Plustek OpticPro A360 Plus Bruksanvisning
Läs nedan 📖 manual på svenska för Plustek OpticPro A360 Plus (2 sidor) i kategorin Scanner. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/2
OpticPro A360 Plus
OpticPro A360 Plus
OpticPro Series
New resolution for
hyper-speed for A3 size
large format document scanning!
The Plustek OpticPro A360 Plus is a high speed, 300 dpi scanner that can scan an A3 sized page in 2.48 seconds.
It is ideal for graphic designers, publishing companies, libraries, schools, small oce/home oce (SOHO) users
and others that require high speed, large format scanning.
KEY FEATURES
•Large format scanning area (A3 size, 304.8mm x 431.8mm or 12” x 17”)
• Hi-speed scanning
• One-touch button design to personalized the program
• Compatible with most imaging applications
• User-friendly software bundled
www.plustek.com
SEARCHABLE
A3
AUTO
DESKEW
AUTO
CROPPING
DESCREEN
2.48
sec
Image Sensor CCD
Optical Resolution 600 dpi
Scan Modes Color: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
Color Depth Input 48-bit; Output 24-bit
Scanning Speed 2.48 sec (Color mode, 300dpi, A3)
1.65 sec (Grayscale/ B&W mode, 300dpi, A3)
Scanning Area (W x L) Max. 304.8 mm x 431.8 mm (12" x 17"), A3
Daily Duty Scan ( Sheets ) 2,500
Action Button Scan, OCR, Copy, File, Email, Custom1 & Custom2
Power Supply 24 Vdc/ 1.25 A
Power Consumption < 24 W (operation), < 8 W (idle)
Interface USB 2.0
Net Weight 7.5 Kgs (16.52 Lbs)
Dimensions (W x D x H) 623 x 400 x 140 mm (24.53” x 15.75” x 5.51”)
Protocol TWAIN Compliant, WIA
OS Windows 7 / 8 / 10 / 11
Linux*[2]
Specication
© 2021 by . All rights reserved. All registered trademarks are the property of their respective owners. 258AE-00103
Hardware Requirements
2.0 GHz CPU processor or higher[1]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more, A3 size@1600 dpi scanning, allocated
20 GB Virtual Memory at minimum)
6 GB of hard-disk space for program installation
Display dimensions of 1024x768 or greater
SOFTWARE
Button utility to simplify document scanning. DocAction enables you to
specify your personalized scanning conguration settings and scan
documents with the click of a button. Scanned documents are
automatically sent directly to Printer, Email, Folder or FTP. DocAction
also enables you to scan directly to many imaging and document
management applications. DocAction saves scanned documents in all
common imaging formats including JPEG, TIFF, and PDF.
Built-in OCR
Plustek OCR
[1]
Plustek OCR (Powered by ABBYY® FineReader®) helps to convert
scanned paper documents, photos, and PDF les into editable formats.
With Plustek OCR, you can convert paper documents to editable
formats, including Microsoft® Word®, and Excel®, edit resulting
documents, and reuse their text and other content.
Plustek OCR
[1]ABBYY™ FineReader™ © ABBYY. OCR by ABBYY. ABBYY and FineReader are trademarks of ABBYY Software, Ltd. which may be registered in some jurisdictions.
Any other products or company names appearing in this document are the trademarks or registered trademarks of the respective companies.
[2]Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
The Plustek OpticPro A360 Plus is designed to meet the most
demanding large format scanning requirements. It features 600 dpi
resolution and can scan an A3 size (304.8 x 431.8 mm / 12” x17”) size
page.
ns simplify scanning tasks and increase scanning
cy. All scanning is done using the scanner buttons.
o go back and forth between your computer screen
scan additional pages.
431.8 mm
304.8 mm
(17”)
(12”)
Industry standard TWAIN an icrosoft Office file formats ensure
compatibility with thousands of scanning and imaging programs. Built in Plustek OCR (Powered by ABBYY® FineReader®)
allows you to convert files into editable and searchable.
Large Format Scanning
Easy to Use
t Imaging Application
Color Dropout
Auto Rotate
Descreen Filter
Auto Crop & Deskew
AAAA
AAAA
Auto Mode
Auto Threshold
Automatically straightens and crops
image to the documents actual size.
Automatically rotates document based
on the contents of the document.
Automatically thresholds the current
image into a binary black and white
image.
Automatically detects document color and scans document in
color, grayscale or black & white mode.
Removes red, green or blue color when scanning forms.
Removes moiré pattern when scanning newspaper or magazine.
Norma canl S
With Co e ionAuto lor D tect
FEATURES
Multi-Image Output
Scans and saves documents in 2 or 3 color modes at same time.
Supports document
scanning up to A3 size.
2.48 fast scanning speed for
color scans at 300 dpi A3
size.
Automatically straightening an
image that has been scanned,
to make the scanning job
more pleasant and enjoyable!
Single touch buttons simplify
your scanning work and
increase efficiency.
Provide automatically removal
of the outer parts of scanned
image, to improve framing
without using any extra image
editing software.
Save paper documents as
searchable PDFs at the touch
of a button and find your
information faster.
2.48
sec
Produktspecifikationer
| Varumärke: | Plustek |
| Kategori: | Scanner |
| Modell: | OpticPro A360 Plus |
