Quick Setup Guide

Read the Product Safety Guide Quick Setup Guide ﬁrst, then read this for the correct installation procedure. D02CPT001-00

ASA

Version 0

1Unpack the machine and check the components

Remove the protective tape or ﬁlm covering the machine and the supplies. The components included in the box may differ depending on your country.

DCP-J1700DW

DCP-J1800DW

NOTE

• Save all packing materials and the box in case you must ship your machine.

• You must purchase the correct interface cable for the interface you want to use.

USB cable

Use a USB 2.0 cable (Type A/B) that is no more than 2 metres long.

Ethernet (Network) cable

Use a straight-through Category 5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX

Fast Ethernet Network.

NOTE

You can adjust the control panel angle

to read the LCD more easily.

The latest manuals are available at the Brother support website:

support.brother.com/manuals

Video setup instructions:

support.brother.com/videos

Open the output paper tray

cover a.

Adjust the paper guides.

Fan the paper well and load it

in the tray.

Close the output paper tray

cover, and then slowly push

the tray completely into the

machine.

Pull out the paper support , a

and unfold the paper support

flap b so that the printed

pages do not fall.

Follow the LCD instructions to install the ink cartridges. Close

the ink cartridge cover. The machine will prepare the ink tube

system for printing.

NOTE

The first time you install a set of ink cartridges, the machine will use

an amount of ink to fill the ink delivery tubes for high-quality printouts.

This process will only happen once.

Follow the LCD instructions to set the date and time.

After setting the date and time, you can set the Firmware Update

defaults.

After finishing the machine setup, you can change the paper type or size.

For more information about paper handling, see the Online User’s Guide

at support.brother.com/manuals.

2Load plain A4 paper in the paper tray

5Install the inbox ink cartridges

3Connect the power cord

Follow the LCD instructions,

and then press . The [OK]

machine prints the Print

Quality Check Sheet.

Follow the LCD instructions to

check the quality of the four

colour blocks on the sheet, and

then start the cleaning procedure

if required.

OK Poor

7Check the print quality

6Set the date and time

After turning the machine on, you may need to set your country or language

(depending on your machine). If required, follow the LCD instructions.

4Select your country or language

Open the ink cartridge cover and remove

the orange protective part from the

machine.

NOTE

Do not throw away the orange protective part.

You will need it if you transport the machine.

• Most of the machine illustrations in this Quick Setup Guide show the DCP-J1800DW.

• The images in this guide are for illustration purposes only and may differ from the

actual products.

zh-TW

Can’t Connect? Check the following:

Wireless network Restart your wireless access point/

router (if possible). If still not successful, go to 11 .

Disconnect the cable. If still not successful, visit support.brother.com

for FAQs and Troubleshooting.

Restart your machine and

computer, and then go to 10 .

Wired network

USB connection

Visit setup.brother.com to download and install

Brother software.

Follow the on-screen instructions and prompts.

NOTE

For Wired Network Connection and USB Connection,

locate the correct port (based on the cable you are using)

inside the machine as shown.

Setup Finished

You can now print and scan using your machine.

To check for the latest firmware, visit

support.brother.com/up7.

Find your SSID (Network Name) and Network Key

(Password) on your wireless access point/router

and write them in the table provided below.

SSID (Network Name)

Network Key (Password)

Go to 10 to install

software.

SSID: XXXXXXX

Network Key: XXXX

If you cannot find this information, ask your network

administrator or wireless access point/router

manufacturer.

If setup is not successful, restart

your Brother machine and your

wireless access point/router, and

repeat 11 .

Important Notice for Network Security:

The default password to manage this machine’s

settings is located on the back of the machine

and marked “ ”. We recommend immediately Pwd

changing the default password to protect your

machine from unauthorised access.

For detailed machine information and product specifications, see the Online User's Guide at support.brother.com/manuals.

11 Manual wireless setup

If the wireless setup is not successful, try to set up the connection manually.

10 Connect your computer or mobile device to your machine

Follow these steps to complete the setup using one of the connection types available on your machine.

If any notifications appear on the LCD, clear them by

pressing [OK].

Clear the LCD notifications

setup.brother.com

Select the SSID (Network

Name) for your access point/

router and enter the Network Key

(Password).

When the wireless setup is

successful, the LCD displays

[Connected].

Follow the LCD instructions

to print the Adjustment Sheet.

The black circle mark is

located in the upper left corner

of the sheet.

Place the Adjustment Sheet

face down on the scanner

glass.

Make sure the black circle

mark is in the upper left corner

of the scanner glass.

Follow the LCD

instructions and

complete adjusting the

alignment.

When finished, remove

the Adjustment Sheet

from the scanner glass.

Adjust the print alignment (recommended)

To adjust the print alignment before using your machine, press .[Start]

NOTE

(Windows) You must install the Brother software if you

want to use the Cut Print function.

Go to your machine, and press >

[Find Wi-Fi Network] > [Yes].
