BOYA BY-M1000 Pro Bruksanvisning
Läs nedan 📖 manual på svenska för BOYA BY-M1000 Pro (12 sidor) i kategorin mikrofon. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/12
BY-M1000 Pro
Large Diaphragm
Condenser
Microphone
大振膜电容式麦克风
• BY-M1000 microphone Pro
• Pop lter
• Shockmount
• 3m(10ft) balanced XLR cable
Instruction
General Functions
Polar Patterns
Contents
Thanks for purchasing BOYA BY-M1000 Pro!
The BOYA BY-M1000 Pro is a 34mm(1.3") diaphragm condenser microphone,
with sturdy all-metal housing, three selectable polar patterns, and a -10dB
output pad. The microphone is suited for capturing instruments and vocals in
project and professional recording applications, such as singers, songwriters,
podcasters, voiceover artists, eld recorders, and home studio recordings.
Additionally, the microphone oers a 20 Hz to 20 kHz frequency response for
accurately reproducing audio signals in a variety of ranges. The microphone
uses standard 24V or 48V phantom power, which is supplied through the
standard XLR connector.
Cardioid
The cardioid polar pattern is focusing audio capture in front of the capsule,
minimizes unwanted ambient sound from the other sides and back of the
microphone. This polar pattern is suitable for such situations when you
want to pick up specic sund sources, such as recording vocals, guitar,
pianos, stringed instruments, and more.
High-Pass Filter
A -10 dB Pad Switch
Omnidirectional
The omnidirectional polar pattern will in principle pick up sound equally from all
directions. Whether the sound resource from the front, the side, or even back, the
microphone will record the signals all with equal gain. This polar pattern can be
very useful in applications where sound needs to be recorded from multiple
directions, such as a musical performance where there is a band of musical
instruments in front and a choir singing behind.
Bidirectional
Bidirectional polar pattern is gure-of-eight pattern and picks up sound equal
sensitivity from two opposite directions, front and back of the microphone,
and with low sensitivity from the sides. This polar pattern is best suited for
interview, Q&A lecture or presentation, acoustic instruments, and for live
recordings of jazz and acoustic groups.
Sounds that are 120Hz or lower will be ltered.
The audio will be recorded in -10dB if it is enabled in case the recording gets
distorted due to loud sound sources, or the subject's voice is not clearly heard
due to ambient noise.
Produktspecifikationer
| Varumärke: | BOYA |
| Kategori: | mikrofon |
| Modell: | BY-M1000 Pro |
