BY-HM2
Digital Handheld Microphone
Instruction Manual
1. On/O switch
2. Gain control switches for microphone and headphone
3. Indicator light
4. 3.5mm headphone monitoring jack
5. USB Type-C socket
6. USB Type-C to Lightning audio cable
7. USB Type-C audio cable
8. USB Type-C to USB-A audio cable
9. 5/8“ microphone mount
10. 3/8” to 5/8“ screw
11. Cable protector
12. Mini tripod
1. Use the USB Type-C to Lightning audio cable, cross the USB Type-C
connector side through the cable protector and plug it on the USB
Type-C socket on the bottom of BY-HM2.
3. Turn on the microphone, the LED indicator light will turn solid green.
4. Adjust the microphone gain control switch to adjust the microphone
volume to get the best recording experience.
5. Cross the earphone 3.5mm plug through the cable protector and
plug it on the earphone socket on the bottom of BY-HM2.
6. Attach the cable protector to the bottom of the microphone
7. Turn on the audio/video app that allow external microphones and
start the recording.
2. Plug the Lightning connector on the iOS devices
1. Please keep the microphone away from dust and water.
2. Please follow all the safety instruction.
3. Please put the manual in safe place if you are about to sell it
to customers.
4. Please do not replace any components inside the microphone
on your own.
5. Please keep it away from children and pets.
www.boya-mic.com
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
TEL: 400 6131096
Email: sales@boya-mic.com
www.boya-mic.com / www.jiayz.com
100x160
深圳市长丰影像器材有限公司
品牌
子件名称 版本
材质
比例
审核 暂无
吴蒙蒙
2019-8-26 核准/日期 赵宏亮
单位1:1 mm尺寸
子件编号
设计/日期
长丰型号
8
变更日期 变更担当变更内容版本修改名称
7
1 2
BY-HM2说明书
BY-HM2说明书 V01
BOYA BY-HM2
1F0300300217
V01
105g双铜纸 双面印刷 5折页
吴蒙蒙
长丰影像
2019-8-26
技术要求:
1、表面无色差
2、无正负公差
3、包装标注尺寸为内尺寸
第一页内容更改，封底加联系电话 吴蒙蒙2019-8-26
1
12
11
3
4
5
6
7
8
9
10
2
2
Principle of acoustics:
Polar pattern:
Frequency response:
Sensitivity:
Signal to noise ratio:
Plug socket:
Headphone output:
A/D:
Sampling rate:
Power requirement:
Size:
Cables included:
Cable length:
Construction:
Weight:
Working environment temperature:
Condenser
Cardioid
20-20,000HZ
-40±3dB (0dB=1V/Pa@1KHz)
85dB
Type-C
3.5mm TRS
16bit/24bit
44.1kHz,48kHz,96kHz
iOS, Android mobile devices & PC
Φ50*225mm (Φ1.9x8.8“)
USB Type-C to USB-A
USB Type-C to Lightning
USB Type-C to USB Type-C
1.2 meter
Zinc alloy
345g (12oz)
-10 -55℃ ℃
Instruction:
Android devices , Windows and Mac PC please refer to
the usage of iOS devices.
Package Content:
Specication:
Features:
Accessories instruction:
BOYA BY-HM2 is a cardioid handheld mic, which is specially designed for
mobile devices.
With USB Type-C, USB-A and Lightning audio cables all included, it
perfectly compatibles with most iOS , Android smartphones & tablets,
Windows and Mac PC etc.
With cardioid polar pattern, it greatly helps mobile devices to focus
on sound in front of the microphone and eectively reduce unwanted
background noise.
With gain control on both microphone and Headphone, it allows users to
adjust volume on both headphone and the microphone to get the best
recording experience according to dierent environment.
A mini tripod and 3/8” to 5/8” microphone mount are included as well,
which allow users to make any on desk recording like vlogging, live
streaming and music recording, or the microphone could be mounted
on any professional microphone stand with 3/8“ or 5/8” male screw,
perfect for live, speech and studio recording etc.
On the bottom of the microphone, there is an interchangeable USB
Type-C socket that allow BY-HM2 to be used with dierent devices via
dierent cables, the otherside is a buit-in 3.5mm headphone output
jack, and no latency headphone monitoring is allowed.
To protect earphone cables and audio cables in chaos environment, in
the BY-HM2 kit, a very considerable cable protector will be included to
protect cables from damaging.
- BY-HM2 microphone
- USB Type-C to Lightning audio cable
- USB Type-C to USB-A audio cable
- USB Type-C audio cable
- Microphone mini tripod
- A 3/8” to 5/8” microphone mount
- Cable protector
- Carrying Pouch
- Manual
Please noted that Android built-in camera do not allow external
microphone, when you using this microphone on Android devices,
a third party audio/video App need to be download before you
start recording.
For some applications,they do not allow no latency headphone
monitoring.So if you found the sound could not be monitored while
you are recording, please kindly check all the settings on your
application and see if no latency sound monitoring is supported.
Insert the 3/8” screw to the 5/8” screw on the bottom of the
microphone mount
Put the microphone on the microphone mount
Lock the microphone mount on the mini tripod
Take out the 3/8” screw from the 5/8” mount
Lock the microphone mount on any 5/8” microphone stand
Put the microphone on the microphone mount
Tips and notes:
Main features:
How to use BY-HM2 handheld mic with iOS devices:
Put the microphone on other stand with 5/8” mount
- High quality handheld digital condenser microphone
- USB Type-C, USB-A, Lightning audio cables all included
- Compatible with iOS, Android mobile devices, Windows and Mac PC
- Intergrated gain control switches for microphone and headphone
- Mini tripod, 3/8“ to 5/8” microphone mount included
- Zinc alloy construction
