BY-M800
Cardioid Condenser Microphone
Cardioid
Instruction Manual
Thanks for purchasing BOYA BY-M800!
• BY-M800 condenser microphone
• Studio-grade pop shield
• Shockmount
• 3m(10ft) balanced XLR cable
3. Mounted the supplied pop lter in front of microphone.
4. Insert supplied XLR cable to microphone
Instruction:
1. Mount BY-M800 on 3/8" and 5/8" microphone stands
or tripods.
2. Rotate locking knob to adjust microphone ts your
position.
Note:
When changing the mic position, always be sure to loosen
the adjustment knob rst to ensure you do not damage
the shock mount.
How to use it
Note:
When recording any sound source, whether it be vocals,
instruments or anything else, always spend time
experimenting with microphone placement to ensure you
are picking up the best possible sound. Adjust the
microphone position as many times as you need to
achieve your demand.
General Functions
- Polar Pattern
- High-Pass Filter
- A -10 dB pad switch
Contents:
BOYA BY-M800 is a large cardioid diaphragm condenser
microphone with a smooth, at, wide-range frequency
response, it’s perfect for for vocal and general instrument
capturing in project and professional studio environments.
It's featured with a cardioid pattern rejects o-axis sound,
-10dB switch and 2-position low-cut lter switch.
Features
Polar Pattern
Frequency Response
• Large gold-sputtered diaphragm
• Great for studio and broadcast
• Flat, wide-range frequency response
• Cardioid pickup pattern
• Controlled by low-cut lter switch
• A selectable -10dB pad
• Included shockmount & pop lter
• 24V or 48V phantom power
• Standard XLR connector
• 3m(10ft) XLR cable included
• Included 3/8" and 5/8" thread
The microphone is with all sturdy metal construction
housing design, and uses standard 24V or 48V phantom
power, which is supplied through the standard XLR
connector. A shockmount, pop lter, and 3m(10ft) case
are all included.
Cardioid
The cardioid polar pattern is focusing audio capture in
front of the capsule, minimizes unwanted ambient
sound from the other sides and back of the microphone.
This polar pattern is suitable for such situations when
you want to pick up specic sund sources, such as
recording vocals, guitar, pianos, stringed instruments,
and more.
A low-cut lter at 150 Hz allows you to eliminate low
frequency hum and other low-frequency noises.
A -10 dB pad switch provides more headroom when
capturing transient signals that may otherwise cause
peak distortion.
Specications:
www.boya-mic.com
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
Email: sales@boya-mic.com
www.boya-mic.com / www.jiayz.com
Maintaining Your Microphone
• Keep your microphone away from dust, moisture, or water.
• To clean the housing, wipe with a dry micro-ber cloth to
remove dust.
• Store your microphone in the included pouch to protect it
from dirt and dust.
Important Safety Information
• Make sure that you follow all safety notes.
• Keep these instructions for use in a safe place. If you sell
the equipment or pass it on to someone else, you should
also pass on these instructions for use.
Marking on the devices
Danger of re and short-circuit
Waste disposal and protection of the environment
Electric and electronic appliances, as well as batteries, must
not be disposed of together with domestic waste. The user is
legally obliged to return electric and electronic appliances as
well as batteries to specially set up public collecting points or
the sales outlet once they have reached the end of their service
life. Details are regulated by national law. The symbol on the
product, the instructions for use, or the packaging refers to
these provisions. The recycling of waste equipment/batteries is
an important contribution to the protection of our environment.
• Do not operate the device with wet hands.
• Clean the equipment only in the way described in Maintaining
Your Microphone.
• Take care to avoid dropping the equipment. Make sure that
the device is properly fastened and reliably mounted. If the
device has been dropped, have it inspected by a skilled
technician before you switch it on again.
• Should the equipment be damaged or defective, or if you
notice a scorching smell, remove the batteries immediately.
Do not operate the device with a damaged housing and do
not repair the device yourself. Have the device only repaired
by a skilled service person.
Note:
The “BOYA” Logo on the face of the BY-M800 indicates
the front of the microphone, and the pickup area of the
capsule. The “BOYA” Logo should always be facing towards
the sound source that you wish to record.
Condenser
Cardioid
34mm(1.3" )
20– 20,000Hz
-33±3dB (0dB=1V/Pa @ 1KHz)
80dB and more
200 Ohm
24V or 48V Phantom
3m(10ft)
207 x 115 x 162mm
642g
Acoustic Principle:
Polar Pattern:
Diaphragm:
Frequency Response:
Sensitivity:
SN:
Output Impedance:
Power Requirement:
Cable Length:
Dimensions:
Weight:
100x160
深圳市长丰影像器材有限公司
品牌
子件名称 版本
材质
比例
审核 暂无
吴蒙蒙
2019-5-16 核准/日期 赵宏亮
单位1:1 mm尺寸
子件编号
设计/日期
长丰型号
8
变更日期 变更担当变更内容版本修改名称
7
1 2
BY-M800说明书
BOYA BY-M800
1F0300300153
V00
105g双铜纸 双面印刷 5折页
吴蒙蒙
长丰影像
2019-5-16
技术要求:
1、表面无色差
2、无正负公差
3、包装标注尺寸为内尺寸
