Sida 1/49
PavilionTM 65-
G
3
Canadian User Guide
Guide d’utilisation canadien
24 in.
9
9
LOCKING
TAB
CLAMP
1
2
LOCKING
TAB
CLAMP 1
VEHICLE
BELT
2
• Check that your vehicle belt is compatible for use with child
seats. See pages 6 – 8 for more information.
• Remove the Versa-Tether from the pouch and place it up and
over the child seat back.
* The Versa-Tether must be used at all times. Using the tether will
improve the stability of the child seat and reduce the risk of injury.
Check your vehicle owner’s manual for tether anchor locations.
Only attach the Versa-Tether to anchor points designated to the
chosen seating position as indicated by your vehicle owner’s
manual.
• Adjust this child seat to position 1 or 2 and place forward-facing
on the vehicle seat (see page 15).
* Ensure that no more than 20% or 7.6 cm (3 in.) of the base hangs
over the edge of the vehicle seat.
IMPORTANT:
• use lock-offs for lap belt installations.
rward-Facing Installation
WARNING!
• Your child seat may not perform as intended if the base of the child
seat is not flat on the vehicle seat.
• Some vehicle head restraints may obstruct the harness adjuster from
reaching the highest position. If this is the case, you may need to raise
or remove the vehicle head restraint.
force the child seat head restraint past the vehicle
head restraint. Doing so could cause the child seat
not to perform as intended.
• HUGS chest pads must be used when the child
seat is installed in forward-facing mode.
This child seat is certified for aircraft use. Most airlines
in Canada and the U.S. will allow the use of a child
seat as long as it is labeled as an approved child seat
for use in aircraft and fits properly on the aircraft seat.
Contact the airline about their policy prior to traveling.
The FAA recommends that a child weighing up to
18.1 kg (40 lbs) use a certified, harnessed child seat
while traveling on an aircraft.
Install your child seat in a window seat to
avoid blocking the aisle.
Rear-Facing Installation
For rear-facing aircraft installation (Fig. A),
follow Rear-Facing Lap Belt Installation
instructions on pages page 24 – 25.
Forward-Facing Installation
For forward-facing aircraft installation (Fig.
B), follow Forward-Facing Lap Belt Installation
instructions on pages page 30 – 31.
If the aircraft lap belt is too short, ask a flight
attendant for a belt extender.
NOTE: Your child may experience discomfort
if the buckle is located in the seating area of
the child seat after installation.
Aircraft Installation
WARNING!
• Adjust the belts provided with this child seat so they fit snugly
around your child. A snug strap should not allow any slack.
It lies in a relatively straight line without sagging. It does not
press on the child’s flesh or push the child’s body into an
unnatural position.
• Adjust the harness to fit the clothes the child is wearing.
Remove bulky coats and/or jackets before putting the child
in the child seat.
• The HUGS™ chest pads must be used at all times when
installing the child seat forward-facing.
• Verify that the child seat is secure and the harness is properly
adjusted around the child time the child seat is used.each
Before You Begin:
• Follow the instructions on page 13 to make the proper
adjustments to the harness and buckle.
WARNING!
Inflatable lap belts are compatible with this child seat.NOT
A
b
34
re and Maintenance
1 Loosen the harness.
2 Open the chest clip.
3 Unbuckle the harness.
4 Remove the infant body pillow
if necessary.
5 Remove the belly pad and
buckle.
2a
2b
Removing the Cover
Never remove the buckle tongues from the harness.
They cannot be reattached after removal. If reassembled
incorrectly, the child seat may not perform as intended .
1a
1b
36
re and Maintenance
Replacing the Cover
Cleaning the Cover
• HAND WASH the cover using cold water and mild soap.
• LINE DRY to prevent the cover from shrinking.
• DO NOT:
* Bleach
* Machine wash
* Machine dry
* Iron
Cleaning the Harness
• SPONGE CLEAN the harness using warm water and mild soap.
• TOWEL DRY
• DO NOT:
* Disassemble the harness
* Bleach
* Machine wash
* Machine dry
* Iron
Cleaning the Shell
• SPONGE CLEAN the shell using warm water and mild soap.
• TOWEL DRY
• DO NOT use abrasive cleaners
2 Attach the plastic hooks
behind the head restraint to
the child seat.
3 Replace the belly pad and
buckle:
a Turn the buckle retainer sideways
and route it through the belly
pad.
b Route the belly pad and buckle
retainer through the buckle slot
in the cover.
* Ensure that the buckle is through
the correct cover slot for the
desired buckle position.
1 Fit the child seat cover around
the child seat shell.
1
2
3a
38
re and Maintenance
WARNING!
• HUGS chest pads must be used when the child seat is installed
in forward-facing mode.
• HUGS chest pads MUST be removed when a snug
harness cannot be achieved in rear facing for small infants
(approximately 3 months old or younger).
1 Loosen the harness.
a Lift the harness adjuster lever
located under the cover flap
b Grasp the chest clip and pull
outward
* Connect the chest clip for easier
adjustment.
2 Open the chest clip.
a Press tabs
b Pull apart
5 Pull the HUGS strap through
the opposite harness slot to
the front of the seat.
3 From the back of the HUGS
chest pad, angle the strap
retainer and route it through
the slot in the HUGS chest
pad and out through the top to
remove the HUGS strap.
4 Pull the HUGS strap out
through the harness slot to the
back of the seat and unhook
it from the HUGS clip on the
back of the seat.
Removing the HUGS™ with SafeCell Technology ®
1a
1b
40
re and Maintenance
Replacing the HUGS™ with SafeCell Technology ®
6 Connect the HUGS strap
to one HUGS chest pad by
routing the retainer through
the slot at the top of the HUGS
chest pad and then through
the slot at the bottom ensuring
that it is properly seated on
the back.
2 Open the chest clip.
a Press tabs
b Pull apart
3 From the back of the seat,
unhook the harness straps
from the yoke.
4 Pull the harness straps
through the harness slots to
the front of the seat.
5 Remove the chest clip and the
comfort pads.
1 Loosen the harness.
a Lift the harness adjuster lever
located under the cover flap
b Grasp the chest clip and pull
outward
* Connect the chest clip for easier
adjustment.
WARNING!
• HUGS chest pads must be used when the child seat is installed
in forward-facing mode.
• HUGS chest pads MUST be removed when a snug
harness cannot be achieved in rear facing for small infants
(approximately 3 months old or younger).
1a
1b
42
re and Maintenance
Cleaning the Buckle
If your child eats and drinks while in the child seat, you will need
to check the buckle periodically and rinse out any accumulated
debris.
Removing the Buckle
1
a Lift the cover from the seat
front to find the buckle strap
connection.
b Remove the buckle strap by
turning the buckle retainer
sideways and routing it out of the
front buckle slot in the child seat.
c Slide the end of the belly pad out
from under the foam pad on the
seat.
d Pull the end of the belly pad
and buckle retainer out of the
slot in the cover to remove.
e
