Unpack the machine and check the components

AC Power Cord

USB Port Cover

(Not included in all models)

Toner Cartridge and Drum Unit

Assembly

(Installed in the machine)

Quick Setup Guide Product Safety Guide

1Remove the packing materials and re-install the toner cartridge and drum unit assembly

2Load paper in the paper tray

Adjust the paper

guides.

3Connect the power cord and turn the machine on

Back Front

Do not exceed this mark.

Power button location may vary depending

on the model.

NOTE:

•The components included in the box may differ depending on your

country.

•The available connection interfaces vary depending on the model.

You must purchase the correct interface cable if you require one.

• USB cable

We recommend using a USB 2.0 cable (Type A/B) that is no more

than 2 metres long.

• Network cable

Use a straight-through Category 5 (or greater) twisted-pair cable.

•The illustrations in this show the HL-L6415DW.Quick Setup Guide

Remove the orange part.

Discard the silica

gel pack.

Quick Setup Guide

Read the for the correct installation procedure.Product Safety Guide Quick Setup Guideﬁrst,thenreadthis

Not all models are available in all countries.

The latest manuals are available at the Brother support website:

support.brother.com/manuals

Video setup instructions:

support.brother.com/videos

HL-L5210DN / HL-L5210DW / HL-L6210DW / HL-L6410DN / HL-L6415DW

D02DT9001-00

OCE/ASA/SAF/GLF/TWN

Version 0

Select your language (if needed)

1. Press▼or▲toselect ,and[Initial Setup]

then press .OK

2. Press▼or▲toselect ,and[Local Language]

then press .OK

3. Press▼or▲toselectyourlanguage,andthen

press .OK

4. Press .Cancel

For LCD models For touchscreen models

1. Onthemachine’stouchscreen,press

[Settings] [All Settings] > >

[Initial Setup] [Local Language] > .

2. Press your language.

3. Press .

5Connect your computer or mobile device to your machine

Follow these steps to complete the setup using one of the connection types available on your machine.

Can’t Connect? Check the following:

Restart your wireless access point/

router (if possible).

Disconnect the cable.

Wired network

USB connection

Ifstillnotsuccessful,goto .

Ifstillnotsuccessful,visitsupport.brother.com

for FAQs and Troubleshooting.

Restart your machine and

computer,andthengoto .

6Manual wireless setup (Wireless models)

Find your SSID (Network Name) and

Network Key (Password) on your wireless

access point/router and write them in the

table provided below.

SSID

(Network Name)

Network Key

(Password)

Ifyoucannotfindthisinformation,ask

your network administrator or wireless

access point/router manufacturer.

SSID: XXXXXXX

Network Key: XXXX

For LCD models

Toselectmenuoptions,press

▲or▼,andthenpressOK to

confirm.

Select > [Network]

[WLAN(Wi-Fi)] >

[Find Network].

Follow the LCD instructions.

For touchscreen models

Press >

[Find Wi-Fi Network].

Follow the LCD instructions.

Go to to install software.

Ifsetupisnotsuccessful,restartyour

Brother machine and your wireless

accesspoint/router,andrepeat .

Ifstillnotsuccessful,visit

support.brother.com.

Select the SSID (Network Name) for your

access point/router and enter the Network

Key (Password).

Whenthewirelesssetupissuccessful,the

touchscreen/LCD displays .[Connected]

Important Notice for Network Security:

The default password to manage this

machine’s settings is located on the back of

the machine and marked “ ”. Pwd

We recommend immediately changing the

default password to protect your machine from

unauthorised access.

Visit setup.brother.com to download and install

Brother software.

Follow the on-screen

instructions and

prompts.

setup.brother.com

Setup Finished

You can now print using your

machine.

Tocheckforthelatestfirmware,

visit support.brother.com/up7.

For LCD models

Pressandhold(orpressrepeatedly)▲/▼

to select one of the following characters:

0123456789abcdefghijklmnopqrstuvwxyz

ABCDEFGHIJKLMNOPQRSTUVWXYZ

(space)!"#$%&'()*+,-./:;<=>?@[\]^_‘{|}~

Ifthewirelesssetupisnotsuccessful,trytosetuptheconnectionmanually.

Forcertainmodels,thewirelessnetworkconnectioncanbeusedonlywhentheoptionalWirelessModuleisinstalled.

Fordetailedmachineinformationandproductspecifications,seetheOnline User's Guide at support.brother.com/manuals. ©2023BrotherIndustries,Ltd.Allrightsreserved.

Wireless network*
