USB Microphone
Instruction Manual
BY-PM700
Introduction Introduction
Instructure Features: How to use
Set Up for Windows 8 Setup for Apple System
Specications:
Package Contents
Rear
Bottom
Front
Thanks for choosing BOYA!
The BOYA BY-PM700 is a USB condenser microphone, and compatible
with Windows and Mac Computers. Its polar pattern knob lets you opt
for omni-directional, Cardiod, Stereo and bi-directional pickup modes,
suit for verious situations, such as recording, interviews, conference
calls, vocals, instruments, podcasting and more.
1. Connect the BOYA BY-PM700 to an un-used USB port on your computer.
2. Go to Apple Icon-->System Preferences-->Sound Icon.
3. Select “BY-PM700” under “Input” tab.
IMPORTANT
• If you do not intend to use the conference microphone for
a long period time, please remove the USB cable.
• Do not touch the microphone while recording, as this will
cause noise to be recorded.
• Do not let the microphone close to high-voltage equipment
or to devices that emit strong electromagnetic elds,
otherwise, it may cause the noise to be recorded.
• Do not use or leave the microphone in hot, humid places.
4. Select “BY-PM700” under “Output” tab.
• Compatible with Windows and Mac Computers
• Triple-capsule design
• Stereo, cardioid, omnidirectional, and bi-directional polar patterns
• 16 Bit/48 kHz Resolution
• Muting function
• 1/8" Headphone Monitoring Jack
• Latency-Free Monitoring
• Desktop Stand
• Durable all metal construction
• Intergrated USB cable
1. Connect microphone with a USB port on your computer using
the supplied USB cable.
2. From the “Setting Menu”, select the “Control Panel”.
3. Go to “Control Panel” , select “Hardware and Sound”
5. Select “Speaker BY-PM700” as the default device in the “Sound”,
under “Playback” manu.
6. Select “Microphone BY-PM700” as the default device in the “Sound”,
under “Recording” manu.
4. Select “Sound”
1. Connect microphone with a USB port on your computer using the
supplied USB cable.
2. Go to “Setting”, choose “Sound” as shown below.
3. Select “Speaker BY-PM700” as Output device.
4. Select “Microphone BY-PM700” as Input device.
1. Unscrew the knobs of both sides at anti-clockwise.
2. Adjust the microphone at your desired angle, then screw the knobs of
both sides at anti-clockwise to x the microphone.
3. Plug the mini USB of supplied cable into the USB port of microphone,
and conect the other plug into the available USB prot of your computor.
4. Connect your headphone to 3.5mm headphone output if needed.
Set Up for Windows 10
14 mm(0.55")
20-20,000Hz
-45dB±3dB@1KHz
5V/150mA
48 kHz
16 Bit
Impedance: 16ohms
Power output(RMS): 130mW
Frequency Response 15-20,000Hz：
Micro USB
112 x 108 x 200mm(4.4 x 3.8 x 7.9”)(Min.)
112 x 108 x 295mm(4.4 x 3.8 x 11.6”) (Max.)
1042g(36.8oz)
Diaphragm:
Frequency Response：
Sensitivity：
Power Consumption:
Sample Rate:
Bit Depth:
Headphone Amplier:
Plug:
Size:
Weight:
1. Tri-Capsule Array
2. Power Indicator
3. Mute Button
Press mute button, when LED indicator is red, muting function on.
4. Headphone Volume Control
5. Screws
6. Desk Stand
7. Microphone Gain
8. Stereo Pattern
Pick up the sound from left and right side, it is ideal for capturing a
realistic, general sound.
9. Cardioid Pattern
Maximizes the rejection of sound coming from the sides and rear of the
mic and can be used as a directional microphone to capture full, rich,
natural-sounding audio for podcast, speech, dialog, instrument etc.
10. Omnidirectional Pattern
Pick up sound equally from all directions, capturing a natural blend of
voice and ambiance with low sensitivity to wind and handling noise, as
well as to vocal plosives.
11. Bi-directional Pattern
Pick up sound at the front and rear of the microphone, while sounds to
the sides are not picked up, it ts for capturing instruments, or recording
an interview between two people.
12. Mini USB Connection
13. Headphone Output
14. 5/8” screw
This mic can capture your audio in up to 16 bit/48 kHz resolution, and it
features gain control, mute button, zero-latency headphone output.
This mic has durable all metal construction, includes desk stand that can
ajust microphone in various desired angles, also functionality of folding
the mic down for storage and transport as well.
• BY-PM700 Microphone
• USB Cable
• User Manual
www.boya-mic.com
1 2 3 4 5
6 7 8 9 10
• Do not operate the device with wet hands or feet.
• Clean the equipment only in the way described in the
instructions for use.
MAINTENANCE
SHENZHEN JIAYZ PHOTO INDUSTRIAL., LTD.
The BOYA logo is a trademark which is registered and owned by
Shenzhen Jiayz Photo Industrial., Ltd.
COPY RIGHT 2010-2020
Email: sales@boya-mic.com
www.boya-mic.com / www.jiayz.com
