Sida 1/10

Not all models are available

in all countries.

Quick Setup Guide

ADS-4100/ADS-4300N/ADS-4500W/ADS-4700W/ADS-4900W

Please read the , located later in this document before you set up your machine.Product Safety Guide

WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in

death or serious injuries.

Unpack the machine and check the components

The components included in the box may differ depending on your country. Remove the protective tape

and lm covering the machine. Open the Front Cover and Roller Cover, and then remove the protective

tape.

Prepare your machine

• This product is packaged in a plastic bag. To avoid

suffocation, keep plastic bags away from babies and

children. The bag is not a toy.

• Use only the AC adapter supplied with this product.

Automatic Document

Feeder (ADF)

AC Adapter USB Interface

Cable

WARNING

Select your language (ADS-4500W/ADS-4700W/ADS-4900W only)

Press > > and select your language. Press .[Settings] [Initial Setup] [Local Language]

Attach the Automatic

Document Feeder (ADF)

rmly until it locks into place.

Connect the AC adapter. Extend the trays.

The latest manuals and FAQs are available at the Brother support website: support.brother.com.

Quick Setup

Guide/Product

Safety Guide

We recommend saving the original packaging in case

you must ship your machine.

NOTE

When loading a document, always fan the paper and align its edges before loading it into the Automatic Document

Feeder (ADF).

NOTE

Secure Network Access

Your machine’s default password is on the label on the

back of the machine (preceded by “Pwd”). We strongly

recommend you change it to protect your machine

from unauthorised access.

Unless otherwise specied, illustrations in this guide show the ADS-4300N.

Manual Wireless Setup (ADS-4500W/ADS-4700W/ADS-4900W only)

If you do not have a computer connected to the network or if you cannot connect your machine using your computer, try to set up the

connection manually.

1. Press > [Find Wi-Fi

Network] [Yes] > .

2. Select the SSID (Network

Name).

Enter the Network key

(Password).

When the wireless setup is

successful, the LCD displays

[Connected].

If you cannot nd your SSID or

Network key, ask your network

administrator or wireless access

point/router manufacturer.

NOTE

• If setup is not successful, restart your machine

and the wireless access point/router, and then

repeat these steps.

• If using a computer, go back to A to install

software.

Using your machine with your computer or mobile device

Visit setup.brother.com to download and

install Brother software.

Follow the on-screen

instructions to continue

installation.

Finish

setup.brother.com When nished, restart your computer.

• To check for the latest rmware, visit

support.brother.com/up7.

• If not successful, try to set up the

connection manually.

For detailed scanning instructions,

see the at Online User’s Guide

support.brother.com/manuals.

For Mac: Visit support.brother.com/mac to

download Brother software.

LED Indications (ADS-4100/ADS-4300N only)

Connect your machine and install software

Select your preferred scanning method and choose your connection method.

Using your machine as a standalone device (ADS-4300N/ADS-4500W/ADS-4700W/

ADS-4900W only)

Connect your machine to your network using a network cable (purchased separately) or via Wi-Fi

®.

You can set up your Wi-Fi connection either using the machine's control panel or using your computer.

If setup is not successful, visit support.brother.com for FAQs, Troubleshooting, and manuals.

NOTE

Off

Lit

Blinking

Machine Status

Ready

(Blinking slowly)

Sleep

Error Status

• Document Jam

• Document Pick Up Error

• Front Cover Open

• Multifeed Detection Error

(ADS-4300N only)

• Access Error

• Scheduled Maintenance

Notication

• Pick Up Roller

Replacement Notication

For more information about troubleshooting your machine, see the Online User’s Guide.

For Mobile Devices:

• Set up the connection

manually.

• You can also connect

to your machine if it is

connected to your router/

access point using a

network cable (purchased

separately). For more

information, see the Online

User's Guide.

Symbols and conventions

used in this guide

The following symbols and conventions are used

throughout this guide:

WARNING

WARNING indicates a potentially hazardous situation

which, if not avoided, could result in death or serious

injuries.

CAUTION

CAUTION indicates a potentially hazardous situation

which, if not avoided, may result in minor or moderate

injuries.

IMPORTANT

IMPORTANT indicates a potentially hazardous situation

which, if not avoided, may result in damage to property

or loss of product functionality.

NOTE

NOTE tells you how you should respond to a situation

that may arise or give tips about other scanning

features.

Prohibition icons indicate actions that must not

be performed.

This icon indicates that ammable sprays may

not be used.

This icon indicates that organic solvents, such as

alcohol or other liquids, may not be used.

Electrical Hazard icons alert you to possible

electrical shocks.

Fire Hazard icons alert you to the possibility of

re.

Unplug icons indicate that you should unplug the

machine.

(ADS-4500W/ADS-4700W/ADS-4900W only)

Courier

New

Text in Courier New font identies

messages on the LCD of the machine.

Follow all warnings and instructions marked on the

machine and AC adapter (from now on collectively

referred to as “the unit”).

The illustrations in this guide show the

ADS-4300N.

NOTE

Compilation and Publication

Notice

This manual has been compiled and published to

provide the latest product safety information at the

time of publication. The information contained in this

manual may be subject to change.

For the latest manual, please visit us at

support.brother.com/manuals.

Choose a safe location for the

unit

Put the unit on a at, stable surface that is free from

shocks and vibrations, such as a desk. Choose a

dry, well-ventilated location where the temperature

remains between 5°C and 35°C and the humidity is

between 20% to 80% (without condensation).

WARNING

DO NOT expose the unit to direct sunlight,

excessive heat, open ames, corrosive gasses,

moisture or dust. DO NOT place the unit on a

carpet or rug, as this will expose it to dust. Doing

so may create a risk of an electrical short or re.

It may also damage the unit and/or render it

inoperable.

Product Safety Guide

Produktspecifikationer

Varumärke:	Brother
Kategori:	Scanner
Modell:	ADS-4500W
Plattform:	PC, Mac
Kompatibla operativsystem:	Windows 7 Ultimate, Professional, Home Premium\nWindows Vista Ultimate, Business, Home Premium (SP 2)\nWindows XP Professional, Home Edition (SP 3)\nMac OS X v10.6\nMac OS X v10.5.7
Mac-kompatibilitet:	Ja
Minimal processor:	Pentium III 700 MHz/PowerPC G4 867 MHz+
Minsta RAM:	256 MB
Antal licenser:	1 licentie(s)
Rekommenderad processor:	1 GHz+/Intel-based Mac
Rekommenderat RAM:	2048 MB
Mjukvaru-version:	11
