bluetooth (BT-LE) for service communication which on Android devices is
only switched on when Location Services are enabled. Bowers & Wilkins do not
use any location services data for marketing purposes.
ENGLISH
Contents
ENGLISH 2
1. Formation Flex Carton Contents 3
2. Installing Your Formation Flex 3
3. Using Your Formation Flex 5
4. The Bowers & Wilkins Home App 6
5. Formation Music Streams and Sources 6
6. Cleaning 6
7. Support 6
3
ENGLISH
1. Formation Flex Carton Contents
Formation Flex
Mains power cable set appropriate for your territory
Document pack
2. Installing Your Formation Flex
Formation Flex can be used in a range of situations
— as a single mono speaker, as a compact stereo
pair, or as rear surround speakers in a 5.1 home
theatre setup.
When used as a stereo pair, your Formation Flex
should be at least 1m (3ft) apart and a similar
distance from the listening area. If the speakers
are positioned too close together, the stereo
reproduction may lack scale; if they are too far
apart, the stereo focus may be weak. There is no
need to angle your Formation Flex inwards towards
the listening area however doing so may tighten
the stereo focus. Diagram 1 illustrates basic
speaker positioning.
When used as rear speakers in a 5.1 home theatre
conguration, your Formation Flex should be placed
as close to 120 degrees from the front centre
speaker as possible, as shown in Diagram 2.
Your Formation Flex requires a mains power supply
to operate so must be located within reach of a
mains socket. If your Formation Flex is to use a
wired connection to your home network it will need
to be located within reach of an appropriate network
(Ethernet) cable.
If you decide to place your Formation Flex on a
shelf, ensure that the shelf is easily able to support
the weight.
Like the vast majority of speakers, your Formation
Flex radiates sound energy not only forward but
also to the side and rear. Consequently, if your
Formation Flex is positioned close to room
boundaries, or particularly in a corner, bass may
become over emphasised. If you nd that bass
from your Formation Flex is too prominent, moving
it to an alternative position may be benecial,
however you can also adjust the bass level via
the Bowers & Wilkins Home app Settings menu.
Diagram 1
Stereo positioning
Diagram 2
Home theatre positioning
120º
1 metre

Produktspecifikationer

Varumärke: Bowers Wilkins
Kategori: högtalare
Modell: Formation Flex
